Polygroup TG76M3AE4C01 User manual

ASSEMBLY INSTRUCTIONS MADE IN CHINA

Top view Side view

Fig. C

MODEL #: TG76M3AE4C01

*Electrical Rating For The Tree

(For Indoor Use Only)

2.04A 120V 60Hz

Fig. B - Tree and Light Assembly

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®! This tree comes with

Quick Set® technology-Set up and light up your tree in less than 10 minutes!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

3. Each tree section is numbered with a tag. Please identify all sections before assembling.

4. Assemble the tree from bottom to tree top. Start with the bottom section and remove the protective

cap before inserting into the assembled stand.Make sure the pole is firmly inserted and secured into the

stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all

wires are free of branch hinges.

7. Insert green label plug into the wall outlet.(See Fig. B ), your entire tree should now be lit. If some bulbs

do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the

plugs or replace the bad bulbs promptly in order to maintain the performance and life expectancy of

your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

Section 3

Section 2

Section 1

Insert

Green Label

Plug Into Wall

Outlet

Do Not Tamper

Internal Parts

Open the

protective

cover

Do Not Tamper

Internal Parts

Open the

protective

cover

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

Please scan code to

learn how to shape

and set up your tree

ASSEMBLY INSTRUCTIONS MADE IN CHINA

STORAGE INSTRUCTIONS

TROUBLE SHOOTING TIPS

SPARE PARTS

1. Unplug extension cord from the wall outlet first and then remove all ornaments and decorations.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to

remove from section below and fold all branches toward the pole.

3. Continue by gently lifting straight up each section(s) from the section

below and fold all branches toward the pole until the bottom section

is removed from the tree stand.Cover the cap on the poles to avoid

damaging the internal parts. (See Fig. D)

4. Carefully place all tree sections into shipping box and tape it shut.

5.When not in use, please store your tree in a cool, dry place away from

sunlight. Exposing your tree to excessive heat or humidity may damage your tree.

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected and power cord is plugged into the wall

outlet. (If the tree comes with a foot pedal, try stepping on the on/off button).

2.Turning the poles gently to make sure pole to pole are connected into place.

3. Check for loose connection between light string plugs and extension cords.

4. Please check for loose, broken or missing light bulbs and replace as needed.

1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer.(See Fig. E)

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs and fuses are also included. If extra

parts are needed, please contact our customer service

center.

Loose Hinge Pin

Fig.E

Fig. D

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
