PRAIM PR165 User’s Manual
Documentnumber: 0016001018
Eighth Edition: November 1997
ThisdocumentwasproducedbyPRAIM
Under no circumstances will PRAIM (hereafter called PRAIM) be liable for any
damages, including incidental or consequential damages, expenses, lost profits or other
damagesarisingoutoftheuseoforinabilitytousetheproduct.Theinformationcontained
inthismanualissubjecttochangeatanytimewithoutnotice.PRAIMshallnotbeliablefor
technical or editorial omissions made herein; nor for incidental or consequential damages
resultingfromthefurnishing,performanceoruseofthismaterial.Referencesinthismanual
to PRAIM products, programs and services does not imply that PRAIM intends to make
theseavailableinallcountriesinwhichthePRAIM ismarketed.Referencesinthismanual
to third party products, programs or services does not convey a commitment of any kind
from PRAIM, nor does it imply that PRAIM intends to make these available.
Trademarks and registered trademarks occurring in this publication are the properties of their
respectiveowners.
TheinformationdisclosedinthispublicationisthepropertyofPRAIMandisprotectedbycopyright.
Allrightsarereserved.Nopartofthismanualmaybereproducedinanywayorbyanymeanswithout
thepriorwrittenconsentfromPRAIM.
© 1997 PRAIM
ThisproductcomplieswiththefollowingprotectionrequirementsofECCouncil
directives:
· 89/336/EEC May 3th 1989 and subsequent changes;
The symbol indicates that the product,since January 1st 1996,is in
conformance with
the followingharmonicrules:
· EN 55022 Limits and methods of measurements of radio
interference characteristics of Information Technology Equipment;
· EN 50082-1 Electromagnetic Compatibility - Generic Immunity
Standard - Part 1: Residential, commercial and light industry;
Tofollowingconditionsmaynegatecompliancewiththeaboverules:
·Wrong power supply.
·Wrong use and installation or any operation not indicated by
the user's manual.
·
Componentsubstitutionby unauthorized personnel or the use of
unauthorizedparts.
·
The use of the product with devices not having the symbol.
Certifications
FCC Rules
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
1PRAIM PR165
Chapter 1
Introduction
About this publication
Thispublication describesthe PRAIMPR165 printerinterface. Itis written
forusersas aguideforinstallationandconfiguration.As such,itisassumed
that the reader is familiar with the general terminology used in the field of
IBM systems.
PR165 Twinax Interface
The PRAIM PR165 is an external interface that connects PC compatible
parallel or serial printers to either IBM Systems S/34, S/36, S/38, AS/400
ortoIBMRemoteControlUnits5251/12,5294,5394,5494andcompatibles.
PRAIM PR1652
PR165 Interface versions
PRAIM PR165 is available in four different models:
With parallel Centronics connector:
• PR 165E-PAR for printers with up to 600 LPM (Lines Per Minute)
or 16 PPM (Pages Per Minute) printing speed
With built-in PC-Sharing feature:
• PR 165E-SHA for printers with up to 600 LPM (Lines Per Minute)
or 16 PPM (Pages Per Minute) printing speed
• PR 165S-SHA for printers with up to 2500 LPM (Lines Per Minute)
or 50 PPM (Pages Per Minute) printing speed
With serial connector:
• PR 165E-SER for printers with up to 600 LPM (Lines Per Minute)
or 16 PPM (Pages Per Minute) printing speed
Resident Barcode and Large Character (BCGC) capabilities are standard
and available on all models.
The following table describes the characteristics of each PRAIM PR165
model:
3PRAIM PR165
General characteristics of PRAIM PR165 Interfaces
NOTE The information contained in this manual applies to all
versions until otherwise noted.
MAX
PRINTER
SPEED
600 LPM /
16 PPM
MAX
PRINTER
SPEED
2500 LPM /
50 PPM
PC-SHARING SERIAL
CONNECTION BCGC
FUNCTION
PR 165E-PAR * *
PR 165E-SHA * * *
PR 165S-SHA * * *
PR 165E-SER * * *
PRAIM PR1654
PR165E-PAR
The figure below shows PR165E-PAR interface.
This product has a standard Centronics connector.
WARNING : PR165E-PAR doesn't support PC-Sharing optional
device.
Centronics Connector
PR165E-PAR Interface
5PRAIM PR165
PR165E-SHA / PR165S-SHA
The figure below shows PR165E-SHA and PR165S-SHA interfaces.
These interfaces have built-in PC-Sharing feature that allows the printer
to be shared between host and a Personal Computer.
The PC-Sharing option is explained later in this publication.
PC-Sharing device
PR165E-SHA Interface or
PR165S-SHA Interface
PRAIM PR1656
PR165E-SER
The figure below shows PR165E-SER Interface.
This product has a serial connector that allows the connection with the
serial printer.
PR165E-SER Interface
Serial Connector
