Philips 32PHT4001/60 User manual

15.OSD Tree(Page64-70)

14.ISP Customs Table(Page63)

Colour Television Chassis

32PHT4001/60

43PFT4001/60

contents

1.Product Specification Sheet(Page1-7)

2.Instruction Manual(Page8-15)

3.Troubleshooting Procedure(Page16-21)

4.MSD3463 Software Upgrades(After Service)(Page22-31)

5.Circuit Diagram(Page32-39)

6.Exploded View(Page40-41)

7.Styling Sheet(Page43-47)

8.IR Board&Key Board Circuit diagram(Page48)

9.Key Board Silk Printing Schematic(Page49-50)

10.IR Board Silk Printing Schematic(Page50-51)

11.Main Board Silk Printing Schematic(Page52-55)

12.Main Board System Frame Diagram(Page 56)

13.The Main Board Interface Function(Page57-62)

Product Specification Sheet 32"HDDTV(32L92F-DVB) 43"FHD DTV(43L91F-DVB)

Series name 32PHT4001/60 43PFT4001/60

Processortype (CPU)/ GPU

Picture/Display

RC 7601-32E232-0244FLP1 7601-32E232-0244FLP1

Backlight Type (PanelSupplier) DLED DLED

DiagonalScreenSize 31.5" 42.51

Perfect Motion Rate 1360×768@60Hz 1920×1080@60Hz

PanelFrequency(Native) 60HZ 60HZ

ChasisFrequency 60HZ 60HZ

Backlight DimmingPWM PWM

ScanningSegments(amount) 48.25--863.25MHZ 48.25--863.25MHZ

PanelResolution 1366*768 1920*1080

Aspect ratio 16:9 16:9

Brightness(Home VividMode)cd/m²Min:160cd/m2,Typ:190cd/m2

(LCM:Min:200cd/m2,Typ:240cd/m2

)

Min:180cd/m2,Typ:210cd/m2

(LCM:Min:220cd/m2,Typ:260cd/m2)

Panelcontrastratio 1200:1 1200:1

ViewingAngle -H (L+R) 176°176°

ViewingAngle -V 176°176°

ResponseTime (ms) 8ms 8ms

Analog +PWMdimmingYES YES

2D/3D Logic (2D/3DActive/3DPassive)2D 2D

ColorGamut NTSC65% NTSC 65%

PQengine DigitalCrystalClear DigitalCrystalClear

PQResolutionN/A N/A

3D features N/A N/A

Improved 3D SuperResolution N/A N/A

ISFColorManagement N/A N/A

DigitalNaturalMotion (2D/3D)N/A N/A

Perfect NaturalMotion (2D/3D)N/A N/A

2D to 3D Conversion N/A N/A

3D Depth adjustment (Auto/Offset) N/A N/A

Auto 3D Detection N/A N/A

Micro DimmingDemo N/A N/A

Micro Dimmingmode N/A N/A

DualView(2PlayerFull Screen

Gaming/Video)N/A N/A

Supported DisplayResolution(Computer

Inputs) 720*400@70HZ

640*480@60HZ

800*600@60HZ

1024*768@60HZ

1360*768@60HZ

720*400@70HZ

640*480@60HZ

800*600@60HZ

1024*768@60HZ

1360*768@60HZ

1280*720@60HZ

1280*960@60HZ

1280*1024@60HZ

1600*900@60HZ

1920*1080@60HZ

Supported DisplayResolution(Video

Inputs) 480i, 480p,576i,

576p,720p,1080i,1080p(24/25/30/5

0/60Hz)(anythinglargerthan

displaysizewillbe reducedto HD

format)

480i,480p,576i,

576p,720p,1080i,1080p(24/25/30/5

0/60Hz)

Brightness(Shop Vivid mode: 10%boost) YES(1%boost) YES(1%boost)

PixelPlusLink(I/II/III) N/A N/A

ActiveControlN/A N/A

Product Specification Sheet 32"HDDTV(32L92F-DVB) 43"FHD DTV(43L91F-DVB)

NaturalMotion/Perfect NaturalMotion N/A N/A

"UHD Display"-logo(Industry) N/A N/A

"UHD Receiver"-logo(Industry)-pending

std

N/A N/A

HDMI2.0 4:4:4 @60p N/A N/A

10-bitcolorsupport N/A N/A

DAPQ N/A N/A

Ambilight

Ambilight Version N/A N/A

Pixels N/A N/A

Ambilight Performance (nit, noofcolors,

halo length) N/A N/A

Ambilight Features(Wall colouradaptive,

LoungeLightMode, Ambilight Motion,

Gaming Mode)

