Safety Precautions

Do not subject the device to severe impact or drop it from heights.

Do not use the device in extreme hot or cold, dusty or damp conditions.

Do not expose it to direct sunlight.

Avoid using the device near strong magnetic fields.

Keep the device away from water and other liquids. In the event that

water or other liquids enter the device, power off the product

immediately and clean the device.

Do not use chemicals to clean the device in order to avoid corrosion.

Clean it with a dry cloth.

We are not responsible for damage or lost data caused by malfunction,

misuse, modification of the device or battery replacement.

Do not attempt to disassemble, repair or modify the product. This will

invalidate the warranty.

If the device will not be used for an extended period of time, please

charge the battery at least once per month to maintain battery life.

Charge the battery if:

a) The battery level icon displays as empty.

b) The device powers off automatically when restarted.

c) There is no response when pressing keys with keys unlocked and

battery full.

When the device is being formatted or transferring a file, do not

interrupt the connection. Otherwise, data may be corrupted of lost.

When the device is used as a portable HD, please use only per the

instructions.

Otherwise, permanent data loss could occur.

Please use and install data using the attachments/accessories

provided and only according to the manufacturer’s instruction.

Please refer to the information on the bottom of the device for

electrical and safety information before installing data or operating the

device.

To reduce the risk of fire or electric shock, do not expose this device to

rain or moisture. The device should not be exposed to dripping or

splashing. Never place objects filled with liquids, such as vases, on the

device.

There is danger of explosion if the battery is replaced incorrectly.

Replace only with the same or equivalent type.

The battery (battery or batteries or battery pack) should not be

exposed to excessive heat such as sunlight, fire or the like.

Please follow responsible procedures for battery disposal.

If the power adaptor is disconnected from the device, the device will

remain operable as long as the battery has sufficient charge.

The power adaptor is a CLASS II apparatus with double insulation, and

no external ground is provided.

Safety symbol explanation:

-The lightning flash with arrowhead symbol within an equilateral

triangle is intended to alert the user to the presence of

non-insulated ―dangerous voltage‖ within the product enclosure

that may be of sufficient magnitudes to constitute a risk of

electric shock.

-To reduce the risk of electric shock, do not remove the cover (or

back) as there are no user-serviceable parts inside. Refer

servicing to qualified personnel.

-The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance instructions in the literature accompanying the

device.

This product should not be disposed of with other household waste in

the EU. To prevent possible harm to the environment or human health

from uncontrolled waste disposal, recycle it responsibly to promote

the sustainable reuse of material resources. To dispose of your used

device, please use the return and collection systems available in your

area or contact the retailer where the product was purchased. They

can take this product for safe environmental recycling.

Do not leave the device on in a confined space such as a book case or

similar. The ventilation should not be impeded by covering the

ventilation openings with items such as newspaper, table-cloths,

curtains, etc.

No open flames, such as lighted candles, should be placed on the

device.

Use the device in moderate climates.

Listening Precautions

Do not listen to your earphones or headphones at a high volume.

Hearing expert advice against continuous extended play.

Excessive volume through earphones and headphones can cause

hearing loss.

If you experience a ringing in your ears, reduce volume or discontinue

use.

Do not use while operating a motorized vehicle. It may create a traffic

hazard and is illegal in many areas.

You should use extreme caution or temporarily discontinue use in

potentially hazardous situations created by obstructed hearing.

Even if your headphones or earphones are the open-air type designed

to let you hear outside sounds, don’t turn up the volume so high that

you can’t hear what’s around you.

Sound can be deceiving. Over time your hearing ―comfort level‖

adapts to higher volumes of sound. What sounds ―normal‖ can actually

be loud and harmful to your hearing. Guard against this by setting the

volume of your device at a safe level BEFORE your hearing adapts.

To establish a safe volume level:

a. Start your volume control at a low setting.

b. Slowly increase the sound until you can hear it comfortably and

clearly, and without distortion. Once you have established a

comfortable sound level, leave it there.

Table of Contents

Safety Precautions

Listening Precautions

1. Packing List

2. Device Overview

3. Charging

4. Power on/Power off

5. Inserting a Memory Card

6. Calibration

Home screen

7. Home screen bars

8. Prestigio home screen

9. Customizing the home screen

10. Pop-up menu

Touch Screen

eBook Reader

11. On-screen Google search bar

12. Keyboard settings

13. Memory cards and storage

Connecting to Internet

14. Connecting to WiFi

15. Browsing the Web

16. Using Web Links and History

17. Managing Bookmarks

Settings

18. Sound & Display settings

19. Language settings

Applications

20. Transferring content from PC

21. Using applications

22. Managing applications

23. Downloading and installing applications

24. Uninstalling applications

25. Downloading content from AppsLib

26. Email

Technical Specifications

Disclaimer

1. Packing List

1. Prestigio MultiPad

2. AC Adapter

3. Earphone

4. USB Cable

5. Quick Start Guide

6. Carrying Case

7. Warranty Card

2. Device Overview

Page Jump

Buttons

Turn to the previous/next page in eBook

Reading Mode

Press and hold the Previous Page Button to

return to Home page. Press and hold the Next

Page Button to return to previous page.

