Philips FC6055/01 User manual

FC6055

ENGLISH 6

 15

 25

 33

 41

 50

 59

 69

 77

 85

 94

 103

 113

 122

 130

 139

General description (Fig. 1)

ACrevice tool

BBrush tool

CSqueegee

DFilter holder

EFilter

FFilter ring

GStorage slots for accessories

HCharging unit

IAdapter

JDust compartment

KDust compartment release button

LExhaust air openings

MCharging light (LED)

NOn/off slide

OContact strips

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

Do not use the appliance if it is damaged in any way.Take it to an

authorised Philips service centre for repair.

Check if the voltage indicated on the adapter corresponds to the

local mains voltage before you connect the appliance.

The adapter and the charging unit of this appliance cannot be

replaced. If the adapter or charging unit is damaged, the appliance

must be discarded.

Never suck up ammable substances or corrosive liquids and do

not suck up ashes until they are cold.

Never immerse the vacuum cleaner or the charging unit in water

and do not let water enter the motor unit or the charging unit.

Remove the adapter from the wall socket before cleaning the

charging unit.

ENGLISH

Only charge the vacuum cleaner with the adapter and charging unit

supplied. During charging, the adapter will feel warm to the touch.

This is normal.

Do not hold the appliance with the dust compartment pointing

upwards and do not tilt the appliance to one side when sucking up

liquids.

Always switch the vacuum cleaner off after use.

Keep the appliance out of the reach of children.

The voltage on the contact strips in the charging unit is low (max.

12 volts) and therefore not dangerous.

Never block the exhaust air openings during vacuuming.

Switch the appliance off when recharging it.

When the appliance has been used to suck up liquids, empty and

dry the dust compartment before storing the appliance in the

charging unit.

To avoid the risk of electric shock, be careful when drilling holes in

the wall to attach the charging unit, especially close to a wall socket.

Noise level: Lc = 80 dB [A]

Preparing for use

Installing the charging unit

1 You can attach the charging unit to the wall as indicated in the

gure. (Fig. 2)

If you attach the charging unit to the wall, the space between the screw

holes should be 70 mm.

2 You can also place the charging unit on a horizontal surface (e.g. a

table or desk). (Fig. 3)

3 Excess mains cord can be wound round the charging unit. (Fig. 4)

Charging the appliance

Charge the appliance for at least 16 hours before you use it for the rst

time.

1 Insert the adapter into the wall socket.

ENGLISH 7

2 Place the vacuum cleaner on the charging unit. (Fig. 5)

The charging light will go on to indicate that the appliance is

charging. (Fig. 6)

Note:The charging light will stay on as long as the appliance is connected to

the charging unit and the adapter is in the wall socket.

Note:The charging light does not give any information about the charge level

of the built-in batteries.



1 Push the on/off slide forwards to switch the appliance on. (Fig. 7)

2 Push the on/off slide backwards to switch the appliance off. (Fig. 8)

3 Leave the adapter in the wall socket and always put the vacuum

cleaner back onto the charging unit immediately after use, even if

the batteries are still almost fully charged.

Brush, crevice tool and squeegee

This appliance comes with three accessories:

a brush tool to clean delicate surfaces;

a crevice tool to clean hard-to-reach places;

a squeegee to suck up liquids.

1 Take the accessory you want to use from the charging unit.

2 Attach the accessory to the nozzle of the appliance. (Fig. 9)

When sucking up liquids, hold the appliance with the nozzle

pointing downwards at an angle of 30 c. Make sure the squeegee

touches the surface to be cleaned. Do not tilt the appliance to one

side.

Stop sucking up liquids when the liquid level inside the dust

compartment has reached the maximum indication line.

Never hold the appliance with the on/off slide pointing downwards

when the dust compartment is lled with liquid. (Fig. 10)

Empty the dust compartment each time you have used the

appliance to suck up a liquid.

ENGLISH8

3 You can store all accessories by placing them in the storage slots in

the charging unit. (Fig. 11)

Cleaning

Always remove the adapter from the wall socket before cleaning the

charging unit.

When you have used the appliance to suck up liquids, empty and dry

the dust compartment.

1 Clean the appliance with a damp cloth.

Emptying the dust compartment

Make sure you empty the dust compartment and clean the lter regularly.

1 Hold the appliance over a dustbin and press the dust compartment

release button. (Fig. 12)

2 Remove the lter holder from the dust compartment. (Fig. 13)

3 Empty the dust compartment with your free hand.

4 Clean the lter and the lter holder. (Fig. 14)

Note:Remove the lter from the lter holder by turning it anticlockwise.

Note:Clean the lter with a brush or with a normal vacuum cleaner if it is

very dirty.

Note:If necessary, you can rinse the lter in cold or lukewarm water.

5 Fasten the lter in the lter holder by turning it clockwise and put

the lter holder into the dust compartment. Make sure you insert

the lter holder in the correct way. (Fig. 15)

Never use the vacuum cleaner if the lter is still wet.

Replacement

Replace the lter if it can no longer be cleaned properly (usually

after having been cleaned about 50 times).

ENGLISH 9

1 Remove the lter holder from the dust compartment. (Fig. 16)

2 Remove the lter from the lter holder by turning it anticlockwise.

(Fig. 17)

3 Remove the lter from the ring by gently turning it anticlockwise.

(Fig. 18)

4 Attach a new lter to the lter ring by turning it clockwise. (Fig. 19)

5 Push the tip of the lter inwards. (Fig. 20)

6 Fasten the lter in the lter holder by turning it clockwise. Put the

lter holder back into the dust compartment. (Fig. 21)



New lters are available under type no. FC8036. Contact your Philips

dealer.

Environment

Do not throw the appliance away with the normal household waste

at the end of its life, but hand it in at an ofcial collection point for

recycling. By doing this you will help to preserve the environment.

(Fig. 22)

Saving energy

If you are not going to use the appliance for a longer period of time, we

advise you to remove the adapter from the wall socket to save energy.

Disposal of batteries

NiCd/NiMH batteries can be harmful to the environment and may

explode if exposed to high temperatures or re.

Batteries contain substances that may pollute the environment.Always

remove the batteries before discarding the appliance or handing it in at

an ofcial collection point. Dispose of the batteries at an ofcial collection

point for batteries.

Only remove the batteries if they are completely empty.

Remove the batteries in the following way.

ENGLISH10
