PTZOptics 20X-ZCAM User manual

Rev 1.1 1/17

PTZ Optics 20X-ZCAM

User Manual

V1.1

(English)

Preface

Thank you for using this HD Professional Box Camera. This manual introduces the function, installation and operation of the

HD camera. Prior to installation and usage, please read the manual thoroughly.

Precautions

This product can only be used in the specified conditions in order to avoid any damage to the camera:

Don’t subject the camera to rain or moisture.

Don’t remove the cover. Removal of the cover may result in an electric shock. In case of abnormal operation,

contact the manufacturer.

Never operate outside of the specified operating temperature range, humidity, or with any other power supply

than the one originally provided with the camera.

Please use a soft dry cloth to clean the camera. If the camera is very dirty, clean it with diluted neutral detergent;

do not use any type of solvents, which may damage the surface.

Note

This is an FCC Class A Digital device. As such, unintentional electromagnetic radiation may affect the image quality of TV in a

home environment.

iii

Table of Contents

1 SuppliedAccessories ··················································································································iii

2 Notes······································································································································1

3 Features···································································································································2

4 Product Specifications··················································································································3

5 Main Unit·································································································································4

6 Serial Communication Control & Command Listings·············································································5

7 Menu Setting··························································································································· 17

8 Networking····························································································································· 21

9 Maintenance and Trouble Shooting································································································· 37

Supplied Accessories

When you unpack your camera, check that all the supplied accessories are included:

Camera ................................1

AC Power Adaptor ..............1

Power Cord...........................1

This User Manual ...............1

Notes

Electrical Safety

Installation and operation must be in accordance with national and local electric safety standards. Do not use any power

supply other than the one originally supplied with this camera.

Polarity of power supply

The power supply output for this product is 12VDC with a maximum current supply of 1A. Polarity of the power supply

plug is critical and is as follows.

Handling

Avoid any stress, vibration, or moisture during transportation, storage, installation and operation.

Do not expose camera to any corrosive solid, liquid, or gas to avoid damage to the cover which is made of a plastic

material.

Never power camera on before installation is complete.

Do not dismantle the camera - The manufacturer is not responsible for any unauthorized modification or dismantling.

Features

1. Panasonic 1/2.7” inch HD CMOS Sensor

2. 20x Optical Zoom

3. 58.6° field of view

4. 3G-SDI High Definition Video Output up to 60 fps

5. Wide Dynamic Range

6. High performance in low illumination situations (0.2 Lux)

7. Full 1920x1080p HD Resolutions up to 60 frames per second

8. 2D and 3D noise reduction with our latest “low noise CMOS sensor”

9. Button controls on back of camera

10. RS485 remote camera control interface

11. H.264 IP Streaming Output (dual stream) up to 30 fps

12. IP Remote Camera Control

13. Standard ¼-20 female thread for camera mounting

Product Specifications

Model

PTZ Optics 20X-ZCAM

Type

PTZ Optics HD 1080p Color Video Camera

Video System

720p50, 720p60, 1080i50, 1080i60, 1080p25, 1080p30, 1080p50, 1080p60

(with IP stream currently limited to max 1080p30)

Sensor

Panasonic 1/2.7”, CMOS, Total Pixels: 2.2M, Effective Pixels: 2.12M

Scanning Mode

Progressive

Lens

20x; f4.42mm - 88.5mm; F1.8 - F2.8

Minimal Illumination

0.2 Lux (F1.6, AGC ON)

Shutter

1/30s - 1/10000s

White Balance

Auto, Indoor, Outdoor, One-Push, Manual

Backlight Compensation

Yes

Digital Noise Reduction

2D & 3D Digital Noise Reduction

Video S/N

≥55dB

HorizontalAngle of View

3.6° (tele) - 58.6° (wide)

Vertical Angle of View

2.0° (tele) - 35.1° (wide)

Ceiling Installation

Yes

Image Mirroring

Yes

Number of Presets

PresetAccuracy

0.1°

HD Output

1x 3G-SDI female

Control Input / Output

1x RS-485: 3pin phoenix port, Max Distance: 1500m

Protocols: VISCA/Pelco-D/Pelco-P

Power Connector

JEITA type (DC IN 12V)

Input Voltage

12VDC (10.8 - 13.0V DC)

Current Consumption

1.0A (Max)

Operating Temperature

23°F - 104°F [-5°c - 40°c]

Storage Temperature

-4°F - 140°F [-20°c - 60°c]

Power Consumption

12W (Max)

Dimensions

2.4”W x 3.0”H x 5.7”D [60mm x 76mm x 144mm]

Weight

1.4 lbs. [0.63kg]

Main Unit

1. 3G-SDI Female connector

2. Ethernet Port

3. RS485

4. Menu Navigate Buttons

5. Audio in/out

6. DC 12V power jack

7. Power indicator

Serial Communication Control

In default working mode, the camera is able to connect to a VISCA or Pelco controller with an RS485 serial interface.

