Planar Dome E2 User manual

Dome EX Displays

Quick Reference

Windows XP

Windows 2000

020-0434-02A_1.indd 1020-0434-02A_1.indd 1 11/16/06 5:44:10 PM11/16/06 5:44:10 PM

Check that your system meets these requirements for installation of a Dome EX

display system. The Dome E3 and E3c displays are compatible with either the

DX2 or the AX5 board.

Before You Begin

EX Display Controller System Requirements Operating System

Dome E2

Dome E3

Dome E3c

Dome E5

DX2 • PCI slot per board

(64-bit recommended)

• 50 MB hard disk space

• 256 MB RAM

• CD-ROM drive

Windows XP

Service Pack 2

Windows 2000

Service Pack 4

Dome E3

Dome E3c

AX5 • Intel Pentium 4/Xeon; AMD Athlon

64/K7/XP or compatible

• PCI Express x16 lane slot

• 50 MB hard disk space

• 256 MB RAM

• CD-ROM drive

• Power supply, 350 watts or greater

Safety Precaution

Wear an antistatic heel or wrist strap

when installing the video card to avoid

damage to computer components.

Warning

Avertissement

Avvertenza

Advertencia

Warnung

Increasing the PCI Bus Performance

(PCICacheMode registry entry)

On systems with 64-bit PCI slots, use the display

driver to enable write-combining for the display

controller. Enabling this function can improve video

performance on the board by 100% or more.

The results: faster image loads, increased window

and level speed, and enhanced system performance.

For more information, visit www.planar.com.

020-0434-02A_1.indd 2020-0434-02A_1.indd 2 11/16/06 5:44:13 PM11/16/06 5:44:13 PM

Unpacking the Display

Check the contents of your Dome EX display package for all the items

shown here. Save the original packaging materials for storage and shipping.

Guidelines

• Use both hands to lift

or adjust the display.

• Avoid touching the

display screen.

• Do not set up the display

in areas with sudden

temperature changes and

strong light sources.

• Do not block the vents on

the back of the display.

• Do not remove the back

cover or disassemble

the display.

• In locations where 240V

outlets are used, connect

the display only to a

center-tapped, 240V,

single-phase supply.

Dome EX

digital at panel

Power block

Dome EX and Dome CXtra

quick references

Display controller

Power cord

DVI-to-DVI video cable

Dome display driver

and Dome CXtra CDs

020-0434-02A_1.indd 3020-0434-02A_1.indd 3 11/16/06 5:44:14 PM11/16/06 5:44:14 PM

Setting DIP Switch S2

If you are installing the DX2

display controller, you will need

to set DIP switch S2 for your

system conguration.

Slide switch 1 into the ON

position to enable VGA mode.

Enable VGA on only one (1)

board when you install

multiple boards. Disable VGA

on all boards if you are using

a separate VGA card.

For some Dell systems, you may

need to enable VESA modes

in order to see output on the

screen. If so, slide switch 2 into

the ON position.

For single desktop mode, slide

switch 3 into the ON position.

Video #1

port

DX2

DIP Switch S2 Function Position

1 VGA ON

2 VESA ON

3 Single Desktop ON

020-0434-02A_1.indd 4020-0434-02A_1.indd 4 11/16/06 5:44:15 PM11/16/06 5:44:15 PM

Installing the Display Controller

To install the controller

1 Turn o all peripherals. Disconnect all

cables from the back of your computer.

2 Remove the computer cover.

3 Remove the blank bracket from the

available PCI or PCI Express slot.

4 Insert the display controller into the slot,

align the connector pins, and press the

board down until it is rmly seated.

5 Secure the mounting bracket.

6 Reattach the computer cover and

the peripherals.

Before you install the DX2 or AX5 display controller, turn your computer

o. Leave the power cord plugged into the grounded outlet.

Notes

• When installing multiple

display controllers, install

all boards before you

install the driver.

• The top port on the

Dome DX2 board is the

primary (DVI #1) port.

• The AX5 board supports

dual-link functionality

on the Dome E3 and

Dome E3c displays.

• The bottom port on the

AX5 board is the primary

(DVI #1) port.

020-0434-02A_1.indd 5020-0434-02A_1.indd 5 11/16/06 5:44:15 PM11/16/06 5:44:15 PM

Power cord DVI cable

Connecting the Display

To connect the display

1 Press the PUSH button on the

desk stand and remove the stand

cover.

2 Plug one end of the DVI cable into

the DVI connector port. Tighten

the thumbscrews to secure the

connection.

3 Plug the power cord into the power

input port.

4 Plug the other end of the DVI cable

into the video port on the installed

display controller. Use DVI port #1

to install only one display.

