General Intro

LED is the acronym for “Light Emitting Diode”. LED technology is based on

the electroluminescence generated by the emission of photons. Unlike

common light bulbs whose ﬁ laments work at very high temperatures

and feature a remarkable thermal inertia, an LED emits cold light. The

LEDs that we are interested in are those that emit red, orange, yellow, or

green light. In relatively recent times the creation of a blue LED was also

achieved. This development is very important as a blue LED combined

with green and red radiations allows the creation of a white light sour-

ce and also of all those colours allowed by an RGB (additive synthesis)

combination. In recent years LED technology has been the choice in all

applications requiring high reliability, long life span and top eﬃ ciency.

Some of its main applications are:

• Decoration and signage

• Variable message LED Walls

• Entertainment and architectural lighting

LED technology is employed more and more in architectural and enter-

tainment lighting instead of more traditional light sources, but its low

power prevents it from replacing them completely. Basically, its main

drawback is the amount of emitted light (ﬂ ux of light expressed in lu-

mens) which ranges up to 120 lm for the most recent professional mo-

dels, whereas a 60W incandescence light bulb emits a light ﬂ ux of about

550 lumens.

The advantages in the use of LED technology for lighting are:

• Long life span (high emission LED can last up to 50,000 hours)

• No maintenance costs

• High performance (if compared to incandescent light bulbs or

halogen lights)

• Non polluting, as it does not include IR or UV components

• Sharp spot eﬀ ect (highly speciﬁ c point source)

• Safety, as it works with very low voltage (normally around 24 Vdc)

• No sensitivity to humidity or vibrations

• No mercury

Finally, the commercial strength of such equipment lies in its brightness

(four times brighter than ﬂ uorescent lights and tungsten ﬁ lament lights),

low price, high eﬃ ciency and reliability. Furthermore, an LED can last a

lot longer than any classic light source (especially if under mechanical

stress) and its very low absorption allows it to be used anywhere.

Architectural LED

Entertainment LED 6

Made in Italy LED 29

LED Tubes 45

Index

Moving Heads

90 high power RGBW LED Moving Head

Power supply: 100-240V 50/60Hz

Rated Power: 550W

LED: 90 (18Rx2W – 24Gx5W – 24Bx5W – 24Wx5W)

Eﬀ ects: RGBW Colour Mixing, Built-in Programs, Strobe, White Balance, RGB Calibra-

tion, Dimmer, Colour Macros.

Control: DMX 10/14 channels – Stand Alone – Master/Slave

Movements: 540° Pan – 270° Tilt – adjustable speed

IP rating: IP20

This unit complies with CE directives

0.23

0.44

0.68

1.01

1.44

650LUX

Distance (m)

Diameter (m)

180 86 51 35

BLUE

15°

0.23

0.46

0.69

0.95

1.40

6930LUX

Distance (m)

Diameter (m)

1850 860 500 330

GREEN

15°

0.20

0.39

0.56

0.81

1.42

3750LUX

Distance (m)

Diameter (m)

945 407 228 139

RED

15°

0.22

0.43

0.67

0.82

1.14

10800LUX

Distance (m)

Diameter (m)

2830 1320 743 514

RGB

15°

0.22

0.42

0.65

0.94

1.26

19300LUX

Distance (m)

Diameter (m)

5030 2300 1302 880

RGB+WHITE

15°

0.22

0.42

0.62

0.83

1.25

8720LUX

Distance (m)

Diameter (m)

2260 1040 590 394

WHITE

15°

14 channels DMX PLLEDHTML

100

0° - 540°

Min

Max Macro

Macro

DMX Pan Tilt

fine

Pan/Tilt

speed Macro

Value Ch1

0° - 280°

Tilt

Ch2 Ch4

Pan

fine

Ch3 Ch5 Ch10

Slow

Fast

Strobe

Ch12

Red

Ch6

Green

Ch7

Blue

Ch8

White

Ch9

Dimmer

Ch11

Dimmer

speed

Ch13

Control

Ch14

Min

Max

Power : 100 - 240V 50/60Hz

LED: 90 RGBW - (18x2WR - 24x5WG - 24x5WB - 24x5WW)

Size: L433xW320xH462 mm

Weight: 20,3 Kgs

PLLEDHTML

Moving Heads

LED moving head with RGB technology. This projector provides illumination via 36

high-eﬃ ciency LEDs (12 red, 12 green, 12 blue) oﬀ ering high luminous output as well

as inﬁ nite RGB colour mixing.

LED WASH MOVING HEAD

Input Voltage: 230V / 50Hz - 120V / 60Hz (selectable with onboard switch)

High Power 1W LEDs: 12 red, 12 green, 12 Blue -1,4W over 50000 hours rated life

Beam angle: 15 degree

Movements: 540 degree PAN and 270 degree

Colours & rainbow eﬀ ect: pre-programmed

Electronic dimmer for light output adjustment: from 0 to 100% (no colour varia-

tion) Flash rate 1-25 fps

Protocol: DMX512 - 10 ch (12 Ch in 16 bit mode)

Fuse: T2A Max.

