Polaroid Pixie CSA-00302S User manual

FCC Compliance Statement:

This device complies with Part 15 of the FCC Rules. Operation is subjected to the

following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide

reasonable protection against harmful interference in residential installations.

This equipment generates, uses, and can radiate radio frequency energy, and

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause interference to radio or television

equipment reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures:

-Reorient or relocate the receiving antenna.

-Move the equipment away from the receiver.

-Plug the equipment into an outlet on a circuit different from that to which the

receiver is connected.

-Consult the dealer or an experienced radio/television technician for additional

suggestions.

You are cautioned that any change or modications to the equipment not expressly

approved by the party responsible for compliance could void Your authority to

operate such equipment.

* Environment:

Do not throw the product away with the normal household waste at the end of its life.

Bring it to an ofcial collection point for recycling.

By doing this you will help to preserve the environment.

Welcome:

Thanks for purchasing this product. Much time and effort has gone

into this product’s development, and our hope is it will give you many

years of trouble-free service.

Safety Notice:

1. Do not disassemble the camera; otherwise the warranty will be

voided.

2. Avoid all contact with water, and dry hands before using.

3. Do not expose the camera to high temperature or leave it in direct

sunlight. Doing so may damage the camera.

4. Use the camera with care. Avoid pressing hard on the camera

body.

5. For your own safety, avoid using the camera when there is a storm

or lightning.

6. Do not use batteries of different types. Doing so may lead to the

potential for serious damage.

7. Remove the batteries during long periods of non-use, as a

deteriorated battery may affect the functionality of the camera.

8. Remove the battery if it shows signs of leaking or distortion.

9. Use only the accessories supplied by the manufacturer.

10. Keep the camera out of the reach of small children.

13 Lens

14 Flash Strobe

15 Speaker

16 USB Port

17 Bottom Cover (Battery / Memory Card Slot inside)

Parts of the camera - 2Parts of the camera - 1

1Mode Switch

2 Viewnder

3Reset Button

4Directional Pad

5LCD Panel

6TV-out Connector

7Shutter Button

8Start/Pause Button

9Playback/Turbo Button

10 Flash Toggle/B Button

11 Strap Holder

12 Delete/A Button

Need help with your digital camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

Bottom View

13 Lens

14 Flash Strobe

15 Speaker

16 USB Port

17 Bottom Cover (Battery / Memory Card Slot inside)

Parts of the camera - 2

Parts of the camera - 1

1Mode Switch

2 Viewnder

3Reset Button

4Directional Pad

5LCD Panel

6TV-out Connector

7Shutter Button

8Start/Pause Button

9Playback/Turbo Button

10 Flash Toggle/B Button

11 Strap Holder

12 Delete/A Button

Need help with your digital camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

Turning on the camera:

Slide the mode switch to CAMERA ( ) or

GAME ( ) mode to power on the camera.

Turning off the camera:

Slide the mode switch to the OFF position to

power off the camera.

Turning on/off the camera

Icon Description

Full battery life

Half battery life

Empty battery life

Battery life indicator

1. Loosen the 2 screws and remove the battery/card compartment

cover.

2. Insert the card as shown in the illustration until it reaches the end

of the slot.

3. When using a SD card, the camera’s built-in memory will become

inaccessible.

4. To remove the SD card, gently push the card until it pops up.

5. Re-install the cover.

Please use two AAA batteries.

1. Loosen the 2 screws and remove the battery/card compartment

cover as indicated.

2. Load the batteries into the battery compartment with + and - ends

correctly installed.

3. Re-install the cover.

Loading the battery

Inserting the SD/MMC card (optional)

Turning on the camera:

Slide the mode switch to CAMERA ( ) or

GAME ( ) mode to power on the camera.

Turning off the camera:

Slide the mode switch to the OFF position to

power off the camera.

Turning on/off the camera

Icon Description

Full battery life

Half battery life

Empty battery life

Battery life indicator

1. Loosen the 2 screws and remove the battery/card compartment

cover.

2. Insert the card as shown in the illustration until it reaches the end

of the slot.

3. When using a SD card, the camera’s built-in memory will become

inaccessible.

4. To remove the SD card, gently push the card until it pops up.

5. Re-install the cover.

Please use two AAA batteries.

1. Loosen the 2 screws and remove the battery/card compartment

cover as indicated.

2. Load the batteries into the battery compartment with + and - ends

correctly installed.

3. Re-install the cover.

Loading the battery

Inserting the SD/MMC card (optional)

PGG

Taking a still picture

1. Slide the mode switch to CAMERA ( ) mode to power on the

camera.

1. Use the directional pad ( ) to zoom in or zoom out the screen.

2. Press the Shutter button on the top of the camera to take a

still picture.

: You can press the B button to toggle ash mode. Use ash if the

environment is too dark.

Playing back your pictures

1. While in CAMERA ( ) mode, press the Playback/T button.

2. Use the directional pad ( ) to shift between images.

3. You can press the Playback/T button twice to enter thumbnail

mode.

4. Use the directional pad to select a picture and press the Playback/T

button to view the picture in full-screen mode.

5. Press the Shutter button to return to CAMERA preview mode.

Need help with your digital camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

Reading LCD indicators

Camera preview:

Playback thumbnail view:

Playback full view:

Number of

pictures

SD card inserted

Zoom ratio

Highlight box

Flash mode

Mode icon Battery life

Number of

pictures

SD card inserted

Battery life

Number of

pictures

SD card inserted

Battery life

Current images

in memory To delete a picture

1. You must be in the Playback mode.

2. Select a picture and press the Delete/A button.

You will see a prompt window.