5 Plug the other end of the power

cord into a grounded outlet.

6 Thread the cable and cord through

the stand column and reattach the

stand cover.

7 Power on your display rst, then

the computer.

Use only the cable and power cord supplied with the Dome EX display.

020-0434-02A_1.indd 6020-0434-02A_1.indd 6 11/16/06 5:44:15 PM11/16/06 5:44:15 PM

Installing the DX Display Driver

Before you install the driver, remove any previously installed display driver from

your system.

To install the driver

1 Log on with administrator privileges. The InstallShield Wizard reports

new hardware.

2 Click Cancel. You must run Setup.exe to install the driver.

3 Insert the W2KDXPCI CD and open the CD folder.

4 Double-click Setup.exe.

5 Click Next to proceed and start copying les.

6 If the Digital Signature Not Found message appears, click Yes or Continue to

complete the driver installation.

7 Select Yes,I want to restart my computer now, and click Finish.

To enable the display

1 Log on with administrator priviledges.

2 Right-click the desktop. Select Properties > Settings.

3 Select the display icon.

4 Select Extend my Windows desktop onto this monitor. Click Apply.

5 Click OK.

To change the display properties

Use the Dome tab to change display properties after the Dome EX display is

attached to the Windows desktop. Otherwise, use Properties > Settings tab.

020-0434-02A_1.indd 7020-0434-02A_1.indd 7 11/16/06 5:44:16 PM11/16/06 5:44:16 PM

Auto-orientation

When powering on or resetting your computer, the orientation of your panel is

detected automatically, whether portrait or landscape. The default setting is ON.

Use the Dome tab to disable this funtion.

To set the resolution palette

Use the Resolution eld on the Dome tab to manually set the resolution to

portrait or landscape.

1 Log on with administrator priviledges.

2 Right-click the desktop. Select Properties > Settings.

3 Select the Plug and Play Monitor on Dome DX2/PCI Properties from

the Display list.

4 Select Extend my Windows desktop onto this monitor. Click Apply.

5 Select Advanced > Dome.

6 Choose a resolution and palette option. Click Apply.

7Click OK until you return to the desktop.

To set brightness

In the Brightness eld of the Dome tab, slide the scroll box left or right, or use

the left and right arrows, to adjust each panel. (The default brightness is 100%.)

Click OK. (Note: If the Dome CXtra software is running, the brightness function

on the tab is disabled.)

020-0434-02A_1.indd 8020-0434-02A_1.indd 8 11/16/06 5:44:16 PM11/16/06 5:44:16 PM

Before you install the driver, remove any previously installed display driver from

your system. Refer to Dome EX User’s Guide for instructions on changing the

display orientation and setting up a dual-display conguration.

To install the driver

1 Start the system. Click Cancel on the Found New Hardware Wizard.

Click No when the system prompts you to restart the computer.

2 Insert the driver installation CD and run Setup.exe.

3 Click Next.

4 Click Yes to the license agreement. The installation starts.

5 Follow the onscreen instructions to complete the installation.

Planar recommends that you select the Express installation option.

6 When the Setup complete message appears, select Yes, I want to restart

my computer now and click Finish.

7 If the Digital Signature Not Found message appears, click Yes or Continue to

complete the driver installation.

To congure the display

1 Right-click the desktop and select Properties > Settings.

2 Use the native resolution of the display.

3 Click OK until you return to the desktop.

To set the brightness

Install the Dome CXtra software to change the display brightness. Adjust

the value of the white level on the Backlight tab of the RightLight Panel

Conguration dialog.

Installing the AX5 Display Driver

020-0434-02A_1.indd 9020-0434-02A_1.indd 9 11/16/06 5:44:16 PM11/16/06 5:44:16 PM

Display Resolution Palette Bits per pixel

Dome E2 1200 x 1600

1600 x 1200

1200 x 1600

1600 x 1200

Dynamic Gray

Nonlinear Gray

Static Gray

True color

Dome E3 1536 x 2048

2048 x 1536

3072 x 2048*

4096 x 1536†

1536 x 2048

2048 x 1536

3072 x 2048*

4096 x 1536†

Dynamic Gray

Nonlinear Gray

Static Gray

True color

Dome E3c 1536 x 2048

2048 x 1536

3072 x 2048*

4096 x 1536†

True color 32

Dome E5 2048 x 2560

2560 x 2048

4096 x 2560*

5120 x 2048†

Dynamic Gray

Nonlinear Gray

Static Gray

Display Resolutions and Palette Options

* Single desktop in portrait mode on a dual-display system, using Dome DX2 board only.

† Single desktop in landscape mode on a dual-display system, using Dome DX2 board only.