N/A N/A

Ambilight for3D N/A N/A

Ambilight forall TVEvents N/A N/A

Ambilight Open Source via N/A N/A

Wall Distance Adaptive(Stand vsMount) N/A N/A

Motion Adaptive N/A N/A

Built-in AL + Hue N/A N/A

TVasLamp(s)in Hue ecosystem N/A N/A

Inscreen demo in mobile shop app N/A N/A

AmbiWakeup (refHTV) N/A N/A

Ambimusic N/A N/A

Sound (TV)

Sound (Internal)

Output Power(10%THD)RMS 16W 16W

Speakerconfiguration 8W+8W 8W+8W

Speakersystem 2.0 2.0

Speakertype built-in(normal) built-in(normal)

Auto VolumeLevelier/ Auto Volume YES YES

Sound Claim(Incredible

Surround/Cinema Surround/Clear

Sound/AmbiwOOx/3DMovie/Incredible

Surround

3D)

N/A N/A

Bass(Basscontrol/DBE/UltraBass/Ultra

BassII)N/A N/A

WirelessSound Interface N/A N/A

DolbyDigitalDecoderType YES YES

DTSStudioSound N/A N/A

DTS2.0+ Digitalout N/A N/A

AcousticCompensationFiltersN/A N/A

DynamicTreble Enhancement N/A N/A

ProgrammableBass AndTreble Curve N/A N/A

VisibleSound N/A N/A

Sound (External)

ExternalSound device type N/A N/A

Output Power(10%THD)RMS N/A N/A

Design Specs

Standtype(Swivel/non Swivel)PlasticWing MetalWing

Frame Blackmetal(with keybutton

silkprint)

Blackmetal

RearBoard Black metal Blackmetal

Rearcover black plastic blackplastic

I/Oportto be clearlyindicatedTV*1/USB*2/VGA*1

/HDMI*3/MiniYPBPR*1/

AV-IN*1/CI*1/Earphone*1/

Coaxial-OUT*1

TV*1/USB*2/VGA*1

/HDMI*3/YPBPR*1/

AV-IN*1/CI*1/Earphone*1/

Coaxial-OUT*1

LocalKeyboardNO YES

Product Specification Sheet 32"HDDTV(32L92F-DVB) 43"FHD DTV(43L91F-DVB)

PhilipswordmarkPHILIPS PHILIPS

LeadingEdge #7 #7

Vesa WallMount CompatibleYES YES

Compatible Wall Mount 100mm×100mm 200mm×300mm

POSlabel

Connectivity(I/O)

HDMINumberHDMI1.4(*3) HDMI1.4(*3)

HDMI1.4a HDMI(Under-out) HDMI(Under-out)

HDMI2.0 N/A N/A

HDMI/DVI YES YES

HDMIARC HDMI-3 HDMI-3

EasyLink(HDMI-CEC) NO YES

Scart(EU)Connections N/A N/A

YPbPr/CVI (EU/Latam)Connections N/A N/A

CVBS (EU/Latam)Connections *1 *1

AudioL/Rin *1 *1

CI+slots *1 *1

Antenna *1 *1

Satellite (forK&Sonly) N/A N/A

USB USB2.0(*2) USB2.0(*2)

USBHarddiskFormat (Power) FAT/NTFS(500mA) FAT/NTFS(500mA)

VGA YES YES

VGA/DVIAudio Input share Audio L/R in share AVaudio input

Digitalaudio out (SPDIF) N/A N/A

Headphone *1 *1

Ethernet-LANRJ-45 N/A N/A

ServiceConnector VGAconnectable VGAconnectable

Wirelessconnections N/A N/A

Wi-FiBand Concurrent N/A N/A

WoWLAN N/A N/A

WoLAN N/A N/A

Bluetooth forsubwoofer/RC (donotclaim

commercially) N/A N/A

MultichanneloverBT N/A N/A

HDCPv2.2 (on HDMI2.0 port) N/A N/A

MHL (HDMI+power+returnchannel) YES YES

Wi-fiMiracastCertified (HDCP2.2

supported)

