Pickering Pxi 41-182A User manual

Page (1)

50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Issue 1.1 February 2019

User Manual

50Ω 6GHz Solid State Attenuator

(Model No. 41-182A)

pickeringtest.com pickering

Page (II) 50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) 50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI Cards.................4.1

Module Architecture..............................................................4.3

Programming The Module ....................................................4.4

Using Pickering Drivers in LabVIEW ...................................4.6

Programmable Attenuator Soft Front Panel .......................4.7

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting.........................................................................6.1

Section 7

Maintenance Information............................................................7.1

CONTENTS

Page (VI) 50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

Page (VII)

REED RELAY MODULE 40-110/115/120/125

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the PXI/LXI chassis are populated with blanking plates to prevent access to user

I/O signals that may be present. Blanking panels are available to order from Pickering in a variety

of slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page (VIII) 50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

THIS PAGE INTENTIONALLY BLANK

Page 1.1

50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI 6GHz Triple Solid State Attenuator 41-182A

ISSUE 1.1 FEB 2019

• 10MHz To 6GHz Programmable Attenuator

• 0 to 31.75dB in 0.25dB Steps For Fine Level

Control

• Three or Six Channels Per Module

• Solid State Switching For Long Service Life

• Robust SMA Connectors

• VISA, IVI & Kernel Drivers Supplied for Windows

• Supported in PXI or LXI Chassis

• 3 Year Warranty

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 1

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 2

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 3

41-182A Triple 6GHz Solid State Attenuator Functional Diagram

(Default Condition Shown - All Channels Set To 0dB Attenuation)

The 41-182A is a programmable RF attenuator module that has

3 (one slot) or 6 (two slots) channels each capable of inserting a

signal loss of 0 to 31.75dB in 0.25dB steps. The attenuator uses

solid state switches for a long service life and fast operation with

minimum settling time and no signal bounce. The inclusion of

DC blocking reduces the risk of damage to the switches by the

accidental application of DC sources from ampliers or other bias

devices.

The 41-182A is ideal for conditioning signal levels in RF test

systems to ensure equipment is used in its optimal signal level

range. Fast attenuator operating speed ensures minimal system

delays in setting up the required attenuation and a service life

which is independent of the number of operations allows the

sequence of RF tests to be arranged to optimize the life of other

switching components in the system.

The attenuators can be connected in series to increase the

attenuation range available and the high isolation minimizes signal

leakage.

The attenuators can be used for the back to back testing of

devices, providing the ability to condition the signal level between

the two devices. It is also ideal for the conditioning of special to

type signal sources which lack ne level control.

SMA connectors ensure that the attenuators can be used

with standard cabling and the input and output ports are fully

interchangeable.

Page 1.2 50Ω 6GHz SOLID STATE ATTENUATOR 41-182A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

6GHz Triple Solid State Attenuator – 41-182A

pickeringtest.com

Speciﬁcations

Insertion loss for every discrete attenuator setting

for all channels of 41-182A-003 (normalized to 0dB)

Insertion loss for 41-182A-003 with each

attenuator channel set to 0dB

VSWR for 41-182A-003

with all attenuator channels set to 0dB

Attenuation values for 41-182A-003

with three attenuator channels in series

(set to major step values)
