Philips SWV3052 User manual

Turn up your viewing experience

with this 3-way manual switcher

Step up to a better connection for transferring audio/video signals between your

components.

Enjoy better picture quality

• 24 carat gold-plated connectors optimise signal

Enjoy better audio quality

• High-purity copper conductor for reliable signal transfer

• 24 carat gold-plated connectors optimise signal

Protects against signal loss

• Copper-braided reinforced aluminium shielding

Easy installation

• Plug and play for easy use

• Colour-coded connectors for instant recognition

Enjoy extended durability

• Protective metal shell for extended durability

• Flexible PVC jacket

• Rubber strain relief

Philips

Manual switcher

3-Way

Composite A/V Connections

SWV3052

SWV3052/10

Manual switcher

3-Way Composite A/V Connections

Specifications Product highlights

Inner Box

•EAN/UPC/GTIN: 87 10895 96137 0

•Quantity: 10

•Gross weight: 7.47 kg

•Tare weight: 0.37 kg

•Net weight: 7.10 kg

•Length: 405 mm

•Width: 190 mm

•Height: 240 mm

Outer Box

•EAN/UPC/GTIN: 87 10895 96138 7

•Quantity: 20

•Gross weight: 16.04 kg

•Tare weight: 1.1 kg

•Net weight: 14.94 kg

•Length: 550 mm

•Width: 420 mm

•Height: 330 mm

Dimensions

•Gross weight: 0.71 kg

•Tare weight: 0.08 kg

•Net weight: 0.63 kg

•Product length: 28 cm

•Product dimensions (W x H): 190 x 55 mm

•

Issue date 2008-10-11

Version: 4.0.5

12 NC: 9082 100 06249

EAN: 87 10895 93378 0

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

High-purity copper

This copper conductor provides high accuracy in signal

transfer with minimal resistance.

24 carat gold-plated connector

24 carat gold-plated connectors ensure the best signal

quality for your components.

Braided shielding

Copper-braided reinforced aluminium shielding protects

against signal loss and interference.

Metal shell

The metal shell protects the internal connection of the

cable. It ensures durability and reliability of your

connection.

Flexible PVC Jacket

Flexible PVC jacket provides protection to the delicate

core of the cable. It also offers extended durability and

ease of installation.

Colour-coded connectors

Colour-coded connections make it easy to install your

cable into the correct inputs and outputs