N/A N/A

GoogleCast Receiver N/A N/A

Tablet ScreenMirroring(Wi-FiMiracast) N/A N/A

TADAppFTAchannels(free app) N/A N/A

TADServer, FTAchannel N/A N/A

Indep. Watching(TV&PVR), FTA&CI+ N/A N/A

SAT>IPClient, FTA N/A N/A

HEVC@FHD 60Hz N/A N/A

HEVC@UHD 60Hz N/A N/A

H264 @UHD N/A N/A

VP9 @UHD N/A N/A

UI &Interaction

Ux(Basic:without Dashboard, Advanced:

with Dashboard)Basic Basic

AnimationsN/A N/A

DraganddropN/A N/A

RemoteControlVersion (state ifinclude

Keyboard/Pointer) N/A N/A

Sensor.accelerometer&sensor

gyroscope

N/A N/A

Easyaccess toeDFU(Bluekey)N/A N/A

Product Specification Sheet 32"HDDTV(32L92F-DVB) 43"FHD DTV(43L91F-DVB)

TextEntry(Basic : Text Entryvia HID

and/orOn-screenKeyboard) Basic Basic

Multi-viewN/A N/A

Multi-taskN/A N/A

Screen Format Adjustments4:3,16:9,film,PC Mode(HDMI) 4:3,16:9,film,PCMode(HDMI)

DualScreen (TVandTeleText)N/A N/A

Teletext YES YES

e-Sticker N/A N/A

PriorityChannelList N/A N/A

ChannelCloningvia USB N/A N/A

Logo Editor(ChannelEditor) N/A N/A

ChannelMatrixwithEPGdata N/A N/A

ChannelScanning(Australia/NZ) N/A N/A

TimeZone(Australia/NZ) N/A N/A

PCSorting N/A N/A

Intelligent SourceList N/A N/A

On-screen Remote(via HDMI) N/A N/A

Cold boot to broadcast N/A N/A

Cold boot to onlinedashboard N/A N/A

Warmboot to broadcast N/A N/A

Warmboot to onlinedashboard N/A N/A

ZappingOSD with EPGdata N/A N/A

Electronic ProgramGuide (IP&

Broadcast)

N/A N/A

8DaysElectronicProgramGuide YES YES

LiveSettingAssistant (include PQlevel)N/A N/A

SignalStrengthIndication YES YES

Pause TV/USB recording(PVR)YES YES

Two simultaneousrecordingsinstdbyN/A N/A

UI LanguagesRussian(default), English Russian(default), English

MemoryProfile (DRAM)128M 128M

Menu Layout UpdateN/A N/A

Wizards(Ease of Installation)N/A N/A

Single SignOn(googlea/conly)N/A N/A

Personalized Dashboard N/A N/A

Face recognition N/A N/A

Shopmode 2015N/A N/A

CloudTVapp contentin searchand

Dashboard (onTV) N/A N/A

Firmware Upgradeable YES YES

Multimedia Applications

Video PlaybackFormatsMPEG-2/MPEG-4 /H.264 MPEG-2/MPEG-4/H.264

SubtitlesFormatsSupport SRT ASS SRT ASS

MusicPlaybackFormats MP3，AAC MP3，AAC

PicturePlayback Formats JPEG BMP PNG JPEG BMP PNG

SmartTV N/A N/A

SoftwarePlatform N/A N/A

Android Home Page N/A N/A

AndroidOS N/A N/A

UI Resolution N/A N/A

GoogleVoiceSearch N/A N/A

GoogleHangouts N/A N/A

RemoteControl N/A N/A

Gesture N/A N/A

Pre-installed GoogleApps(Google

Search, GoogleHangouts, Google Play

Movies,Google PlayMusic, Youtube)

N/A N/A

Product Specification Sheet

Basic

Performance Profile N/A N/A

Google

Play N/A N/A

Memory

sizeto

installapps N/A N/A

Extendable USB

storagefor

App N/A N/A

Smart

Experience N/A N/A

DLNA1.5

DMR, DMP N/A N/A

DLNA1.5

DMS N/A N/A

MultiRoom

Client, FTA+Scrambled Non-

Copy

Protected &CI+ N/A N/A

MultiRoom

Server, FTA+Scrambled Non-

Copy

Protected &CI+ N/A N/A

PVR

Auto Recording (IP-EPG) N/A N/A

API -access

control N/A N/A

xTV

Support N/A N/A

Rich UserInteraction N/A N/A

Smart Home N/A N/A

4kphoto support in

Android apps N/A N/A

4kphoto support in

Picture apps N/A N/A

4kphoto support inUSB/DLNA N/A N/A

UHD

content playback

fromall

sources

(USB,DLNA,web) N/A N/A

NextFlix

UHD N/A N/A

Youtube UHD N/A N/A

Google

PlayUHD N/A N/A

Smart TV

with Broadcast PIP;