RS485 Communication Control

The camera can be controlled via RS485, Half-duplex mode, with support for VISCA, Pelco-D or Pelco-P protocol.

The parameters of RS485 are as follows:

Baud rate: 2400, 4800 or 9600 bps.

Start bit: 1 bit.

Data bit: 8 bits.

Stop bit: 1 bit.

Parity bit: none.

Note:As this camera does not have pan or tilt functionality, not all of the commands in the following command lists will apply.

VISCA Command List

Part 1: Camera-Issued Messages

ACK/Completion Message

Command

Function

Command Packet

Comments

ACK/Completion

Messages

ACK

z0 4y FF

(y: Socket No.)

Returned when the command is accepted.

Completion

z0 5y FF

(y: Socket No.)

Returned when the command has been

executed.

z = Camera Address + 8

Error Messages

Command

Function

Command Packet

Comments

Error Messages

Syntax Error

z0 60 02 FF

Returned when the command format is

different or when a command with illegal

command parameters is accepted.

Command Buffer Full

z0 60 03 FF

Indicates that two sockets are already being

used (executing two commands) and the

command could not be accepted when

received.

Command Canceled

z0 6y 04 FF

(y: Socket No.)

Returned when a command which is being

executed in a socket specified by the cancel

command is canceled. The completion

message for the command is not returned.

No Socket

z0 6y 05 FF

(y: Socket No.)

Returned when no command is executed in a

socket specified by the cancel command, or

when an invalid socket number is specified.

Command Not

Executable

z0 6y 41 FF

(y: Execution command

Socket No. Inquiry

command: 0)

Returned when a command cannot be

executed due to current conditions. For

example, when commands controlling the

focus manually are received during auto

focus.

Part 2: Camera Control Commands

Command

Function

Command Packet

Comments

AddressSet

Broadcast

88 30 01 FF

Address setting

IF_Clear

Broadcast

88 01 00 01 FF

I/F Clear

CAM_Power

8x 01 04 00 02 FF

Power ON/OFF

Off

8x 01 04 00 03 FF

CAM_Zoom

Stop

8x 01 04 07 00 FF

Tele(Standard)

8x 01 04 07 02 FF

Wide(Standard)

8x 01 04 07 03 FF

Tele(Variable)

8x 01 04 07 2p FF

p = 0(low) - 7(high)

Wide(Variable)

8x 01 04 07 3p FF

Direct

8x 01 04 47 0p 0q 0r 0s FF

pqrs: Zoom Position

CAM_Focus

Stop

8x 01 04 08 00 FF

Far(Standard)

8x 01 04 08 02 FF

Near(Standard)

8x 01 04 08 03 FF

Far(Variable)

8x 01 04 08 2p FF

p = 0(low) - 7(high)

Near(Variable)

8x 01 04 08 3p FF

Direct

8x 01 04 48 0p 0q 0r 0s FF

pqrs: Focus Position

Auto Focus

8x 01 04 38 02 FF

AF On/Off

Manual Focus

8x 01 04 38 03 FF

Auto/Manual

8x 01 04 38 10 FF

CAM_ZoomFocus

Direct

8x 01 04 47 0p 0q 0r 0s

0t 0u 0v 0w FF

pqrs: Zoom Position

tuvw: Focus Position

CAM_WB

Auto

8x 01 04 35 00 FF

Normal Auto

Indoor mode

8x 01 04 35 01 FF

Indoor mode

Outdoor mode

8x 01 04 35 02 FF

Outdoor mode

OnePush mode

8x 01 04 35 03 FF

One Push WB mode

Manual

8x 01 04 35 05 FF

Manual Control mode

OnePush trigger

8x 01 04 10 05 FF

One Push WB Trigger

CAM_RGain

Reset

8x 01 04 03 00 FF

Manual Control of R Gain

8x 01 04 03 02 FF

Down

8x 01 04 03 03 FF

Direct

8x 01 04 43 00 00 0p 0q FF

pq: R Gain

CAM_Bgain

Reset

8x 01 04 04 00 FF

Manual Control of B Gain

8x 01 04 04 02 FF

Down

8x 01 04 04 03 FF

Direct

8x 01 04 44 00 00 0p 0q FF

pq: B Gain
