Prestigio GEOVISION 5000 User manual

GPS Personal Navigation

GEOVISION 5000

Quick Guide Version 1.0

GV5000 Navitel_QSG_V1.0.indd 1 2013/9/2 15:54:26

GV5000 Navitel_QSG_V1.0.indd 2 2013/9/2 15:54:26

Quick Start Guide

Prestigio GPS

GV5000

EN-1

Important Safety Instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol alerts you that important literature

concerning operation and maintenance has been

included with this product.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any

internal part of this product.

Caution

• Do not disassemble your device. It might cause electric shock.

Only PRESTIGIO certified technicians are qualified to Repair

your device. In calling upon nonqualified persons to repair

your product, you run the risk of damaging your device and

voiding your guaranty.

• Use only accessories that are PRESTIGIO branded or certified

by manufacturer.

• Power off and disconnect the power supply cable before

opening the unit.

Warning

Keep your product away from any sources of humidity. This can

seriously damage the device. Do not manipulate your device

with wet hands. Any damage done to the device due to its

contact with water voids your guaranty.

This product falls into the category of electric/electronic

equipment and contain substances that are potentially

dangerous to the environment and to human health.

Therefore, you should not dispose of the PRESTIGIO

electronic device in a regular trash and should hand it over to

the applicable collection point for the recycling.

As the Prestigio products are constantly updated and

improved, your device’s software and hardware may

have a slightly different appearance or modified

functionality than presented in this Quick Start Guide.

Prestigio hereby states that this GPS Navigator complies to

basic requirements and another relevant regulations given by

the EU directive 1999/5/EC. Full version of the declaration of

conformity is available on:

http://www.prestigio.com/compliance.

To prevent possible hearing damage, do not listen at

high volume levels for long periods.

GV5000 Navitel_QSG_V1.0.indd 1 2013/9/2 15:54:26

Quick Start Guide

Prestigio GPS

GV5000

EN-2

Using the mounting cradle

• Do not operate the device while driving.

• Please select an appropriate location on the

dashboard or windshield where the device will

not obstruct driver field of vision.

• Make sure that the device has a clear view of sky

to attain best GPS reception.

Please follow procedures below to operate mounting cradle:

1. Place device on the bracket with bottom positioned on the

appropriate socket.

2. Push on the top edge to securely install device onto the

cradle.

3. Lift the suction cup lever and press the suction cup at desired

location.

Open your package

• Prestigio GPS • Car Charger

• Mounting Cradle • USB Cable

• Stylus • CD-ROM

• Quick start guide • Warranty card

Your GPS Navigator at a glance

Touch

screen

Power

button

Headset jack

Memory

card slot

Mini USB port

Reset hole

Speaker

Stylus

GV5000 Navitel_QSG_V1.0.indd 2 2013/9/2 15:54:28

Quick Start Guide

Prestigio GPS

GV5000

EN-3

Please connect the car charger to vehicle 12V

accessory/cigarette socket after vehicle engine is

started to protect the device from sudden surges in

current.

Stylus

While the first time you turn on the GPS navigator, you are

asked to do calibration for the stylus. Thus, strokes or taps by

the stylus will be precisely displayed on the screen. (Or go to

Settings to do calibration).

Getting started

Press and hold the power key to power on your GPS.

Home screen

Your Home screen is the starting point to access all of the GPS

navigator’s features.

General operations

• Tap or to select your desired function on the Home

screen.

• Go to Settings, Tap or to go to previous or next

page.

• Tap to exit and return to your Home screen.

4. Press down the suction cup lever to secure the mounting

cradle on the surface.

5. Rotate the knob to adjust device to desired viewing angle.

To Dismount Device

1. Push the tap on top of the mounting cradle to release the

device.

2. Lift the suction cup lever to easily remove the suction cup

from windshield or dashboard.

Charging your GPS

Connect your GPS to the vehicle accessory/cigarette socket by

using the included USB cable and car charger.

