3) Press the【ENTER】button to escape and save.
6.4 WIRELESS SET
1) Press the【ENTER】button in【WIRE】menu, then enter to the wireless set.
2)【RESET】Analog the wireless module,it is the process of off and pressing the
button then power
3)【KEY】similar as the external key.
6.5 BATTERY OUTPUT SETTING
1) Press the【ENTER】button in【BAT】menu, then enter to the Battery output
setting.
2) Press the【UP/DOWN】button to select【HIGH】, 【MIDDLE】, 【LOW】
3) Press the【ENTER】button to escape and save.
6.6 COLOR CAST CALIBRATION SETTING
1) Press the【ENTER】button in 【CAL】menu, then enter to the color cast
calibration setting.
2) Press the【UP/DOWN】button to select 【RED】，【GREEN】...【WHITE】
3) Press the【UP/DOWN】button to set up the【0-255】numerical value.
4) On the【USE】interface, pressing【YES】button means valid, 【NO】means
invalid.
5) Press the【ENTER】button to escape and save.
Illustrations: When pressing the【YES】button which means valid on the【USE
】interface, the actual output value of RED... WHITE is output in accordance with
the percentage which the color cast calibration value divides 255.
6.7 CHANNEL MODE SETTING
1) Press the【ENTER】button in 【CHMD】menu, then enter to the channel
mode setting.
2) Press the【UP/DOWN】button to select【11CH】，【8CH】，【6CH】，【
5CH】
3) Press the【ENTER】button to escape and save.
6.8 DIMMING MODE SETTING
1) Press the【ENTER】button in【DIM】menu, then enter to the dimming mode
setting.
2) Press the【UP/DOWN】button to select【LIN】，【SQR】，【ISQR】，【
SCUR】，【LIN.】，【SQR. 】，【ISQR.】And SCUR.】.
3) Press the【ENTER】button to escape and save.
Illustrations：When setting【LIN.】【SQR. 】，【ISQR. 】and 【SCUR. 】in