SD Card Slot

Insert SD card

Reset Button

Reset the device to default settings

Mini USB Port

USB connection

Earphone Jack

Earphones connection

DC Port

AC adapter connection

Power Button

Turn on/off the device; Suspend/Activate the

device.

3. Charging

Insert the AC connector to the DC port on the device and connect the

power adapter to the wall socket for charging.

Normally it takes approximately 3 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

4. Power on/Power off

Press and hold the Power Button to turn on the device. It will

automatically enter the Lock screen after the start-up screen:

To unlock the device touch and drag horizontally the Unlock button.

Press the Power Button once to enter sleep mode and press it again

to awake the device. The device will automatically enter the Lock

screen. To unlock it touch and drag horizontally the Unlock button.

Unlock button

Press and hold the Power Button, and then tap on Power

off/Standby to power off the device or to enter sleep mode.

5. Inserting a Memory Card

The device supports SD/SDHC cards.

To insert a SD card, place the card connector towards the device and

the card label towards the rear side of the device.

To remove the SD card, gently press the edge of the card to release

the safety lock and pull the card out of the slot.

To access the files on the memory card, select Explorer mode and

tap on SD Card.

6. Calibration

When using the device for the first time (or after erasing all user’s

personal data) the device will automatically performs the G-sensor

calibration.

At the Calibration screen place the device on the flat horizontal

surface and follow the on-screen instructions. If failed to do so you

may notice deviations of the screen image from the device position in

space later on. In this case it is recommended to calibrate the device

again by touching Settings > Touch panel calibration.

After successful calibration the device will enter the home screen.

Home screen

7. Home screen bars

Your device has the resistive screen. It is operated by touching the

screen surface with your finger.

Status bar

Widget

Buttons panel

Page scroll

Status bar

The status bar displays the home button, time, battery status, alarm,

WiFi as well as Return and Menu buttons.

Time and WiFi area

Displays the current time and the alarm symbol,

when Alarm is activated.

Connected to a WiFi network.

Battery status

Displays the battery power or charging progress.

Battery is full

Battery is low and must be recharged

Battery is extremely low and must be

recharged immediately

Battery is empty and must be recharged

immediately

Battery is charging

Return button

Return to the previous screen.

Menu button

Displays the current options.

Home Button

Touch the home button to return to the

home screen. Touch and hold the home button

to display recently opened items.

Table of contents

Other Prestigio Tablet manuals

Prestigio

Prestigio multipad User manual

Prestigio

Prestigio MultiPad PMP5080CPRO User manual

Prestigio

Prestigio PMP3970B_DUO Operating manual

Prestigio

Prestigio MultiPad PMP5070 User manual

Prestigio

Prestigio MULTIPAD GRACE 4991 4G PMT4991-4G User manual

Prestigio

Prestigio MultiPad PMT5011 3G User manual

Prestigio

Prestigio MultiPad PMT5001 3G User manual

Prestigio

Prestigio MultiPad PMP7070C3G User manual

Prestigio

Prestigio MULTIPAD WIZE 3777 3G User manual

Prestigio

Prestigio MULTIPAD PRO QUAD 8.0 3G PMP7380D3G_QUAD User manual

Prestigio

Prestigio MultiPad PMT3017 User manual

Prestigio

Prestigio PMP7079D User manual

Prestigio

Prestigio PMP7100D3G QUAD User manual

Prestigio

Prestigio PMT4348 User manual

Prestigio

Prestigio MultiPad 7.0 PRIME+ User manual

Prestigio

Prestigio MultiPad Visconte 3 User manual

Prestigio

Prestigio PMP7280C3G-Duo User manual

Prestigio

Prestigio MultiPad 4 Quantum User manual

Prestigio

Prestigio Multipad 4 Quantum 7.85 User manual

Prestigio

Prestigio MULTIPAD GRACE 4991 4G User manual

Prestigio

Prestigio PMP7170B3G DUO Operating manual

Prestigio

Prestigio PMP7380D3G_Duo User manual

Prestigio

Prestigio MultiPad Consul 7008 4G User manual

Prestigio

Prestigio MultiPad PMT3177 3G User manual

Popular Tablet manuals by other brands

Laser

Laser MID-1060 Quick operation guide

MUNBYN

MUNBYN IRT09J Easy setup guide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz quick start guide

Dell

Dell Latitude ST Setup and features information

Lenovo

Lenovo IdeaTab S6000L Hardware Maintenance Manual

Venturer

Venturer WT9L11 quick start guide

EDUGEAR

EDUGEAR UnoBook user guide

Philips

Philips PI3210G/58 user manual

ADLINK Technology

ADLINK Technology IMT-BT user manual

TwinMOS

TwinMOS TwinTAB-T102D1 user guide

Archos

Archos 9.7 xenon manual

Getac

Getac E100 user manual

HANNspree

HANNspree HANNspad SN70T3 quick start guide

Philips

Philips PI3105W2/55 user manual

LG LG-V935 user guide

Zeki

Zeki TBDB763B user guide

Ricoh

Ricoh eQuill user guide

DT Research

DT Research DT365CT Basic operation guide
