Philips Aurea User manual

Start

Quick

www.philips.com/welcome

Installation

What’s in the box

User manual

Start guide

Television and stand

Start

Power cord and antenna cable Scart - SVHS - Cinch adaptor

Remote control

Wall mount bracket

Please find the wall mounting and / or VESA compliant

mounting instructions in the User manual.

OUT

VESA, FDMI and the VESA Mounting Compliant logo are trademarks of the Video Electronics Standards Association.

Remove the yellow brake at the back of

the stand to allow the TV to swivel.

1Swivel stand

Remote control

Navigation and OK key

Press o,œor p,πto navigate the

TV menu. Press the OK key to con-

firm your choice.

Colour coded keys

Press a colour key to select a task

or choice shown on screen.

OPTION

DVD STB HTS

LIST

21 3

54 6

87 9

iP P

jbq

INPUT

GUIDE

DEMO

BROWSE

TELEVISION

1 2

3Power & antenna

The TV will switch on automatically when

you plug in the power cord.

Cable

ANTENNA

MAINS

Installation

Select your menu language with the cursor up / down.

Menu language

Select your language

with the cursor up / down

Next-

Nederlands

Français

Chinese

Hrvatski

Magyar

English

Italiano

Press OK or the green colour key on your remote control to continue

Menu language

Français

Chinese

Hrvatski

Italiano

Magyar

Nederlands

English

Select your language

with the cursor up / down

Press œ or oto select your language. Press the green key to proceed the installation.

Tip – Press the red key repeatedly to return to

a previous menu in case you made a mistake.

•••

OPTION

DVD STB HTS

LIST

INPUT

GUIDE

DEMO

BROWSE

OPTION

DVD STB HTS

LIST

INPUT

GUIDE

DEMO

Enjoy your television !

If later on you still want to change a setting, you can

go to the installation section in the menu.

Installation

Finish

You can now start automatic installation.

This can take more than half an hour.

Start Skip StopPrevious

Television

The automatic installation will search and store all

available TV channels.

Tip – If you watch all TV channels with a cable box

or digital receiver, you can skip this automatic

installation.

You finished the installation succesfully.

Press the red key to watch TV.

If you want to change the order of the TV channels,

see section 6.3.3 Reorder the channels of the user

manual.

•••

Caution

Disconnect the TV mains power

before you connect other devices.

DVD player, HD game, Home Theatre System

Set the adaptor switch to Input.

HD Game console

Home Theatre System

Or use an HDMI connection for your DVD

or Blu-ray Disc player.

DIGITAL AUDIO

HDMI In

DVD player

AUDIO

OUT

VIDEO

S-VIDEO

ACE ANTENNA

SERVICE

UART

HDMI 1 HDMI 2 HDMI 3

HDMI

OUT

AUDIO OUT

RDIGITAL

AUDIO

OUT

DISPLAY SYNCHRONIZED

EXT 3 EXT 2 EXT 1

AUDIO L / R

EXT 3

HDMI 1 (DVI)

HDMI 2 (DVI)

HDMI 3 (DVI)

INPUT OUTPUT

DVD recorder and HD receiver

Or use an HDMI connection for the

DVD Recorder.

HDMI In

DVD recorder

HD receiver

Set the adaptor switch to Input.

ANTENNA

OUT

ANTENNA

Splitter

Cable

AUDIO

OUT

VIDEO

S-VIDEO

HDMI

OUT

HDMI OUT

EXT 3 EXT 2 EXT 1

AUDIO L / R

EXT 3

HDMI 1 (DVI)

HDMI 2 (DVI)

HDMI 3 (DVI)

ACE ANTENNA

SERVICE

UART

HDMI 1 HDMI 2 HDMI 3

AUDIO OUT

OUT

DIGITAL

AUDIO

DISPLAY SYNCHRONIZED DISPLAY

SYNCHRONIZED

INPUT OUTPUT

Photo camera, game, camera, PC

Computer

DVI TV OUT

Game console

Camcorder

Photo camera

Caution

Before connecting a PC, set the PC

monitor refresh rate to 60Hz.

USB

S VIDEO

VIDEO

AUDIO

S VIDEO

VIDEO

AUDIO

S VIDEO

VIDEO

AUDIO
