Prestigio PMP5597D User manual

Quick Start Guide

Prestigio MultiPad

PMP5597D

1. Packing List

1. Prestigio MultiPad 5597D 2. UK AC Adapter

3. Carrying Case 4. USB Cable

5. Quick Start Guide + Legal 6. Warranty Card

and Safety Notices

2. Device Overview

Quick Start Guide

Prestigio MultiPad

PMP5597D

Device Overview

Power

Turn on/off the device; Suspend/Activate

the device

DC port

AC adapter connection.

HDMI Button

HDMI cable connection.

USB port

USB connection

Micro SD Card Slot

Insert the Micro SD card

USB port

USB connection

Earphone Jac

k Earphones connection.

Rear Camera

Take photos

Home

Back to Home page

Vol +\ Vol -

Adjust the volume level

Reset

Reset the device if it fails to operate correctly

Front

Camera Take photos or video chat

Getting Started

3. Charging

Insert the connector of adaptor to the DC port on the device and

connect the power adapter to the wall socket for charging.

Normally it takes approximately 4 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

Notice: The device cannot be charged via USB.

Quick Start Guide

Prestigio MultiPad

PMP5597D

4. Power on/Power off

Press and hold the Power Button to turn on the device. It will

automatically enter the Home screen after the start-up screen.

Press the Power Button once to enter sleep mode and press it again

to awake the device.

Press and hold the Power Button, and then tap on OK button to power

off the device.

5．Inserting a Memory Card

The device supports micro SD/SDHC cards.

To insert a Micro SD card, place the card connector towards the rear

side of the device and the printing side of the card towards the front

side of the device.

To remove the micro SD card, gently press the edge of the card to

release the safety lock and pull the card out of the slot.

To access the files on the memory card, select File icon and tap on

SD Card.

Notice: When you are reading the file from micro SD card, please

don’t remove it, otherwise the device could fail to operate correctly.

Quick Start Guide

Prestigio MultiPad

PMP5597D

Technical Specification

Processor Dual Core RK3066 2 x 1.6GHz ARM CPU

RAM 1GB DDR3

OS Android 4.0 (Ice Crean Sandwich)

Display 9.7” IPS LCD, Capacitive multi touch

Resolution 1024 x 768 pixels

Storage capacity 8 GB flash memory

(about 6.0 GB are accessible by user),

Memory card slot supports micro SDHC card up to 32

Interfaces USB 2.0, Micro SD (micro SDHC compatible),

USB Host

Communications Wi-Fi (802.11 b/g/n)

Battery 7000 mAh Li-Polymer battery

Dimensions 243×190×10.5（mm）(L x W x H)

Weight 620 g

Storage Temperature -10℃～+60℃

Operation Temperature 0℃～+50℃

Storage Relative

Humidity 0% ～90%，Non-Condensed

Operation Relative

Humidity 0% ～90%，Non-Condensed

Disclaimer

As the Prestigio products are constantly updated and improved, your device’s

software may have a slightly different appearance or modified functionality than

presented in this Quick Start Guide.

Quick Start Guide

Prestigio MultiPad

PMP5597D

WARRANTY AND LIMITED LIABILITY

This product is sold with a limited warranty and specific remedies are

available to the original purchaser in the event the product fails to conform

to the limited warranty. For detailed warranty terms, please see:

http://www.prestigio.com/service

MANUFACTURER SHALL NOT BE LIABLE FOR ANY SPECIAL,

INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF

INFORMED OF THE POSSIBILITY THEREOF IN ADVANCE.

LITHIUM-ION BATTERY CAUTION

This product is equipped with a Lithium-Ion battery. Do not pierce, open,

disassemble it, or use it in a humid and/or corrosive environment. Do not

put, store or leave your product in or near sources of heat, in direct strong

sunlight, in a high temperature location, in a pressurized

container or in a

microwave oven. Do not expose

to temperatures over

60 C (140 Fl. If the

battery leaks and you come into contact with the leaked fluids, rinse

thoroughly with water and seek medical attention immediately. Failure to

follow these instructions could cause the Lithium-Ion battery to leak acid,

become hot, explode or ignite and cause injury and/or damage.

OPTIMIZING BATTERY PERFORMANCE



Do not leave your battery charging for more than one week.

Doing so runs the risk of overcharging the battery and

shortening its total life span.



If the device is not used for an extended period of time, the

battery will slowly discharge and the device will need to be

recharged before using again.



Unplug the charger from the wall when it is not being used.



Use only an original manufacturer's battery in the device.