single

video

N/A N/A

SMART

TVoffline

content

(cached) N/A N/A

MPEG-DASH (CENC

CFF) N/A N/A

HLS N/A N/A

Wakeup from

APP N/A N/A

Preinstalled

Apps N/A N/A

Netflix* N/A N/A

YouTube Leanback

(HTML5)* N/A N/A

Spotify* N/A N/A

BBC

iPlayer* N/A N/A

Skype N/A N/A

Skype Cowatch (mixaudio) N/A N/A

Cloud Explorer N/A N/A

Cloud TV N/A N/A

Smart TV

Services N/A N/A

Social

Apps N/A N/A

GameDashboard in Google launcher N/A N/A

OpenGL Games N/A N/A

Playstation Now

App N/A N/A

OnLive

App N/A N/A

STA

3.0 &4.0

Clients N/A N/A

STAshared App store N/A N/A

Camera&MicAPI N/A N/A

TVasan app (Verimatrix, etc) N/A N/A

Companion Apps N/A N/A

PhilipsTVRemoteApp N/A N/A

Sharing in Remote App N/A N/A

Ambilight TVApp N/A N/A

Ambilight+Hue App N/A N/A

UserManualApp N/A N/A

ChannelEditor - PC Client App N/A N/A

Mobile app forin-shop (coverMRA/Demo

Me/SRC functionN/A N/A

Product Specification Sheet 32"HDDTV(32L92FDVB) 43"FHD DTV(43L91F-DVB)

Proximitybased

shop app activation

(BTLE/NFC/QR tbc) N/A N/A

MyRemote App (Old

TVRemote App) N/A N/A

Ambilight Lounge App N/A N/A

Broadcast/Certification

DVB-T/C N/A N/A

DVB-S/S2 N/A N/A

DVB-T/T2 YES YES

DVB-C2 N/A N/A

SBTVD-T

(Brazil) N/A N/A

SATVD-T

(Argentina) N/A N/A

Analog (LATAM/APMEA) PAL

SECAM PAL SECAM

Nicam

(APMEA) N/A N/A

Enhanced

SSU N/A N/A

ItalyHD

Book2.1.1

(GOLD) N/A N/A

HD-Book

Italy 3.0

(HEVC@FHD) N/A N/A

UKD Book

7a N/A N/A

Freeview

(UK) N/A N/A

FreeviewHD

(UK) N/A N/A

MHEG5 N/A N/A

TiVuON

(IT) N/A N/A

TNT

(FR) N/A N/A

Argentina Ginga -NCL N/A N/A

Brazil

Ginga (A/B)N/A N/A

Video

Playback N/A N/A

DualCam

(CI+) N/A N/A

Dual

Tuner N/A N/A

CI+1.4

Multistream

CAM N/A N/A

CI+1.3CAM N/A N/A

HBBTV1.5 N/A N/A

HBBTV2.0 N/A N/A

MHP N/A N/A

Ziggo Interactief N/A N/A

3D DVB

Phase1 N/A N/A

3D signalingbits

in broadcast N/A N/A

Background update installation N/A N/A

Marlin/ Play

ready N/A N/A

Sustainability/Power

PVC/ BFR FreeOptional Optional

Mercury

FreeOptional Optional

Cabinet

Resin SGCC SGCC

Eco-FlowerCertified N/A N/A

ECO

Mode

N/A N/A

Mains

Power

AC100-240V50/60Hz AC100-240V50/60Hz

Standby

Power <0.5W <0.5W

QuickStartup NA NA

NetworkStandbymode (max6W)NA NA

Off Mode Power<0.5W <0.5W

On Mode Power (Consumption Power) 55W(max.) 75W(max.)

Auto Switch-Off TimerYES YES

Green packaging (Non-EPS)YES YES

Light SensorNA NA

PictureMute (ForRadio)N/A N/A

EUEnergyLabel(A++/A+/A/B) - NA NA

non-EUEnergyLabel-StandbyLabel NA NA

BlauerEngel(Germany) NA NA

Product Specification Sheet 32"HDDTV(32L92F-DVB) 43"FHD DTV(43L91F-DVB)

Accessory

By-packedaccessories

Active

Glasses(509) N/A N/A

Active

Glasses(529) N/A N/A

Passive Glasses(PTA417)N/A N/A

Dual

Gaming Glasses N/A N/A

Woofer (e.g.

