Power Fist 6 User manual
User Manual
V 3.03 8254187
Please read and understand all instructions before use. Retain this manual for future reference.
6,500W Remote
Start Generator
2 For technical questions call: 1-800-665-8685
V 3.03 8254187
6,500W Remote
Start Generator
SPECIFICATIONS
Max. Output 6,500 watts
Continuous Output 5,500 watts
Receptacles Four 120V
One 120V/240V Twist Lock
One 12V
Run Time @ 50% Load 11 hours
Hour Meter No
Tank Capacity 25 litres (6.6 gallons)
Fuel Type Gasoline
Engine Displacement 389 cubic centimeters
Operating Noise 74 decibels
Tire Size 10 inches
Low Oil Shutdown Yes
Battery Included No
GFCI Protection No
Electric Start Yes
Recoil Start Yes
Remote Included Yes
Features Heavy duty roll cage with 10 in. wheels
IMPORTANT SAFETY PRECAUTIONS
WARNING! Read and understand all instructions before using this generator. The operator must
follow basic precautions to reduce the risk of personal injury and/or damage to the equipment.
Before allowing anyone else to use this generator, make sure that they are aware of all
safety information.
6,500W Remote Start Generator
Visit www.princessauto.com for more information 3
8254187 V 3.03
WARNING! The warnings, cautions, and instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. Common sense and caution are factors
that cannot be built into this product, but must be supplied by the operator.
NOTE: Keep this manual for the safety warnings, precautions, operating, inspection, and
maintenance instructions.
WORK AREA
1. Operate in a safe work environment. Keep your work area clean and well lit.
2. Do not use in the presence of flammable gases or liquids.
a. Do not use pressurized starting fluids with the generator - the vapors they create
are flammable.
3. Keep anyone not wearing appropriate safety equipment away from the work area.
PERSONAL SAFETY
CAUTION: Wear protective equipment approved by the Canadian Standards Association (CSA) or the
American National Standards Institute (ANSI) when using the tool.
1. Head Protection
a. Always wear impact-resistant safety goggles that provide both front and side protection.
b. Wear earplugs or hearing protector earmuffs if the engine or the work environment
is noisy.
2. Gloves
a. Wear gloves that provide protection from the thermal (heat) levels generated by
the generator.
3. Protective Clothing
a. Wear protective clothing designed for the work environment and the engine.
4. Foot Protection:
a. Wear steel-toed footwear or steel toecaps to prevent injury from falling objects.
b. Non-skid footwear is recommended for maintaining footing and balance.
5. Control the engine, personal movement, and the work environment to avoid personal injury
or damage to the generator.
a. Keep articles of clothing, jewelry, hair, etc., away from moving parts to avoid
entanglement with the engine. Traumatic amputation or severe laceration could result.
b. Do not operate any tool or machine when tired or under the influence of drugs, alcohol,
or medications.
c. Do not overreach when operating the engine. Proper footing and balance enables better
control of equipment in unexpected situations.
SPECIFIC SAFETY PRECAUTIONS
WARNING! This generator produces enough electric power to cause a serious shock or electrocution
if misused.
1. All users must understand the operation of all controls and learn how to quickly stop
the generator in case of emergency. Understand the use of all generator controls, output
receptacles, and connections.
6,500W Remote Start Generator
4 For technical questions call: 1-800-665-8685
V 3.03 8254187
2. If the generator is stored outdoors and is unprotected from the weather, check all of the
electrical components on the control panel before each use. Moisture or ice can cause a
malfunction or short circuit in the electrical components, which could result in electrocution.
3. Do not connect to a building’s electrical system unless a qualified electrician has installed an
isolation switch.