Power Consumption: 70VA

10 channels DMX PLLEDMLBG

100

0° - 540°

Macro

DMX Pan Tilt

fine

Macro

Value Ch7

0° - 270°

Tilt

Ch8 Ch10

Pan

fine

Ch9

Ch5

Slow

Fast

Strobe

Ch1

Red

Ch2

Green

Ch3

Blue

Ch4

Macro

speed

Ch6

Min

Max

Power: 230V 50Hz - 120V 60Hz

LED: 36: 12R - 12G - 12B

Size: mm. 300L x 290W x 350H

Weight: 9,8 Kgs

PLLEDMLBG

Moving Heads

RGB LED Spot Moving Head

Power supply: 230V 50Hz - 120V 60HZ

Rated Power: 50W

LED: 1 x 15W RGB full colour LED

Gobo wheel: 9 ﬁ xed gobos + white

Eﬀ ects: Dimmer, Strobe, Colour Macros.

Control: 13-channel DMX – Stand Alone – Master/Slave – Sound Mode

Movements: 540° Pan – 270° Tilt - adjustable speed

IP rating: IP20

This unit complies with CE directives

13 channels DMX PLLEDMLSUS

100

0° - 540°

Macro

DMX Pan Tilt

fine Macro

Value Ch1

0° - 270°

Tilt

Ch3 Ch4

Pan

fine

Ch2 Ch10

Gobo

Ch13

Red

Ch7

Green

Ch8

Blue

Ch9

Pan / Tilt

speed

Ch5

Min

Max OFF

Lamp

ON/OFF

Ch6

Macro

speed

Ch11

Music

mode

Ch12

OFF

Power : 230V 50Hz - 120V 60Hz

LED: 1 RGB full colour - 15W

Size: L177xW177xH250 mm

Weight: 4,5 Kgs

PLLEDMLS

Moving Heads

RGB LED Wash Moving Head

Power supply: 230V 50Hz 120V 60Hz

Rated Power: 50W

LED: 1 x 15W RGB full colour LED

Eﬀ ects: Dimmer, Strobe, Colour Macros, Macro Speed.

Control: 13-channel DMX – Stand alone – Master/Slave – Sound Mode

Movements: 540° Pan – 270° Tilt – adjustable speed

IP rating: IP20

This unit complies with CE directives

12 channels DMX PLLEDMLWUS

100

0° - 540°

Macro

DMX Pan Tilt

fine Macro

Value Ch1

0° - 270°

Tilt

Ch3 Ch4

Pan

fine

Ch2 Ch10

Red

Ch7

Green

Ch8

Blue

Ch9

Pan / Tilt

speed

Ch5

Min

Max OFF

Lamp

ON/OFF

Ch6

Macro

speed

Ch11

Music

mode

Ch12

OFF

Power : 230V 50Hz - 120V 60Hz

LED: 1 RGB full colour - 15W

Size: L177xW177xH250 mm

Weight: 4,5 Kgs

PLLEDMLW

Colour Changers

RGB LED WASHER

LEDs: 54 LEDs 1W (18 Red – 18 Green – 18 Blue)

Power supply: 230V/50HZ

Colours System: RGB (Red, Green, Blue) blending system to obtain an inﬁ nite series

of colour nuances.

Control: 12 DMX control channels, Stand alone and Master/Slave

Housing Protection: IP 65.

This unit complies with CE directives.

RGB MUTIPAR LED

LEDs: 36 LEDs 1W (12 Red – 12 Green – 12 Blue)

Power supply: 230V/50HZ

Colours System: RGB (Red, Green, Blue) blending system to obtain an inﬁ nite series

of colour nuances.

Control: 9 DMX control channels, Stand alone and Master/Slave

Housing Protection: IP 33.

This unit complies with CE directives.

Recommended remote controller (optional)

DMX, auto programs

Recommended remote controller (optional)

DMX, auto programs

(0.9x0.5)

(1.4x1.0)

(2.0x1.6)

(2.5x2.1)

(3.0x2.6)

307LUX

Distance (m)

Area (sqm)

98 56 27 22

BLUE

15°

(0.9x0.5)

(1.4x1.0)

(2.0x1.6)

(2.5x2.1)

(3.0x2.6)

1763LUX

Distance (m)

Area (sqm)

570 270 159 128

GREEN

15°

(0.9x0.5)

(1.4x1.0)

(2.0x1.6)

(2.5x2.1)

(3.0x2.6)

1130LUX

Distance (m)

Area (sqm)

360 167 97 78

RED

15°

(0.9x0.5)

(1.4x1.0)

(2.0x1.6)

(2.5x2.1)

(3.0x2.6)

2970LUX

Distance (m)

Area (sqm)

950 450 266 218

RGB 100%

15°

0.52

1.05

1.57

2.10

2.60

300LUX

Distance (m)

Diameter (m)

76 35 20 15

BLUE

15°

0.52

1.05

1.57

2.10

2.60

1780LUX

Distance (m)

Diameter (m)

460 210 120 90

GREEN

15°

0.52

1.05

1.57

2.10

2.60

1145LUX

Distance (m)

Diameter (m)

290 130 72 50

RED

15°

0.52

1.05

1.57

2.10

2.60

2750LUX

Distance (m)

Diameter (m)

700 320 190 145

RGB 100%

15°

12 channels DMX 9 channels DMX

Power: 230V/50Hz

Size: L510xW480Xh210mm

Weight: 8,3 Kg

LED: 54 LEDs W (18 Red – 18 Green – 18 Blue)

Power: 230V/50Hz

Size: L310xW340xH220mm

Weight: 5 Kg

LED: 36 LEDs 1W (12 Red – 12 Green – 12 Blue)

Housing Protection:

IP 65.

This unit complies with CE directives.

Control:

Housing Protection:

This unit complies with CE directives.

9 DMX control channels, Stand alone and Master/Slave

This unit complies with CE directives.

PLHT3LED PLHTLED

PLLEDCKT PLLEDCKT