3. Select and press the Delete/A button to

conrm the deletion.

4. If you wish to cancel, select .

Taking a still picture

1. Slide the mode switch to CAMERA ( ) mode to power on the

camera.

1. Use the directional pad ( ) to zoom in or zoom out the screen.

2. Press the Shutter button on the top of the camera to take a

still picture.

: You can press the B button to toggle ash mode. Use ash if the

environment is too dark.

Playing back your pictures

1. While in CAMERA ( ) mode, press the Playback/T button.

2. Use the directional pad ( ) to shift between images.

3. You can press the Playback/T button twice to enter thumbnail

mode.

4. Use the directional pad to select a picture and press the Playback/T

button to view the picture in full-screen mode.

5. Press the Shutter button to return to CAMERA preview mode.

Need help with your digital camera?

Call our toll-free customer service number. Look for the insert with this icon:

Or visit www.polaroid.com.

Reading LCD indicators

Camera preview:

Playback thumbnail view:

Playback full view:

SD card inserted

To delete a picture

1. You must be in the Playback mode.

2. Select a picture and press the Delete/A button.

You will see a prompt window.

3. Select and press the Delete/A button to

conrm the deletion.

4. If you wish to cancel, select . Deleting a picture

Playing games on a TV

By connecting your camera and TV via the accessoryAV cable, you

can play the built-in games directly on your TV, enjoying the great

entertainment the camera has to offer.

1. Turn on your TV and switch to the appropriateAV input mode.

2. Connect the audio and video ends of the AV cable to the TV.

3. Slide the mode switch to GAME ( ) mode to power on the

camera.

4. Connect the other end of the AV cable to your camera.

1. Slide the mode switch to CAMERA ( ) mode to power on the

camera.

2. Connect the camera to your computer via the USB cable, and

the camera will become a removable disk in your computer.

3. You can copy les from the camera to your computer, and vice

versa.

Connecting the camera to your PC

AudioVideo

AV Mode TV-Out

Playing games - 1

Slide the mode switch to

GAME ( ) mode, and you

can select any of the 8 built-in

games for your entertainment.

Basic operations in the games:

Game Description

Basketball

Step up to the free throw line and try to

break the record of 20 baskets (1 point

each) within the time limit. Watch the

power bar at the top right of the screen,

when it reaches the level you want, press

the shoot button to throw the ball.

A Button, Turbo next to A: Shoot a basket

Bounce

You’ll need quick reexes and more than

a little luck in this challenging game! Use

the four paddles to bump the ying ball

away from the wall. If it hits the side of the

board, it’s game over!

Directional Pad: 4 directions

This manual suits for next models

Table of contents

Languages:

Other Polaroid Digital Camera manuals

Polaroid

Polaroid 690 User manual

Polaroid

Polaroid impulse series User manual

Polaroid

Polaroid Q10 User manual

Polaroid

Polaroid PDC 5055 User manual

Polaroid

Polaroid 600SE User manual

Polaroid

Polaroid 600 Close-up User manual

Polaroid

Polaroid Spectra/Image One Board Operating instructions

Polaroid

Polaroid PDC 4355 User manual

Polaroid

Polaroid PDC4055 User manual

Polaroid

Polaroid I532 - Digital Camera - 5.0 Megapixel User manual

Polaroid

Polaroid a300 User manual

Polaroid

Polaroid PDC 3000 User manual

Polaroid

Polaroid 1200i - Spectra Instant Camera User manual

Polaroid

Polaroid POP User manual

Polaroid

Polaroid ID100 Operating instructions

Polaroid

Polaroid MiniPortrait 205 User manual

Polaroid

Polaroid t1242 User manual

Polaroid

Polaroid I832 - Digital Camera - 8.0 Megapixel User manual

Polaroid

Polaroid Snap Touch User manual

Polaroid

Polaroid MiniPortrait 203 User manual

Polaroid

Polaroid DIGITAL MINI PORTRAIT User manual

Polaroid

Polaroid Z340E User manual

Polaroid

Polaroid REVUE 5005 Instruction sheet

Polaroid

Polaroid T1234 - Digital Camera - Compact User manual

Popular Digital Camera manuals by other brands

Mercury

Mercury 350K user manual

Pentax

Pentax Optio LS 465 operating manual

Sanyo

Sanyo VPC-S1085 instruction manual

GE SMART A1255 user manual

Point Grey

Point Grey Gazelle Getting started

Nikon

Nikon COOLPIX A Reference manual

Pentax

Pentax P-5 manual

BlazeVideo

BlazeVideo A280 instruction manual

Sony

Sony MCA-20 manual

Sony

Sony Alpha DSLR-A290 instruction manual

ATIK Cameras

ATIK Cameras One user manual

CohuHD Costar

CohuHD Costar 3930 Series Installation and operation manual

Leica

Leica M10-R quick start guide

FujiFilm

FujiFilm FinePix A700 owner's manual

Lorex

Lorex LNZ81P25 Series quick start guide

GE J1470S user manual

Sony

Sony A6700 Startup guide

Canon

Canon EOS ELAN7 instructions

Polaroid pixie CSA-00302S User manual

Popular Digital Camera manuals by other brands
