Seite 2 von 7
Table of Contents
1Viewing the measurement results....................................................................................3
2“Camera image” results page ..........................................................................................4
3“Measurement values” results page.................................................................................4
4“Database” results page (only plusoptiX A12C and A16) .................................................6
5Performing the next measurement...................................................................................7
List of figures
Figure 1: Overview of the results pages ................................................................................ 3
Figure 2: Viewing the measurement values........................................................................... 4
Figure 3: “Database” results page ......................................................................................... 6
This manual is a supplementary short manual. For general information about your
Plusoptix device, such as its intended use, basic handling, technical information,
maintenance, service, and warranty information, please refer to the user manual that
was delivered with your device. This user manual can also be downloaded on our
homepage www.plusoptix.com, under support.
List of further supplementary short manuals
1. Adjusting settings and setting up WLAN
2. Preparing and performing a measurement
3. Viewing the measurement results
4. Entering, retrieving or deleting patient data
5. Documenting measurement results electronically
6. Documenting measurement results on paper
7. Exporting back-ups and reports (only plusoptiX A12C and A16)
8. Downloading software updates
9. Troubleshooting malfunctions and measuring interruptions
