Pro-Ject Audio Systems Phono Box II User manual

INSTRUCTIONS FOR USE

Pro-Ject Phono Box II

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO phono amplifier.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Setting the cartridge mode

The Phono Box must be used in either MM (moving magnet) or MC (moving coil) mode according to the

construction principle of the pickup cartridge to be used. To find out which type your cartridge is please

consult the literature accompanying your cartridge. If in doubt please consult your dealer.

A switch at the back of the Phono Box sets the correct level of amplification for the cartridge.

Before setting MM / MC mode the unit must be disconnected from the power supply and amplifier.

Connecting the record player

Connect the tonearm signal lead to the In of the Phono Box.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the left

channel black or white. The earthing wire of the tonearm lead should be connected to the earth terminal.

Connection to the amplifier

Connect the Out of the Phono Box to a line input (such as AUX, CD, Tuner, Tape or Video) on your amplifier.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the left

channel black or white.

Make all connections whilst the Phono Box is disconnected from the power supply.

Do not connect the Phono Box output to a phono input (sometimes labelled gram, disc or RIAA) on

the amplifier.

Mains power connection

The phono amplifier is supplied with a power supply suitable for your country's mains supply. Check the label

before connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug

from the power supply to the Power ~16V socket of the Phono Box before connecting the power supply to

the mains.

Technical specifications Pro-Ject Phono Box II

THD, MM / MC <0,01 / <0,05%

Gain, MM / MC 40dB / 60dB

Output voltage typically, MM / MC 300mV at 1kHz - 3mV (MM Input) / 0,3mV (MC input)

Input impedance, MM / MC 47kohms/120pF / 100ohms/120pF

Noise floor, MM / MC 86dB / 68dB (94dB / 75dB - A weighted)

RIAA-equalisation curve accuracy Max. 0,5dB/20Hz - 20kHz

Power consumption 16V/30mA AC

Outboard power supply 16V/200mA AC, suitable for your country's mains supply

Dimensions (W x H x D) 103 x 38 x 115mm

Weight without power supply 570g

Potential incorrect use and fault conditions

No signal on one or both channels:

No connection between player and phono amplifier ore amplifier. This could be due to a faulty plug,

broken wire or solder joint or simply loose plug/socket connection.

Strong hum:

No earth connection from cartridge or arm or arm cable to phono amplifier, or earth loop.

Output too quiet or too loud, or distorted:

MM / MC mode incorrectly set - input overloading or insufficiently amplified.

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,

please contact your dealer for further advice. Only when the problem cannot be resolved there should the

unit be sent to the responsible distributor in your country.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use. Modification or change to any part of the product by unauthorized persons release the

manufacturer from any liability over and above the lawful rights of the customer.

PRO-JECT is a Registered Trademark of H. Lichtenegger.

This guide was produced by: Audio Trade GmbH

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.
