Pioneer AVIC-U310BT User manual

Basic Hardware buttons

FLASH MEMORY NAVIGATION AUDIO

RECEIVER

Quick Start Guide

This guide is intended to guide you through

the basic functions of this navigation system.

For details, please refer to the operation man-

ual.

Searching for your destination

by address

1Display Navigation Menu

and touch Address.

2Input the information that

you want to set as the des-

tination.

Touching the one of options.

After narrowing down your desti-

nation, “Location confirmation

screen” will appear.

3Touch OK.

After searching for the destina-

tion, the “Route confirmation

screen” appears.

4Touch OK.

This navigation systems gives

you route guidance both visually

and by voice.

AVIC-U310BT

Switching the screen

Audio screen

Map screen

Published by Pioneer Corporation.

<KYTZX> <09E00000> <CRB3017-A/S> UC

Press the MODE button to switch between map screen and

audio screen.

Navigation Menu

Touch Menu on the map screen.

5 6 7

2 3 8 9 a

b c d

1MODE button

2MULTI-CONTROL

Rotate to adjust the audio volume.

Pressing this button when the

audio source is selected plays the

track, file or skips chapter.

3LIST button

The list lets you see the list of

file names or folder names.

4SRC/OFF button

Selecting the audio source.

5BAND/ESC button

Changes the band for the radio.

6DETACH button

Press to remove the detachable

device from the head unit.

1Search by address

2Shortcut key for calculating

route of going home

3Search for stores, restau-

rants, and other businesses

in the points of interest data-

base

4Searching for POIs by using

the data on external storage

devices (SD)

5Select a destination from

your address book

6Select a previously routed

destination

7Canceling your current route

8Searching for a location by

coordinates

9Gas Mileage Management

aSwitching to “PC Mode”

bChecking the current route

conditions

cReplicating the settings

dExporting and importing the

data

1Touch Settings on the

“Navigation Menu” screen.

2Touch Sound.

Basic items on the map

1Information for the next

guidance point

2Current time

3Estimated time of arriv-

al (or distance to the

destination)

4Current route

5Current position

6Street name that your

vehicle is traveling

along

7Changing the map

scale and the map ori-

entation

Pairing your

phone

1Activate the Bluetooth

function on your phone.

2Touch the keys in the fol-

lowing order; Phone ➡

Settings

3Turn Bluetooth On/Off to

On.

4Touch the keys in the fol-

lowing order;

Connections ➡Add ➡

Search devices

The system tries to find and

lists nearby devices.

5Touch your phone on the

list and then enter the PIN

code from your phone.

(The PIN code is “1111”.)

When the pairing is success-

ful, the message will appear.

Transferring

the phone book

1Connect the cellular

phone.

2Touch Transfer on Phone

Menu.

3Touch OK to enter the

waiting screen.

4Operate your phone to

transfer the phone book

entries during waiting

screen.

5After transferring, touch

OK.

When the transferring is suc-

cessful, “Completed data

loading!” will appear.

Dragging the map allows

scrolling. The scroll speed will

change depending on your drag

speed.

Scrolling the map

Setting the volume for navigation

system

Selecting the

audio source

1Press the MODE button

when the map of the cur-

rent location is displayed.

2Press the SRC/OFF button

repeatedly to switch

between the following

sources.

XM (XM tuner)➡SIRIUS

(SIRIUS tuner)➡HD Radio

(HD Radio tuner)➡TUNER

(tuner)➡CD (built-in CD

player) ➡USB (USB storage

device)/iPod (iPod connected

using USB input)➡EXT1

(external unit 1)➡EXT2

(external unit 2)➡AUX

(auxiliary device)➡XM (XM

tuner)

Notes:

・ The audio source is disabled

if the equipment is not con-

nected or inserted.

・ When the tuner has been

tuned in to an HD Radio

broadcasting, “TUNER” can

not be selected.

Tuner source screen

1 2 3

1 Shows which band the

radio is tuned to: FM1 to

FM3.

2 Shows what preset item

has been selected.

3 Shows the frequency.

4 Storing and recalling

broadcast frequencies

Playing your

Apple iPod

You can control an iPod by con-

necting the USB interface cable

for iPod (CD-IU50) (sold sepa-

rately) to the navigation system.

1Connect your iPod.

2Switch the audio source to

iPod.

1 Text display area

2 Switches the strings in the

text area

3 Sets iPod control mode.

This navigation system’s iPod

function can be operated from

the connected iPod.

4 Playing songs in random

order

5 Playing songs related to

the currently playing song

・Pressing MULTI-

CONTROL right or left

Skips the track forward or

backward.

・Pressing and holding

MULTI-CONTROL right or

left

Perform fast forward or

backward.

・Pressing the center of

MULTI-CONTROL

The advanced function

screen appears.

・MULTI-CONTROL

Rotating

Adjusts the audio source vol-

ume.

・Pressing LIST button

Shows the list to select a

song.

Note:

In this manual, iPod and

iPhone will be referred to as

iPod.

USB interface

cable for iPod

USB

connector