4. All maintenance and installation must be performed by a qualified service professional and
should meet the following standards:
a. Article 551 of the National Electrical Code, 70-1990 ANSVNFPA
b. The standard regarding recreational vehicles, 501 C-1990 ANSVNFPA
5. The engine and exhaust become very hot during operation. Severe thermal burns can occur
on contact, especially with the muffler.
a. Keep the generator at least 3 feet (1 meter) away from buildings and other equipment
during operation.
b. Remove accumulated debris from the muffler and cylinder area. Combustible debris,
such as leaves, grass, brush, etc., can catch fire if they come in contact with a
hot engine.
c. Do not place anything on the generator while it is running.
d. Allow the muffler, engine cylinder, and fins to cool before allowing the unit to touch
grass-covered or brush-covered unimproved land.
e. Gasoline is extremely flammable and is explosive under certain conditions. Do not
smoke or allow flames or sparks where the generator is refueled or where gasoline is
stored. Refuel in a well-ventilated area with the engine stopped.
f. Fuel vapours are extremely flammable and may ignite after the engine has started. Make
sure that any spilled fuel has been wiped up before starting the generator.
6. Do not let children operate the generator, and do not allow anyone who is unfamiliar with the
generator to operate it without proper supervision.
7. Never remove the warning labels. Generators provide safe and dependable service if operated
according to instructions. Read and understand the owner’s manual before operating your
generator. You can help prevent accidents by being familiar.
NOTE: Safety labels warn you of potential hazards that can cause serious injury. Read them carefully.
Contact Princess Auto if a label comes off or becomes hard to read.
CARBON MONOXIDE POISONING
WARNING! Engine exhaust contains carbon monoxide gas - never start or run this engine indoors.
Opening windows and doors is not enough to ventilate the area.
Carbon monoxide is a colourless and odourless gas that is difficult to detect. Carbon monoxide
poisoning results from inhalation of the gas and may be lethal if left untreated. Evacuate all people to
an area with clean air and seek immediate medical attention for any person experiencing the
following symptoms:
1. Headache
2. Confusion
3. Shortness of breath
4. Weakness
5. Fatigue
6. Dizziness
6,500W Remote Start Generator
Visit www.princessauto.com for more information 5
8254187 V 3.03
7. Unstable gait (stumbling around)
8. Nausea & vomiting
9. Unconsciousness
10. Flu-like symptoms
NOTE: As a precaution, install a carbon monoxide detector in a work area that has
gasoline-powered equipment.
ELECTRICAL SAFETY
1. Disconnect the tool from the power supply when not in use, and before cleaning, servicing,
or changing any parts or accessories.
2. Protect yourself against electrical shocks when working on electric equipment. Avoid body
contact with grounded surfaces such as pipes, radiators, cooking stoves, and refrigerators.
There is an increased chance of electrical shock if your body is grounded.
3. Double insulated tools are equipped with a polarized plug (one blade is wider than the other).
This plug will fit in a polarized outlet only one way. If the plug does not fully fit in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician to install a polarized
outlet. Do not change the plug in any way. Double insulation eliminates the need for a three-
wire grounded power cord and grounded power supply system.
4. Grounded tools must be plugged into an outlet that is properly installed and grounded in
accordance with all codes and ordinances. Never remove the grounding prong or modify the
plug in any way. Do not use any adapter plugs. Check with a qualified electrician if you are in
doubt about an outlet being properly grounded. If the tool should electronically malfunction
or break down, grounding provides a low resistance path to carry electricity away from
the user.
5. Do not abuse the cord. Never use the cord to carry tools or to pull the plug from an outlet.
Keep the cord away from heat, oil, sharp edges, or moving parts. Do not operate this tool if
the power cord is frayed or damaged. Immediately replace damaged cords. Damaged cords
increase the risk of electrical shock. Do not modify the plug in any way.
6. When operating a power tool outside, use an outdoor extension cord marked “W-A” or
“W”. These cords are rated for outdoor use and reduce the risk of electrical shock. Use in
conjunction with a Ground Fault Circuit Interrupter (GFCI). If operating a power tool in a
damp location is unavoidable, the use of a GFCI reduces the risk of electrical shock. It is
recommended that the GFCI should have a rated residual current of 30 mA or less.
7. Avoid using an unnecessarily long extension cord. Choose a cord that is appropriate for the
situation. A cord that is too long and is running across the floor can be more dangerous
than helpful. Using a cord that is too long or too thin could damage the tool. Unroll the cord
completely to prevent it from overheating.
