Power4Patriots Copper User manual
COPPER
Solar Water Heater–Copper Version
Instruction Manual
NOTICE
This is NOT a free book. You may NOT forward this book to anyone else. You do NOT have resale rights for this book. We will
take aggressive legal action against anyone violating these terms. If you have purchased this book from anywhere other than the main
product website, including eBay, please inform us right away.
2014© Copyright 1See
Power4Patriots.com www.Power4Patriots.com/shop
Legal Disclaimer
The authors and publishers both disclaim liability regarding any loss or risk incurred as a direct, or indirect, consequence of the
application and usage of any of the contents within this Do It Yourself (DIY) instructional material.
Copyright
Those who have received or purchased the DIY instruction manual are neither authorized nor permitted to transmit copies of this
file to anyone without written permission. Giving away copies to people who haven’t paid for them is illegal under international
copyright laws and will submit you to possible legal action. Therefore, the utilization of this file is limited to personal use only.
Power4Patriots.com Terms & Disclaimer
By using, viewing, and interacting with the DIY guide or the Power4Patriots.com website, you agree to all terms of engagement,
thus assuming complete responsibility for your own actions. The authors and publishers will not be held liable or claim accountability
for any loss or injuries. Use, view, and interact with these resources at your own risk.
All products from Power4Patriots.com and its related companies are strictly for informational purposes only. While all attempts have
been made to verify the accuracy of information provided on our website and within the publications, neither the authors nor the
publishers are responsible for assuming liability for possible inaccuracies.
The authors and publishers disclaim any responsibility for the inaccuracy of the content, including but not limited to errors or
omissions. Loss of property, injury to self or others, and even death could occur as a direct or indirect consequence of the use and
application of any content found herein.
Working on home improvement projects and with renewable energy sources is dangerous. ince you are dealing with electricity, high
roof tops or towers, and numerous other unknown conditions, seek expert opinions and help where necessary. The authors and
publishers assume that, while carrying out your DIY project, you are aware of all the risks and possible damages associated with
home improvements and renewable energy.
Check with your town, city, state, province, county or country for applicable laws about home improvements and alterations. Often,
it is necessary to obtain local government permits and licenses to prevent legal implications. We also recommend that you call your
local electrician, and other professionals, to assist in your DIY projects. Failure to do so could cause injury or death - you are acting
at your own risk.
Before performing any home improvement or renewable energy project you should first check with your insurance carrier,
homeowners association or any other persons or associations that may need to approve such work. Insurance coverage and premiums
may be affected by home alterations and so you need to check with your insurance agent first. All Power4Patriots.com information
is intended for adults above the age of 18 years only.
By choosing to use the information made available by Power4Patriots.com or within any of our publications, you agree to indemnify,
defend, and hold harmless the authors, publishers, and any other related companies from all claims (whether valid or invalid),
judgments, suits, proceedings, losses, damages, and costs or expenses of any nature whatsoever that result from the use or misuse
of any information provided.
The information provided may need to be downloaded using third party software, such as Acrobat or Flash Player. It’s the user’s
responsibility to install the software necessary to view such information. Any downloads, whether purchased or given for free from
our website, related websites, or hosting systems, are done at the user’s own risk. No warranty is given that websites are free of
corrupting computer codes, viruses or worms.
If you are a minor, you can use this service only with permission and guidance from your parents or guardians. Children are not
eligible to use our services unsupervised. Furthermore, Power4Patriots.com specifically denies access to any individual covered by
the Child Online Privacy Act (COPA) of 1998.
Remember…Safety First!
2014© Copyright 2See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
Solar Water Heater – Copper Version Materials
K2 long aluminum profile
K2 short aluminum profile
Kcorrugated tin sheets to fit long x short frame
Kmineral wool insulation to fit long x short frame
K3/16 inch popping rivets
K24 copper Ts 1.25 inch to 1 inch (3/4 will work, too)
K24 pieces 1.25 inch diameter copper pipes cut 2.2 inches
K2 copper endcaps, 1.25 inch
K12 copper pipes 6 feet
K4 6 inch copper pipes (1 inch or 3/4 inch, depending on Ts)
K2 short hoses
K1 sheet copper (a bit larger than long x short frame)
K1 can heat-resistant black spray paint
K1 piece 6mm glass (to fit long x short frame)
K20 aluminum clamps
K6 corner support pieces
K1 tube heat resistant silicone
K1 piece Tee 3/4 inch
K1 valve 3/4 inch
K1 water controller
K1 water tank
K1 expansion water tank
K1 ventilation valve
K1 temperature sensor
Ktemperature sensor cable
Kcopper pipe and connectors to fit your space
KPVC pipe and connectors to fit your space
2014© Copyright 3See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
Introduction
This manual is a walk-through construction of a olar Water Heater that uses a copper collector.
The solar hot water system we will build includes a tank to store heated water for distribution
throughout our house.
2014© Copyright 4See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
When you open a hot water faucet, hot water is drawn out of the tank and is replaced by cold water
from your water source. Our tank has a copper heat exchanger inside (think 100 feet of copper
tubing loosely coiled inside the tank).
Water is heated by the sun in a solar collector and circulated through this coil to heat the water
around it inside the tank.
Just as “hot air rises,” so does hot water, which means that the hottest water is always at the top of
the tank and the top of the collector. Hot water is drawn from the top of the collector and piped to
the top of the heat exchanger in the tank. As the hot water passes through the coil, it gives up its
heat energy to the surrounding water in the tank, exits at the bottom and is returned to the bottom of the
collector. The tank we will be using also has an electric heating element for days without sun.
2014© Copyright 5See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
We will need a pump – that you can power with solar panels – to circulate water in the solar collector
through the heat exchanger in the tank, and you need a controller to tell the pump when to operate,
so that it doesn’t run all the time. The controller senses the difference in temperature between the
water stored in our tank and the temperature of the water in the collector, and when the difference
is great enough, the controller turns on the pump to circulate water through the system. You can
adjust the controller to optimize your system operation. We found a unit that combines a pump and
a controller, so we will be working with one box instead of two.
Our solar collector consists of an insulated aluminum frame – which we’re going to build – to hold
a system of copper tubing, which is the guts of our collector and which we are also going to build.
The copper tubing and everything else inside the frame is painted with a heat resistant flat black
paint to maximize heat absorption. The whole thing will be covered with glass.
We have an air vent on the output side of the collector to allow any air that may build up in our
system to escape, so that our system is always fully charged with water.
2014© Copyright 6See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
Your components do not have to be this close together – we’re showing them this way simply by
way of illustration – but the greater the distance between your tank and your collector, the more you
will have to contend with potential heat loss.
2014© Copyright 7See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
2014© Copyright 8See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
Tools Needed
Before we get started, let’s take a look at the tools we’ll need to complete the project.
The first tool is the PVC tube cutter.
You will also need a tape measure,
An angle grinder for cutting the
aluminum frame,
A Phillips screwdriver and a flathead
screwdriver.
Other tools we’ll need are a metal file
for smoothing the edges of the frame,
A hammer
And a pair of pliers with a diagonal cutting
edge,
A riveting tool, which will be used to put the frame together. This tool needs to be able to
cut 3/16 inch rivets, so make sure it’s a heavy-duty one.
A pipe wrench, which will come in handy when
tightening the pipe joints,
And a utility knife or office knife.
The pipe-cutter will be used to make a
clean cut on the copper tubing.
You will also need a marker.
The blowtorch will be used to solder the joints in our copper
piping.
2014© Copyright 9See
Power4Patriots.com www.Power4Patriots.com/shop
Power4Patriots Solar Water Heater – Copper
