Philips HR8378/07 User manual

City line reach & clean

ENGLISH 4

DEUTSCH 14

FRANÇAIS 24

NEDERLANDS 34

ESPAÑOL 44

ITALIANO 54

PORTUGUÊS 64

NORSK 74

SVENSKA 84

SUOMI 94

DANSK 104

 114

TÜRKÇE 124

CITY LINE REACH & CLEAN

Important

◗Only use Philips s-bag`double-layer paper dustbags (FC 8021) or

Philips Sydney+ double-layer paper dustbags (type HR 6999).

◗Check if the dustbag has been placed correctly.

◗Never use the vacuum cleaner to suck up water or any other

liquid.Never pick up ashes until they are cold.

◗When the vacuum cleaner is used to suck up fine dust,the pores

of the dustbag may become clogged,causing the passage of air

through the dustbag to become obstructed.As a result,the

dustbag-full indicator will indicate that the dustbag needs to be

replaced,even though the dustbag is not full at all.

◗Never use the appliance without the Motor Protection Filter.This

could damage the motor and shorten the life of the appliance.

◗The infrared remote control on the handgrip contains electronic

components (specific types only).

To avoid defects, never clean this part with water.

Connecting accessories

C◗To connect the hose to the appliance,push it into the appliance

and turn it clockwise.

To disconnect the hose from the appliance,turn it anticlockwise and

pull it out of the appliance.

Button coupling orActive coupling (specific types only)

C1Connect the tube to the handgrip by pressing the spring-

loaded lock button on the handgrip and inserting the handgrip

into the tube.Fit the spring-loaded lock button into the

opening in the tube ("click").

◗To disconnect the tube from the handgrip,press the spring-loaded

lock button and pull the handgrip out of the tube.

◗Use the same method to connect and disconnect the other

accessories.

Telescopic tube

C◗Adjust the tube to the length you find most comfortable during

vacuum cleaning.

ENGLISH4

Reach & Clean nozzle

C◗The Reach & Clean nozzle can be used on either carpets or hard

floors.The nozzle can be put in 4 different positions,allowing you

to also vacuum clean hard-to-reach places in an easy way.The

nozzle can be turned 360 degrees clockwise as well as anti-

clockwise.

C◗To adjust the nozzle to the type of floor and the area to be

cleaned,put your foot on the indicated positions and then turn

the tube until the nozzle is in the required position.

C1With the nozzle positioned breadthwise and the brush strip

folded out,you can clean large hard floor areas.Turn the nozzle

until the brush strip pops out of the nozzle housing and the

nozzle is positioned breadthwise.

C2With the nozzle positioned lengthwise and the brush strip

folded out,you can vacuum clean small hard floor areas.Turn

the nozzle 90 degrees clockwise until it is positioned

lengthwise with the brush strip still folded out of the nozzle

housing.

C3With the nozzle positioned breadthwise and the brush strip

folded in,you can vacuum clean large soft floor areas.Turn the

nozzle 90 degrees clockwise again to position the nozzle

breadthwise and to make the brush strip disappear into the

nozzle housing.

ENGLISH 5

C4With the nozzle positioned lengthwise and the brush strip

folded in,you can vacuum clean small soft floor areas.Turn the

nozzle 90 degrees clockwise again until it is positioned

lengthwise with the brush strip still folded in.

Crevice nozzle,brush nozzle and small nozzle

The crevice nozzle can be used either for cleaning narrow corners or

hard-to-reach places.

C1Lift the handle on the vacuum cleaner to gain access to the

accessory storage compartment.

2Connect the crevice nozzle to the tube or directly to the

handgrip.

C3The brush nozzle can be used for cleaning computers,

bookshelves etc.

C4The small nozzle can be used for vacuum cleaning small areas,

e.g.the seats of chairs and sofas.

Vacuum cleaning

C1Pull the cord out of the appliance and put the mains plug in the

wall socket.

ENGLISH6

C2Switch the appliance on by pushing the on/off button on top of

the appliance with your foot.

C3To carry the appliance,put the handle in upright position and

lift the appliance by the handle.

Adjusting suction power

You can adjust the suction power during vacuum cleaning:

C1Adjust the suction power by means of the electronic suction

power control (specific types only).

Infrared remote control (specific types only)

C1Place the batteries in the battery compartment.

Make sure the - and + poles are pointing in the right direction.

C2With the infrared remote control you can set the suction

power to one of 5 different suction power settings.When you

switch the appliance on,it will always start running at the

highest suction power setting.

ENGLISH 7

C3By pushing the - button,you will reduce the suction power by

one setting.

C4By pushing the + button,you will increase the suction power

by one setting.

C5Push the standby button to temporarily switch the vacuum

cleaner off,for instance when you have to move some

furniture.

6To continue vacuum cleaning,simply press the - button or the

+ button.The appliance will start operating at the previously

selected suction power setting again.

Storage

1Switch the appliance off.

2Remove the mains plug from the wall socket.

C3Rewind the mains cord by pressing the cord rewind button.

C4Put the appliance in upright position and attach the lower tube

to the appliance by means of the clip.

◗The height of the clip can be adjusted by sliding it along the tube.

ENGLISH8

Replacing the dustbag

◗Replace the dustbag as soon as the "dustbag-full indicator" changes

colour (when the nozzle is not placed on the floor).

1Switch the appliance off.

C2Open the cover.

C3Push the dustbag holder backwards.

C4Remove the full dustbag from the holder by pulling the

cardboard tag.

When you do this,the dustbag will be automatically sealed.

C5Slide the cardboard front of the new dustbag into the two

grooves of the dustbag holder.Press it down as far as possible.

C6Pull the dustbag holder forwards (you will hear a click).

You cannot close the cover if no dustbag has been inserted.

ENGLISH 9

Replacing filters

Motor Protection Filter

1Replace the Motor Protection Filter when you insert the first

of a new set of dustbags or once a year.

C2Insert the filter into the appliance with the white side facing

upwards.

AFS Micro Filter

The AFS Micro Filter in this appliance will remove a large part of the

smallest particles from the exhaust air by means of its electrostatically

charged fibres.

C1Replace theAFS Micro Filter when you insert the first of a new

set of dustbags or once a year.

C2Place the sides and the bottom edge of the new filter properly

behind the ridges of the holder.

3Make sure the filter has been properly inserted into the holder

before you close the filter holder.

HEPAFilter (specific types only)

Some appliances are equipped with an HEPA Filter.This filter not only

removes household dust,but also harmful microscopic vermin.

1Replace the HEPA Filter at least once a year.

C2Open the filter grille.

ENGLISH10