SWB50)

with

Soundbeam N/A N/A

Sound Bar N/A N/A

Detachable speakerbaseN/A N/A

Wirelessaudio adaptor

N/A N/A

Wi-Fi

Adapter(PTA01/00/PTA127/55)N/A N/A

Skype Camera (PTA317)N/A N/A

Table

Stand YES YES

Accessory

Bag YES YES

Mains

Cord (EU/UK/Brazil/APMEA) YES YES

RemoteControl

+2x

Philips

Batteries YES YES

Printed QSG YES YES

Printed DFU (APMEA) YES YES

SafetyLegal

Leaflet

(EU)

-3D Health

Advise and

Ukraine requirement N/A N/A

Philips

WarrantyLeaflet YES YES

Optionalaccessories

Active

Glasses(PTA509/529) N/A N/A

Passive Glasses(PTA419)N/A N/A

Dual

Gaming Glasses

(PTA436) N/A N/A

Wi-Fi

Adapter(PTA01/00/PTA127/55)N/A N/A

Skype Camera (PTA317)N/A N/A

Table

Top Stand N/A N/A

Speaker

stand N/A N/A

Others N/A N/A

Certification

DolbyDigital/Dolby

Digital

Plus/Dolby N/A N/A

DTS2.0+

Digitalout

DTS

Premium

Sound

DivX

WMA

Wi-Fi N/A N/A

DLNA

Certified (DMR/DMP/DMS)

SKYPE

HDMI

MHL

Dimensions (WxHxD)

Unit with

stand 732*472*187mm 970*614*219mm

Unit without stand 732*430*73mm 970*564*74mm

Carton 835*514*140mm 1085*667*150mm

Wall-mount 100mm×100mm 200*300

Weight

Product without Stand 3.8kg 8.3kg

Product with Stand 4kg 8.5kg

Product in Packaging 5.5kg 10.5kg

32PFT4001/60 43PFT4001/60

This manual suits for next models

Table of contents

Other Philips TV manuals

Philips

Philips 21PT134B User manual

Philips

Philips The One 8558 Series User manual

Philips

Philips 26-LCD DIGITAL WIDESCREEN FLAT TV PIXEL PLUS... Reference manual

Philips

Philips 42PF5421D Quick start guide

Philips

Philips 9206 Series User manual

Philips

Philips 29PT9008 User manual

Philips

Philips 49HFL7011T User manual

Philips

Philips 20GR1250 User manual

Philips

Philips 8536 Series User manual

Philips

Philips 37PF9975 User manual

Philips

Philips 20PFL4122/93 User manual

Philips

Philips 42PF1000/62 User manual

Philips

Philips 20HF5335D User manual

Philips

Philips 20/26/32HF5335D User manual

Philips

Philips Magnavox PR 1906C User manual

Philips

Philips 65PFL6621/F7 User manual

Philips

Philips Color television User manual

Philips

Philips 6605 Series User manual

Philips

Philips OLED706 Series User manual

Philips

Philips 19PFL5402D User manual

Philips

Philips 30PF9946 Configuration guide

Philips

Philips 21HT3504 User manual

Philips

Philips 8100 series User manual

Philips

Philips 4000 series User manual

Popular TV manuals by other brands

Toshiba

Toshiba 27A10 owner's manual

Hitachi

Hitachi 32FX48B operating guide

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Service manual

Changhong Electric

Changhong Electric uhd55b6000is Operation manual

Panasonic

Panasonic Genus TX-G10 operating instructions

Toshiba

Toshiba 19A20 Service manual

Sony

Sony XBR-100Z9D reference guide

Samsung

Samsung 55S9 B Series Quick setup guide

Sharp

Sharp LC-40FI5012E user manual

Loewe

Loewe Table Stand Reference 55 user guide

Sylvania

Sylvania 6427FB owner's manual

Sanyo

Sanyo CE19LD90N-B instruction manual

North State

North State TV2GO user guide

RCA

RCA RTU7877 instruction manual

Sharp

Sharp 21K-FG1RU Operation manual

Sony

Sony Esprit TAV-L1 operating instructions

Grundig

Grundig 43 VLE 4820 user manual

Samsung

Samsung LN26C350D1D Service manual
