Polygroup TGA0M4865L00 User manual

Fig. B - Tree and Light Assembly

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®!

This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

1. Pull apart the legs of the stand so that they are

snapped into an x-shape, place the tree stand

on a level surface.

2. When inserting the bottom section of the tree

into the assembled stand, insert and turn the

eyebolts into the stand and tighten until the

tree pole is firmly secured.

To close the stand, remove the eyebolts, press

the metal button and fold the legs together.

Fig. A - Tree Stand Assembly Eye Bolt

Click

Eye Bolt

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

NEED HELP?

Foot Pedal

on/off Switch

Section 3

Tree top

Section 2

Section 1

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

Insert Green

Label Extension

Cord into Adapter

Adapter

To Be Plugged

Into Wall

Outlet

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120V, 60Hz 0.38A

Output: 28V DC 0.643A

3. Each tree section is numbered with a tag.Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into the

assembled stand. Make sure the pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.

7. Insert green label adapter into the wall outlet (See Fig. B), your entire tree should now be lit. If some bulbs do not light or flicker,

search for any loose plugs and/or broken, loose or missing bulbs. Connect the plugs or replace the bad bulbs promptly in order to

maintain the performance and life expectancy of your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one to the

right, one to the left and one at the center of the main stem. (See Fig. C)

TREE# : C43

MODEL # : TGA0M4865L00

SKU # : 124304194

1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section

below and fold all branches toward the pole.

3. Continue by gently lifting straight up each section(s) from the section below

and fold all branches toward the pole until the bottom section is removed from

the tree stand. Cover the protective cap on the poles to avoid damaging the

internal parts. (See Fig. D)

4. Carefully place all tree sections into shipping box and tape it shut.

5.When not in use, please store your tree in a cool, dry place away from sunlight.

Exposing your tree to excessive heat or humidity may damage your tree.

STORAGE INSTRUCTIONS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected and adapter is plugged into the wall outlet. (If the tree comes

with a foot pedal, try stepping on the on/off button).

2.Turn the poles gently to make sure pole to pole are connected into place.

3. Check for loose connection between light string plugs and extension cords.

4. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure

using the retainer washer. (See Fig. E)

TROUBLESHOOTING TIPS

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included.

If extra parts are needed, please contact our customer service center.

SPARE PARTS

Fig. E

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to

fill any gaps.Your Christmas tree is now complete and ready to be decorated.

Top view Side view

Fig. C

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070

or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

CUSTOMER SERVICE FOR CHRISTMAS TREES

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Fig. D

CAUTION:

To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product.Using a different adapter will damage the lights and may cause

fire, or electrical shock hazards.

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.

c) Do not mount or support strings in a manner that can cut or damage wire insulation.

d) Do not use near candles, heaters, or other similar sources of heat.

e) Do not use candles on tree. Use only included light string (if present).
