1

TableofContents

Introduction

RandomPatchGeneration

Grains

ParameterModulation

StereoHandling

BypassandMeterSection

EmitSection

Rate

RateLengthLink

Length

Gate

Jitter

Trigger

InputSection

MainAudioInput

Freeze

GrainsDelaySection

Delay

Scale

Spray

GrainsPitchSection

PitchProbability

Reverse

GrainsEnvelopeSection

Shape

Skew

GrainsOutputSection

Level

Pan

GrainsModulationSection

ModulationFrequency

ModulationFMAmount

ModulationAM/RingAmount

GrainsDisplay

OutputSection

MainAudioOutput

NormalizeGrainLevels

InsertEffects

Diffuse

Feedback

Spread

Dry/Wet

Level

2

PatchSection

ModulationLFOSection

Reset

Rate

Phase

PhaseStereo

Waveform

Lag

Output

ModulationCVSection

ModulationNoiseSection

PhaseStereo

Output

SystemDiagrams

SystemSignalPath

GrainPath

RemoteItems



 

3

Introduction

Fritzisagranulareffectsdevice.Incomingaudioissampledandplayedbackinsmallsegmentscalledgrains.

Manygrainscanplaybackatthesametime,eachwithitsownsnapshotofparameters.Thissimple

mechanismcancreatecomplexandpsychedeliceffectsincludingpitchshifting,dronesynthesis,stutters,

glitches,reverbs,pitchsmearing,timesmearing,chordgeneration,textureclouds,sonicbursting,andmany

effectsthataretoostrangetobenamed.



FrontPanel



BackPanel



 

4

RandomPatchGeneration



QuitepossiblythemostimportantbuttononFritzistherandompatchgenerator.Itistheiconofadienextto

thepatchloadingandsaving.InsertFritzintoyoureffectschainandkeepclickingthedietocomeupwith

endlesspermutationsofgranulareffects.

Grains

Manygrainscanbeactiveandoverlappingatthesametime.Whenagrainiscreated,itsparametersare

lockedinplace.Sowhiletherecanbeconstantparametermodulation,asinglegrainplaysbackwiththe

snapshotofthoseparametersfromwhenitwascreated.

ParameterModulation



ModulationAmountKnob.



ModulationSourceSelection.



Almosteveryparametercanbemodulated.Eachmodulationknob( )issharedbythefivemodulation

sources. 

Theactivemodulationsourceisselectedviathebuttons( )intheMODsection.Themodulationknobwill

showtheactivemodulationsources’respectivecolorunderneaththeknob.



Thecurrentamountofmodulationforeachsourceisshowninthedisplaynexttotheknob( ).

StereoHandling

Fritzhastwoseparategranularsystemsrunninginparallel,oneforeachstereochannel.Almostallparameter

modulationisalsoinstereoandcanbeadjustedwithLRPhaseStereocontrols.Grainscanfadeovertothe

otherchannelusingtheirPanparameter.TheStereoSpreadparameteradjuststheoutputstereofieldwidth.

AudioandCVInputsonthebackarenormalizedtofunctionasmonowhenonlytheleftisconnected.



5

BypassandMeterSection



BypassandMeterFrontPanel



InBypassmode,theinputsignalpassesthrough,unaffected,tothemainoutputsofthedevice.InOnmode,

thedeviceoutputstheprocessedsignal.Offmodemutestheinputsandoutputs.



Theleftstereometershowstheinputsignallevel. 

Therightstereometershowstheoutputsignallevel.



 

6

EmitSection



EmitSectionFrontPanel 



EmitSectionBackPanel 



Rate



Setsthefrequencyatwhichgrainsarecreated.Whentemposyncisdisabled,therangeisfrom0Hz(Off)to

500Hz.Whentemposyncisenabled,theavailableratesare:32/4,28/4,24/4,20/4,16/4,12/4,8/4,7/4,6/4,

5/4,4/4,7/8,3/4,5/8,2/4,7/16,5/8T,3/8,4/8T,5/16,1/4,3/16,2/8T,1/8,1/8T,1/16,1/16T,1/32,1/32T,1/64,

1/128. 



RateLengthLink



EnablingtheRateLengthLinkwillcausetheLengthofgrainstobeinverselyproportionaltotheemitRate.If

theemitRategoesup,theLengthofthegrainsdecreases.IftheemitRategoesdown,thegrainLength

increases.Thishelpscreateasteadynumberofactivegrainswhentheratefluctuates.



 

RatechangewithLinkenabled.Rateincreasescauselengthdecreases.



 

RatechangewithLinkdisabled.Rateincreasesdoesnotaffectlength.



7

Length



Setsthedurationoftheemittedgrain.IfRateLengthLinkisdisabled,theLengthrangeis0msto1sec.If

RateLengthLinkenabled,thentheLengthrangeisfrom0%to1000%.Whenitissetto100%,theaudio

willbesmoothandcontinuousaslongasallotherparametersareattheirdefaultstate.



 

Linkenabled.200%

 

Linkenabled.100%

 

Linkenabled.50%

 

Linkenabled.25%



Noisemodulatedlength



 

8

Gate



Gatedetermineswhethertheemitterisactiveornot.IfGateisoff,nograinswillbeemitted.TurningtheGate

offandthenaddingmodulationcancreaterhythmicgrainemissions.ThereisanadditionalCVinputonthe

backforcontrollingthegate.

Jitter



Jitterisrandomnoiseaddedtotheemitterclocktiming.IftheemitRateissetat10Hz,agrainwillbeemitted

every100ms.AJitterof100%wouldcauseeachgrain’sstarttorandomlybeshifted0msto100ms.Jitter

doesnotaffectLength,onlyemissiontime.



 

Jitter0%

 

Jitter50%

 

Jitter100%



Trigger



TriggerCVInputwillcauseasinglegraintobeemitted.ThisoverridesanycurrentGatevalue.



 

9

InputSection



InputSectionFrontPanel



InputSectionBackPanel

MainAudioInput



Mainstereoinput.Asinglemonoinputontheleftchanneliscopiedtotherightchannel.

Freeze



Freezewillstoprecordingaudiodataintotheinputbuffer,causingtheaudiodatatobefixedandthegrainsto

playfrompastcapturedaudio.



 

10