8. Place the electrical cord in a position that prevents it from coming into contact with the tool
and from getting caught by the work piece. The cord should always stay behind the tool.
6,500W Remote Start Generator
6 For technical questions call: 1-800-665-8685
V 3.03 8254187
BATTERY PRECAUTIONS
1. Keep the battery away from fire and sparks. Reinforce the grounding and down-lead.
2. The battery contains strong acid. Avoid contact with skin and eyes. If contact occurs,
immediately wash skin or flush eyes with water. If serious injury occurs, seek
medical attention.
3. To prevent damage, avoid spilling gasoline, oil, or organic material on the battery.
USE AND CARE
1. This generator was designed for a specific function. Do not modify or alter this generator or
use it in a way for which it was not designed.
a. Do not tamper with the governor spring, the links, or any other parts in an attempt
to increase the engine’s speed.
2. Maintain the engine with care (see Maintenance).
3. Remove adjusting keys and wrenches from the engine before operation. A wrench or key that
is left attached to a rotating part of the tool increases the risk of personal injury.
UNPACKING
1. Carefully remove the parts and accessories from the packaging. Retain packaging material
until you have carefully inspected and satisfactorily installed or operated the generator.
2. Inspect the engine carefully to make sure that the generator was not damaged
during shipping.
WARNING! If any parts are missing, do not operate the engine until the missing parts are replaced.
Failure to do so could result in serious personal injury.
OPERATION
WHEEL INSTALLATION
Attach the four wheels to the generator using the axles and
lock-nuts provided provided (see Fig. 1).
NOTE: Before starting the generator, apply the
wheel-locking mechanism to prevent movement
during operation.
Fig. 1
A. Lock nut
B. U-bracket
C. Axle
D. Wheel
E. Pin
6,500W Remote Start Generator
Visit www.princessauto.com for more information 7
8254187 V 3.03
INSTALLATION OF THE BATTERY
1. Place the battery in the battery compartment.
NOTE: The poles face the inside of the compartment.
2. Hang one end of the tie rod in the holes on both sides of the
battery, and insert the other end through the holes of the
fixing board (see Fig. 2).
3. Keep the fixing board on the side opposite from the poles.
4. Secure the tie rod with an M6 nut.
5. Connect the positive anode wire to the anode pole, and cover with the red rubber lagging
on the anode pole. Connect the negative wire to the negative pole, and cover with the black
rubber lagging on the pole.
BATTERY
1. Recommended battery: 12V-9AH
2. Correctly connect the anode and the negative pole when installing the battery.
3. Fill the battery with electrolyte before use.
4. Inspect the electrolyte level each month. If the level is low, refill the battery using distilled or
pure water only. Refill the battery until the fluid level is between the upper level mark and the
lower level mark.
CAUTION: Do not mix electrolyte and tap water.
5. Clean the battery if electrolyte is spilled on the generator in order to prevent corrosion of the
grounding and negative leads. Wash with water if any signs of corrosion are visible.
FUEL VALVE LEVER
The fuel valve is located between the fuel tank and the carburetor.
When the valve lever is in the ON position, fuel is allowed to flow
from the fuel tank to the carburetor. Be sure to return the fuel valve
lever to the OFF position after stopping the engine (see Fig. 3).
OIL ALERT SYSTEM
The oil alert system is designed to prevent engine damage caused
by an insufficient amount of oil in the crankcase. Before the oil
level in the crankcase falls below a safe limit, the oil alert system
automatically stops the engine (the engine switch will remain in the
I (ON) position). Check the oil level before each use. If the engine stops or
does not restart, check the engine oil level (see Engine Oil in the
Pre-Operation section) before troubleshooting other areas.
CIRCUIT BREAKER
The AC circuit breaker will switch OFF automatically if there is a short
circuit or a significant overload of the generator at the receptacle. If the
AC circuit breaker is automatically switched OFF, check that the appliance
is working properly and does not exceed the rated load capacity of the AC
circuit before once again switching ON the circuit breaker. The circuit breaker may be used to switch
the generator AC power ON or OFF (see Fig. 4).
