Pride Mobility Jazzy Select 7 User manual

800-800-8586 (US) • 888-570-1113 (Canada) • www.pridemobility.com

Jazzy®SelectTM 7

JZ SEL 7 SS - 08/07

The Jazzy®SelectTM 7 oﬀers full-size power chair

options and performance on an ultracompact frame

for smooth maneuverability. A tight turning radius

of only 20.5” and Active-Trac® Suspension give the

Jazzy Select 7 strong outdoor performance without

compromising superb indoor maneuverability.

ULTRACOMPACT FRAME FOR

SMOOTH MANEUVERABILITY

JAZZY®SELECTTM 7

shown in Jazzy Blue with high-

back seat, PG GC controller and

foot platform

FEATURES

. Standard Active-Trac® Suspension

for varied terrain

. PG GC controller

. Powerful two-motor, mid-wheel

drive design oﬀers outstanding

maneuverability

. Low center of gravity design delivers

a very smooth and stable ride

. 10” knobby drive wheels and

optimum weight distribution

provide superior traction

. Speed range adjustable up to 4 mph

. On-board battery charger

OPTIONS

. Contoured high-back with solid

seat pan

. Cup holder

. Weather cover

. Rear basket

. Oxygen tank holder

. Cane/crutch holder

. Walker holder

Weight capacity: 300 lbs.

Maximum speed: Up to 4 mph

Ground clearance: 2.5”

Turning radius: 20.5”

Overall length: 36”

Overall width: 23”

Wheels: Drive: 10”

Front anti-tips: 6” solid

Rear casters: 8” solid

Suspension: Active-Trac®

Drive train: Two-motor, mid-wheel drive

Braking system: Intelligent braking

(electronic, regenerative disc brakes)

Std. Electronics: 40 amp, PG GC controller

Specialty controls: N/A

Battery charger: On-board, 4 amp (standard)

Per-charge range: Up to 15 miles

Battery requirements: (2) 12 volt, deep cycle

Battery size: U-1

Transport weight

Battery weight: 24.5 lbs. each

Base weight: 77 lbs.

Seat weight: 37 lbs. (medium-back)

Max. Seat dimensions: 20” x 20”

Warranty: 5-year limited warranty on frame; 1-year limited warranty

on electronics; 1-year limited warranty on drive motors

Colors:

Jazzy®SelectTM 7

800-800-8586 (US) • 888-570-1113 (Canada) • www.pridemobility.com

The information contained herein is correct

at the time of publication; we reserve the right to

alter speciﬁcations without prior notice. Speed and

range vary with user weight, terrain type, battery

charge, battery condition and tire pressure. Due to

manufacturing tolerances and continual product im-

provement, length, width, turning radius and ground

clearance can be subject to variance of

+ or – 3 %.

Jazzy Red Jazzy Blue

•Backpacker®Plus

•Full Platform

•Power chair lift with straps

•Silver Boom 300

These lifts are compatible with the Jazzy® SelectTM 7.

Full

Platform

Backpacker® Plus

The Jazzy® SelectTM 7

series models include:

.Jazzy Select 7-2S-C

.Jazzy Select 7-2S-SS