GV5000 Navitel_QSG_V1.0.indd 3 2013/9/2 15:54:28

Quick Start Guide

Prestigio GPS

GV5000

EN-4

2 Compass Context menu opens by pressing this

button. In this menu switches the

orientation of the map («North up» -

lock icon is next to the compass, «Rotate

in accordance with the movement»

- route is next to the compass), the

type of card (Flat view «2D» and the

Panoramic view of the «3D») and the

skins («Night», «Day», «Auto»). When

driving the compass always points to the

North.

3 Information

panel

A sign of the upcoming maneuver. There

are various turns, distance to the next

maneuver in meters or kilometers, etc.

on a gray background. Clicking on the

sign stops the route guidance and more

route options.

4 Information

panel

The estimated total time in a way, the

total length of the route, time of arrival

at the final point of the route.

5 Route The active route.

6 GPS-cursor Your location indicator.

7 Menu Main menu opens by pressing this

button.

Start GPS navigation

1. Press and hold the power key to power on your GPS.

2. Tap or to select .

3. Tap the icon to start GPS navigation.

Program interface

910

116

No. Name Function

1 Sound Sound menu opens by pressing this

button.

GV5000 Navitel_QSG_V1.0.indd 4 2013/9/2 15:54:28

Quick Start Guide

Prestigio GPS

GV5000

EN-5

15 GPS GPS/GLONASS connection icon. If

the indicator is grey — receiver is

disabled, red — switched on, but the

connection is not established, yellow -

poor connection, green – connection

established. There is a number of the

satellites in the dot.

16 Route panel Allows you to see the entire route, your

location and traffic jams* on the route

directly on the Map page.

No. Name Function

17 «Save» Saves current marc on map as a

waypoint.

18 «Cursor» Shows the point menu.

8 Progress-

bar

Bar is filled in as you approach the place

of maneuver.

9 Traffic lane Displays the traffic lanes with valid

maneuvers at the next intersection.

10 Information

panel

Shows the name of the street you are

currently driving along.

Available only if GPS/GLONASS

connection is established. If there

is no street name, the direction will be

shown.

11 Scale

button

Zoom out.

12 Scale

button

Zoom in.

13 Speed limit

and camera

In excess of the established speed

displays the speed limit on that road

section.

If warning of the cameras turned on in

the settings, then when approaching the

camera distance to it displays.

14 Battery Icon shows the level of battery charge.

Press it to see the remaining memory.

GV5000 Navitel_QSG_V1.0.indd 5 2013/9/2 15:54:28

Quick Start Guide

Prestigio GPS

GV5000

EN-6

23 «Set start» Mark becomes the middle point of the

route.

24 «Set finish» Mark on the map becomes the end of

the route. And previous end of the route

becomes the middle point.

25 Map Back to map.

Autorouting

Route to the objects

To create a route to the object with known address, press the

«Menu» button at the lower left corner of the screen [1]. Then

select «Find», «By address» [2]. Press the «Select country»

button and enter its name [4]. To minimize the keyboard, press

the icon at the right top of the screen. Select the required

country[5]. Menus «Select city», «Select street» and «Select

building» will become active [6]. After choosing the required

information press «Go!» to create a route. The route will

be shown on the map [8]. You can follow this route or start

simulation by pressing the «Demo route» button.

[1] [2] [3]

19 Mark on the

map

You can set the mark by taping on

the map. You can save this mark as a

waypoint, add it to the route or see

object’s characteristics the mark was set

on.

20 Track

record

Track record. Red dot means that the

track is recording, grey dot means that

the record stopped.

No. Name Function

21 «Go!» Marks the current position on the map

as the end of the route

22 «Route

through»

Mark becomes the start point on the

route. You should turn off your GPS/

GLONASS receiver.

GV5000 Navitel_QSG_V1.0.indd 6 2013/9/2 15:54:29

Quick Start Guide

Prestigio GPS

GV5000

EN-7

route by pressing «Cursor» > «Go!». If you didn’t turn off your

GPS receiver, the system will ask you to do it[3]. The start point

will be marked by green flag[4]. Then find the finish point,

tap on map and press «Cursor» > «Go!»[5]. The route will be

created from point to point.

[1] [2] [3]

[4] [5] [6]

Note:

For more detailed information regarding the functionality of

Navitel software, please, refer to the complete user manual on

CD, or to www.prestigio.com.