Fig. 3
Fig. 4
6,500W Remote Start Generator
8 For technical questions call: 1-800-665-8685
V 3.03 8254187
REMOTE START
Minimum starting voltage: 6.2V
1. Aim the remote at the gasoline engine.
NOTE: You must be within 50 meters of the engine.
2. The generator can be turned off remotely whether started manually or remotely.
CAUTION: Do not attempt to remote start the unit while it is running.
3. When using the remote to turn off the generator, it could take the engine up to eight seconds
to completely shut off.
4. Remote starting takes about seven seconds.
GENERATOR USE
WIRING
6,500W Remote Start Generator
Visit www.princessauto.com for more information 9
8254187 V 3.03
CONNECTIONS TO BUILDING ELECTRICAL SYSTEM
A qualified electrician must make the connections for standby power to a building’s electrical system.
The connection must isolate the generator power from utility power, and must comply with all
applicable laws and electrical codes. A transfer switch, which isolates generator power from utility
power, is available through an authorized service professional.
WARNING! Improper connections to a building’s electrical system can allow electrical current from
the generator to back feed into the utility lines. Such back feed may electrocute utility company
workers or others who contact the lines during a power outage, and the generator may explode,
burn, or cause fires when utility power is restored. Consult the utility company or a
qualified electrician.
GROUND TERMINAL
The generator ground terminal is connected to the frame of the generator, to the non-current-carrying
metal parts of the generator, and to the ground terminals of each receptacle. Before using the ground
terminal, consult a qualified electrician, electrical inspector, or local agency having jurisdiction over
local codes and ordinances that apply to the intended use of the generator.
6,500W Remote Start Generator
10 For technical questions call: 1-800-665-8685
V 3.03 8254187
AC APPLICATIONS
Before connecting an appliance or power cord to the generator:
1. Make sure that the appliance is in good working order. Faulty appliances or power cords can
create the potential for electrical shocks.
2. If an appliance operates abnormally, becomes sluggish, or stops suddenly, immediately turn
off the appliance. Disconnect the appliance and determine whether the problem is with the
appliance, or if the rated load capacity of the generator has been exceeded.
3. Make sure that the electrical rating of the tool or appliance does not exceed the rating of the
generator. Never exceed the maximum power rating of the generator. Do not operate a tool or
an appliance at the maximum-power rating for more than 30 minutes at a time.
WARNING! Substantial overloading will open the circuit breaker. Exceeding the maximum-power
time limit or slightly overloading the generator may not switch OFF the circuit breaker, but it may
shorten the service life of your generator.
AC OPERATION
1. Start the engine (see the Starting the Engine section).
2. Switch ON the AC circuit breaker.
3. Plug in the appliance (see Fig. 5).
NOTE: Be sure that all appliances are in good working order
before connecting them to the generator.
a. If an appliance operates abnormally, becomes sluggish, or
stops suddenly, immediately turn off the engine. Disconnect
the appliance and examine it for signs of malfunction.
b. Most motorized appliances require more than their rated wattage during start-up. Do
not exceed the current limit specified for any one receptacle. If an overloaded circuit
causes the AC circuit breaker to switch OFF, reduce the electrical load on the circuit, wait
a few minutes, and reset the circuit breaker.
PRE-OPERATION CHECK
ENGINE OIL
NOTE: Engine oil is a major factor affecting engine
performance and service life. Non-detergent and 2-stroke
engine oils will damage the engine and are not recommended.
1. Check the oil level - BEFORE EACH USE - with the
generator on a flat, level surface and with the
engine stopped.
2. Use 4-stroke motor oil that meets or exceeds the
requirements for API service classification SJ.
NOTE: Always check the API SERVICE label on
the oil container to be sure it includes the letters “SJ”.
3. SAE 10W-30 is recommended for general, all-temperature use. Other viscosities shown on
the chart may be used when the average temperature in your area is within the indicated
range (see Fig. 6).
Fig. 5
Fig. 6
This manual suits for next models
1
Table of contents
Languages:
Other Power Fist Portable Generator manuals
