Polygroup TG76P4223L17 User manual

MODEL #: TG76P4223L17

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120V, 60Hz, 0.45A

Output: 28V DC 0.9A

Fig. B - Tree and Light Assembly

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®!

This tree comes with Quick Set® and Simple Shape® technology-Set up and light up your tree in less than 10 minutes!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

7.5FT LINDEN SPRUCE TREE ASSEMBLY INSTRUCTIONS

3. Each tree section is numbered with a sticker. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective cap before inserting into the

assembled stand. Make sure the pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.

7. Just plug the adapter (connecting with the tree power cord) into the wall outlet (See Fig. B), your entire tree should now be lit. If

some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs promptly in

order to maintain the performance and life expectancy of your pre-lit tree. * The lights will remain lit even if one bulb burns out.

Fig. A - Tree Stand Assembly

Click

Pull apart the legs of the stand so that they

are snapped into an x-shape, place the tree

stand on a level surface.

To close the stand, press the metal button

and fold the legs together.

Tree top

Section 2

Section 1

Foot Pedal

On/Off Switch

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

NEED HELP?

Plug Adapter

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adapter

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure the power cord is properly connected with the adapter and the adapter is firmly plug to the wall

outlet. (If the tree comes with a foot pedal, try stepping on the on/off button).

2.Turning the poles gently to make sure pole to pole are connected into place.

3. Check for loose connection between light string plugs and extension cords.

4. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and

secure using the retainer washer. (See Fig. E)

TROUBLESHOOTING TIPS

Fig. E

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one

to the right, one to the left and one at the center of the main stem. (see Fig. C)

9.This is a Simple Shape

tree. Just slightly upsweep all branch tips for a uniform look. Shift branches to fill any gaps.Your Christmas

tree is now complete and ready to be decorated.

1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section

below and fold all branches toward the pole.

3. Continue by gently lifting straight up each section(s) from the section below and fold

all branches toward the pole until the bottom section is removed from the tree stand.

Cover the protective cap on the poles to avoid damaging the internal parts. (See Fig. D)

4. Carefully place all tree sections into shipping box and tape it shut.

5.When not in use, please store your tree in a cool, dry place away from sunlight.

Exposing your tree to excessive heat or humidity may damage your tree.

STORAGE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

When using electrical products, basic precautions should always be followed including the following:

a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

b. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use.When products are used in

outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact a

qualified electrician for proper installation.

c.This seasonal use product is not intended for permanent installation or use.

d. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring for the night, or if left unattended.

h.This is not a toy. For decorative use only! To avoid risk of fire, burns, personal injury and electric shock it should not be played

with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or light string.

k. Do not close doors or windows on the product or extension cords as this may damage wire insulation.

l. Do not cover the product with cloth, paper or any material not part of the product when in use.

m.This product is equipped with push-in type lamps. Do not twist lamps.

n. Read and follow all instructions that are on the product or provided with the product.

o. SAVE THESE INSTRUCTIONS

Fig. D

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included.

If extra parts are needed, please contact our customer service center.

SPARE PARTS

Step 1

Grasp the power adapter or power cord plug, and than unplug from the power outlet. Do not pull the power cord.

LAMP REPLACEMENT

Step 2

Lift up lamp lock tab, then

pull the lamp and plastic lamp base

straight out of the lamp-holder.

Step 3

Replace with a new spare

lamp provided with this product.

(Reference figure only)

CAUTION:

1.To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product;

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal,

c) Do not mount or support strings in a manner that can cut or damage wire insulation.

2. Use only the adapter supplied with this product. Using a different adapter will damage the lights and may cause fire, or electrical

shock hazards.

USER SERVICING INSTRUCTIONS

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any replacement parts, troubleshooting, or if there are any questions or concerns about this product, please call

us at 1-888-919-0070 or visit www.polygroupstore.com and a customer representative will be happy to assist you.

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Questions or Comments?

We would love to hear about your

Member’s Mark experience! Visit us at:

samsclub.com/membersmarkhelp