Quick Start Guide

Prestigio MultiPad

PMP5597D

WARNINGS AND SAFETY INSTRUCTIONS

CAUTION

To prevent risks of electric shock, this unit must only be opened by

qualified service personnel. Power off and disconnect the power supply

cable before opening the unit.

WARNING

To prevent fire or shock hazard, do not expose the unit to rain or

moisture.

Use of this product is for personal use only. Copying CDs or loading music,

video, or picture files for sale or other business purposes is or may be a

violation of copyright law. Copyrighted materials, works of art, and/or

presentations may require authorization to be fully or partially recorded.

Please be aware of all such applicable laws concerning the recording and

use of such for your country and jurisdiction.

SAFETY

For driving safety, only a passenger should operate the device when the

car is in motion and not the driver. Laws governing the usage of

electronic devices by the driver may be applicable in your jurisdiction

and/or country.

Install your product carefully

Make sure your product and its accessories are solidly secured when you

are using them in a car. Avoiding mounting your device and its accessories

near the airbag opening areas. Equipment that is not accurately fixed in a car

could result in serious injury when the airbag

activates.

Handle the batteries and charger with care and respect the recycling

instructions



only manufacturer's certified batteries and charger for your

product.



Using batteries or a charger that is not certified by the

manufacturer can result in serious injury or damage your product.

Quick Start Guide

Prestigio MultiPad

PMP5597D



Never throw a battery into a fire. See your current local

regulations for

information

on battery recycling.



Never put your device inside of, or on top of, a heating device

such as

microwave oven, toaster oven, or heater. When batteries

heat up, there

is a risk of explosion.



Be careful to never crush or perforate the battery. Avoid exposing

the battery to high external pressure which could provoke an

internal short-circuit and overheating.

Use only accessories that are PRESTIGIO branded or certified by

manufacturer

The use of incompatible accessories with the product can cause injury.

Handle your product with care



Keep your product away from any sources of humidity. This can

seriously damage the device. Do not manipulate your device with

wet hands. Any damage done to the device due to its contact

with water voids your guarantee.



Do not use or store your product in an area that is dusty or dirty.

This can deteriorate the components in your device.



Your device is a complex electronic product. Keep it protected

from falls And physical shock. Do not subject it to violent

movements.



Do not paint your product. Doing so could make movable parts

unusable and reduce or limit its functionality.



Other' products that create a magnetic field could hamper the

functionality of your product. Do not use protective covers or

cases that have magnetic closures. Do not allow your device to

stay in prolonged contact with electromagnetic fields.

Only PRESTIGIO certified technicians are qualified to repair your device

In calling upon nonqualified persons to repair your product, you run the

risk of damaging your device and voiding your guaranty.

Quick Start Guide

Prestigio MultiPad

PMP5597D

Avoid interference with other electronic products

Your device radiates radio frequency

(RF)

signals that could interfere

with the functioning of other electronic devices that are insufficiently or

incorrectly protected from

energy, such as pacemakers, hearing aids,

medical devices, or any other electronic device found in your home or car.

Contact the maker of the equipment to resolve any possible interference

problems.

Other Security Instructions

Always manipulate your device with care. Keep it in a clean environment

away from dust.



Do no expose the device to extreme temperatures.

Do not drop or throw the device



Do not allow the device to come In close contact to a flame.



CHILD PROTECTION:

Keep the device away from children. Do

not allow children to play with this device. They can hurt

themselves or others with this device as well as damage It.

Besides, little kids would much prefer their parents play with them

then pass them an electronic

device.

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with limits for a

Class B digital device, pursuant to Part

of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates uses

and can radiate radio frequency energy and, if not installed and used in

accordance with instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

Quick Start Guide

Prestigio MultiPad

PMP5597D



Reorient or relocate the receiving antenna.



Increase the separation between the equipment and receiver.



Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.



Consult the dealer or an experienced radio(TV technician for

help.

To assure continued compliance, any changes or modifications not

expressly approved by the party responsible for compliance could void

the user's authority to operate this equipment. (Example - use only

shielded interface cables when connecting to computer or peripheral

devices).

USA: - This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause

undesired operation.

FCC Radiation Exposure Statement

: This equipment complies with

FCC RF radiation exposure' limits set forth for an uncontrolled

environment. This transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

Canada:

- Operation is subject to the following two conditions: (1)

this device may not cause interference, and (2) this device must accept

any interference, including interference that may cause undesired

operation of the device.

