Polygroup MCP120703 User manual

*Electrical Rating For The Tree

(For Indoor Use Only)

2.38A 120V, 60Hz

Fig.

Top view Side view

Fig. C

SNOITCURTSNIYLBMESSA ANIHCNIEDAM

MODEL #: MCP120703,MCP120703M

Fig. A - Tree Stand Assembly

B - Tree and Light Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

3. Each tree section is numbered with a tag. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and remove protective

cap before inserting into the assembled stand. Make sure the pole is firmly inserted and secured into

the stand.

5. Please remove protective cap from middle section(s) and continue inserting into the bottom section

until the tree top is inserted.

6. Allow branches to fall into place or gently pull up and out. When adjusting branches, be sure that all

wires are free of branch hinges.

7. (For pre-lit trees only) Connect the plug(s) securely to the extension cord(s) as per the color labels

indicated in Fig. B and insert the green label extension cord plug into the wall outlet. Your entire tree

should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose

or missing bulbs. Replace bulbs promptly in order to maintain the performance and life expectancy of

your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

TREE ASSEMBLY INSTRUCTIONS

Insert

Green Label

Plug Into Wall

Outlet

Section 1

Section 2

Section 3

Congratulations on purchasing your new tree from Polytree®! Carefully follow the instructions below

on how to quickly and easily set up your new tree.

Insert Red Label

Plugs Into Red

Labeled Extension Cord

1. Remove all ornaments and decorations. For pre-lit trees, first unplug extension cord from the wall

outlet and then disconnect light extension cord between each section of the tree.

2. D

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and

rotate the upper pole in both directions. Lift up the upper pole again.

isassemble the tree from the top to the bottom.Start with the tree top and gently lift straight up to

remove from section below and fold all branches toward the pole.

STORAGE INSTRUCTIONS

SSA ANIHCNIEDAM

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches

toward the pole until the bottom section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6.When not in use, please store your tree in a cool, dry place away from sunlight.Exposing your tree to

excessive heat or humidity may damage your tree.

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated

in Fig.B and the power cord is plugged into the wall outlet. Refer to assembly guide for instructions. (If

the tree comes with a foot pedal, try stepping on the on/off button).

3. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer. (See Fig. D)

TROUBLE SHOOTING TIPS

SPARE PARTS

SNOITCURTSNIYLBME

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

2. Please check for blown fuses at the power cord plug. Replace as needed.

Note: Please make sure to use appropriate replacement fuses as indicated on the power cord plug.

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs are included. If extra parts are needed,

please contact our customer service center.