[4] [5] [6]

[7] [8] [9]

Route to the selected point on the map.

You can set the route to any point on the map. This point will

be the end of the route, your current position will become the

start of the route. Create a mark on the route by pressing any

place on the map[1]. Press the «Cursor», then «Go!»[2]. The

route is created[3].

[1] [2] [3]

Route from point to point.

If you want to create a route from point to point you should

create a point on the map[1]. Then set this button as a start

GV5000 Navitel_QSG_V1.0.indd 7 2013/9/2 15:54:30

Quick Start Guide

Prestigio GPS

GV5000

EN-8

Operation Relative

Humidity 45% ~ 80% Non-Condensed

Storage Relative

Humidity 30% ~ 90% Non-Condensed

Technical Specifications

Item Specification

GPS Receiver MT3328

Processor MT3351C ARM-11 CORE , 468MHz

RAM 128MB DDR3

Display 5” TFT touch LCD

Resolution 480 x 272 pixels

Storage capacity 4 GB flash memory, Memory card slot

supports micro SDHC card up to 8 GB

Interfaces USB 2.0, Micro SD (micro SDHC

compatible)

Battery 850 mAh Li-Polymer battery

Dimensions 131.8 x 92 x 10.3mm (L x W x H)

Weight 160 g

Storage

Temperature -10°C ~ +60°C

Operation

Temperature 0°C ~ +50°C

GV5000 Navitel_QSG_V1.0.indd 8 2013/9/2 15:54:30

Other manuals for GEOVISION 5000

Table of contents

Languages:

Other Prestigio GPS manuals

Prestigio

Prestigio GeoVision 5500 User manual

Prestigio

Prestigio GV7059 User manual

Prestigio

Prestigio 4050 User manual

Prestigio

Prestigio GEOVISION 5055 User manual

Prestigio

Prestigio GV5055 User manual

Prestigio

Prestigio Geovision 5330 BTFMTV User manual

Prestigio

Prestigio GeoVision 5500 User manual

Prestigio

Prestigio GeoVision 7790 User manual

Prestigio

Prestigio Qstarz BT-Q816 User manual

Prestigio

Prestigio GV4300 User manual

Prestigio

Prestigio GeoVision 5850HDDVR User manual

Prestigio

Prestigio GV4500 User manual

Prestigio

Prestigio GeoVision 5800BTHDDVR User manual

Prestigio

Prestigio GV7777 User manual

Prestigio

Prestigio GeoVision 4700-5700 User manual

Prestigio

Prestigio GeoVision 4500 User manual

Prestigio

Prestigio GeoVision 5055 iGO User manual

Prestigio

Prestigio GV5050 User manual

Prestigio

Prestigio GV4700BT User manual

Prestigio

Prestigio RoadScout 4150 User manual

Prestigio

Prestigio GeoVision 7790 User manual

Prestigio

Prestigio GeoVision 4466 User manual

Prestigio

Prestigio Geovision Tour 3 Sygic User manual

Prestigio

Prestigio GEOVISION 5055 User manual

Popular GPS manuals by other brands

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Operating instruction

Garmin

Garmin SOUNDER 125 Owner's manual & reference

Garmin

Garmin DEZL 580 owner's manual

Jigabot

Jigabot EX quick start guide

Pointer

Pointer Cellocator CelloTrack XT LTE overview

Queclink

Queclink GV55LITE user manual

Voxson

Voxson Voxtrack GPS500 Quick user guide

Garmin

Garmin ECHOMAP PLUS owner's manual

Starcom Systems

Starcom Systems Kylos Compact user guide

Garmin

Garmin 15 H Series Technical specifications

Cobra

Cobra Marine MC 600Ci owner's manual

Cellocator

Cellocator CelloTrack T installation guide

Enfora

Enfora Mini-MT GSM2228UG001 user guide

Magellan

Magellan eXplorist 100 Reference manual

LTE

LTE G50B user manual

Garmin

Garmin DEZL OTR500 owner's manual

SkyGolf

SkyGolf SkyCaddie SG1 user guide