ELECTROSTATIC DISCHARGE (ESD)

Normal functioning of the product may be disturbed by ESD. If so, simply

reset the product to resume normal operation by following the

instruction manual. During file transmission, please handle with care and

operate in a static-free environment.

Quick Start Guide

Prestigio MultiPad

PMP5597D

AVOIDING HEARING DAMAGE

This product respects the current regulations for limiting the output

volume of consumer audio devices to a safe level. By listening to your

device with headphones or earbuds at high volumes, you run the risk of

permanent damage to your ears. Even if you get used to listening at high

volumes and it seems normal to you, you still risk the possibility of

damaging your hearing. Reduce the volume of your device to a

reasonable level to avoid permanent hearing damage. If you hear ringing

in your ears, reduce the volume or shut off your device. This device has

been tested with the supplied earphones. In order to preserve your

hearing, it is advised that you use only the following headphone models:

the earphones supplied with your device, or any other headphones that

respect the current regulations. Other types of headphones may produce

higher volume levels. So think twice before pumping up the volume,

you'll be glad when you are older.

ENVIRONMENTAL CONSIDERATIONS

Protection of the environment is an important concern to PRESTIGIO. In

order to put this concern into tangible actions, PRESTIGIO has

consciously included a set of methods that favor a respect for the

environment into the entire cycle of its products; from fabrication to

consumer usage, to final disposal.

Batteries:

If your product contains a detachable battery pack, you

should only dispose of it in a designated collection point for used

batteries.

The Product:

This product falls into the category of electric/electronic

equipment and contain substances that are potentially dangerous to the

environment and to human health. Therefore, you should not dispose of

the PRESTIGIO electronic device in a regular trash and should hand it

over to the applicable collection point for the recycling.

Please refer to PRESTIGIO International Limited Warranty Statement for

more details.

Other manuals for PMP5597D

Table of contents

Other Prestigio Tablet manuals

Prestigio

Prestigio MultiPad PMT3037 3G User manual

Prestigio

Prestigio MULTIPAD WIZE 3057 3G User manual

Prestigio

Prestigio MultiPad 4 Diamond 10.1 3G User manual

Prestigio

Prestigio WIZE 3518 4G User manual

Prestigio

Prestigio MULTIPAD WIZE 3027 User manual

Prestigio

Prestigio PMT3708-3G User manual

Prestigio

Prestigio MultiPad 7.0 Prime DUO User manual

Prestigio

Prestigio Q PRO User manual

Prestigio

Prestigio PMP5570C Operating manual

Prestigio

Prestigio MULTIPAD GRACE 4991 4G PMT4991-4G User manual

Prestigio

Prestigio MultiPad PMP5080CPRO User manual

Prestigio

Prestigio MULTIPAD GRACE 4891 4G User manual

Prestigio

Prestigio MULTIPAD WIZE 3108 3G User manual

Prestigio

Prestigio MultiPad 4 Quantum 9.7 User manual

Prestigio

Prestigio MultiPad 4 Quantum 9.7 User manual

Prestigio

Prestigio MultiPad PMP5785C3G QUAD User manual

Prestigio

Prestigio MULTIPAD WIZE 34084G User manual

Prestigio

Prestigio multipad pmp5080b Quick start guide

Prestigio

Prestigio PMP5780D_DUO User manual

Prestigio

Prestigio PMP7079D User manual

Prestigio

Prestigio MultiPad PMT5001 3G User manual

Prestigio

Prestigio PMP5588 Operating manual

Prestigio

Prestigio PMP7380D3G_Duo User manual

Prestigio

Prestigio MultiPad PMT3017 User manual

Popular Tablet manuals by other brands

Laser

Laser MID-1060 Quick operation guide

MUNBYN

MUNBYN IRT09J Easy setup guide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz quick start guide

Dell

Dell Latitude ST Setup and features information

Lenovo

Lenovo IdeaTab S6000L Hardware Maintenance Manual

Venturer

Venturer WT9L11 quick start guide

EDUGEAR

EDUGEAR UnoBook user guide

Philips

Philips PI3210G/58 user manual

ADLINK Technology

ADLINK Technology IMT-BT user manual

TwinMOS

TwinMOS TwinTAB-T102D1 user guide

Archos

Archos 9.7 xenon manual

Getac

Getac E100 user manual

HANNspree

HANNspree HANNspad SN70T3 quick start guide

Philips

Philips PI3105W2/55 user manual

LG LG-V935 user guide

Zeki

Zeki TBDB763B user guide

Ricoh

Ricoh eQuill user guide

DT Research

DT Research DT365CT Basic operation guide
