Philips SLA5500 User manual

SLA5500

User manual 4

Need help?

User Manual

See the user manual that came with your Wireless Music

Receiver.

Online help: www.philips.com/support

For downloads and frequently asked questions

Contact line:

Country Telephone number

Austria ..................................................01 546 575 603

Belgium.................................................02 275 0701

Canada..................................................Eng./Esp.: 1-888-PHILIPS (744-5477)

Fra.: 1-800-661-6162

Denmark..............................................3525 8761

Finland...................................................09 2290 1908

France....................................................03 8717 0033

Germany..............................................0696 698 4712

Greece..................................................0 0800 3122 1223

Ireland...................................................01 601 1161

Italy..........................................................02 4827 1153

Luxemburg.........................................26 84 30 00

Netherlands.......................................053 482 9800

Norway................................................2270 8250

Portugal................................................2 1359 1440

Spain.......................................................91 745 6246

Sweden.................................................08 632 0016

Switzerland.........................................02 2310 2116

UK...........................................................0207 949 0069

USA.........................................................1-888-PHILIPS (744-5477)

4Contents

5Important information

5Safety precautions

6What’s in the box

7System requirements

8Functional overview

10 Navigating the menu

12 Preparing Your PC

12 Installing Philips Media Manager

13 Installing the Philips Wireless Music Receiver PC Utility

17 Installing your SLA5500

18 Configuration

19 Configuration Wizard Menu

20 Changing network settings

22 Operation

22 Listening to Music Files

24 Saving Music Items

26 Advanced Configuration

26 Configuration Menu Structure

28 Managing Network Profiles Using the Remote Control

29 Managing Multiple Key Indexes

31 Advanced Configuration Using Philips Wireless Music Receiver PC Utility

32 Default Profile Settings

34 Uploading New Software to the SLA5500

35 Troubleshooting

36 Glossary

37 Extra information

38 Guarantee

Contents

•Awireless network adapter or a wireless base station is required when integrating your

SLA5500 in a wireless computer network.

•Please install and connect the product in the order described in this manual only. This

assures best installation results with the least technical hassles.

•Please read this guide carefully before using your SLA5500 and keep it for future

reference.

•The most recent downloads and information on this product will be available through

our website www.philips.com/support

•Please check whether your Internet service provider charges extra fees for exceeding a

certain limit of transferred data. When using Internet media services on a daily basis, you

may exceed such a limit.

•During set-up and installation, it may be helpful to have the instructions for your audio

system, wireless base station or other wireless network components at hand.

Safety Precautions

•NEVER MAKE OR CHANGE CONNECTIONS WITH THE POWER OF YOUR

AUDIO SYSTEM SWITCHED ON OR YOUR SLA5500 CONNECTED TO THE

MAINS.

•Before operating the SLA5500, check that the operating voltage indicated on the

nameplate of your SLA5500 is identical with the voltage of your local power supply.

If not, please consult your dealer.

•Radio equipment for wireless applications is not protected against disturbance from

other radio services.

•The SLA5500 should not be exposed to dripping or splashing.

No object filled with liquids, such as vases, should be placed on the product.

•Do not expose the SLA5500 to excessive moisture, rain, sand or heat sources caused by

heating equipment or direct sunlight.

•Allow a sufficient amount of free space all around your SLA5500 for adequate

ventilation.

•Do not open this product. Contact your Philips retailer if you experience technical

difficulties.

•Place the SLA5500 on a flat, hard and stable surface.

When the SLA5500 is switched to standby mode, it is still consuming some power.

To disconnect the SLA5500 from the power supply completely, remove the AC power

plug from the wall socket.

•Make sure the air around your SLA5500 can circulate to prevent your SLA5500 from

overheating internally. Also, avoid putting any heat sources (e.g. a power amplifier)

underneath.

•To prevent your SLA5500 from overheating internally, never place anything on top of it.

Important information

Please check whether the following items are present in the box of the Wireless

Music Receiver. They are provided to help you set up and use your SLA5500.

SLA5500 Wireless Music Receiver

Remote control including batteries (2x AAA)

Power adapter (110V or 200-240V) including cable adapter and power cable

Stereo RCA to 1/8” connector cable

CD-ROM containing:

•This User manual

•Philips Media Manager software

•Wireless Music Receiver PC Utility

Quick start guide

What’s in the box

System requirements

Audio

Audio system (e.g. amplifier, VCR, DVD etc) with auxiliary (AUX) inputs

(RCA connection) or an active speaker system

Personal Computer (PC)

•Pentium Class 300MHz processor or better

•128 MB RAM

•150 MB free hard drive space

•CD-ROM drive

•Windows® XP Service Pack (SP) 1

•Microsoft Internet Explorer 5.0 or later

•Wireless or Ethernet network interface card, installed and configured with TCP/IP

Network

•Wireless connection (WiFi 802.11b/g compatible) from the Wireless Music

Receiver to a PC, base station or both.

Network Environments Supported

Network Environment Description

Infrastructure • Wireless Base station (BS)

•PC with connection to base station

•SLA5500 connects wirelessly to BS

Peer-to-peer (Ad Hoc) • No Wireless Base station (BS)

•PC with wireless card

•Wireless Music Receiver connects

wirelessly to PC

Functional overview

Wireless Music Receiver

1Infrared sensor

Receives the signals from the remote control

2LCD screen

Displays menu status for easy navigation through music library and system settings

3Stereo 1/8” connector cable socket

4Power adapter cable socket

5Reset hole

Remote Control

1HOME

Displays the top level menu.

Turns on the SLA5500 when the SLA5500 is switched in Standby mode.

20-9 digit buttons

Play the item stored on the preset number selected (0 to 9).

In Edit mode: Key 0-9 is used to enter numbers and/or characters (ex: 2abcABC).

Key 1 is also used for special symbols (1 . , ? ! - & * # _ ~)

3PRESET

Press this button followed by one of the number buttons (0-9) to store the currently

selected item against the preset number selected.

4(UN)MARK

Press this button once to add the song currently playing to the Dynamic Playlist.

When playing Dynamic Playlist: press to remove from Dynamic Playlist.

53(UP)

Scrolls up through the current menu list (hold the button down to scroll faster)

In Edit mode: enter or change characters by scrolling up through the ASCII character

table.

4(DOWN)

Scrolls down through the current menu list (hold the button down to scroll faster)

In Edit mode: enter or change characters by scrolling down through the ASCII

character table.

1(LEFT)

Moves up one level up in the menu hierarchy on the LCD display.

Example: if artist is displayed, pressing Left returns you to the PC Files menu.

In Edit mode: Moves the cursor to the left, one character at the time.

2(RIGHT)

Selects the current highlighted menu item

Example: If the currently displayed item is an album, pressing Right will display a list of

all songs of that album

In Edit mode: Moves the cursor to the right, one character at the time and confirms

inputs.

6SYSTEM

Displays the top level of the Configuration menu.

7SHUFFLE

Toggles between random and ordered playback modes in the current folder.

Note: The selected mode is stored permanently until you press the Shuffle button again or

until the products will be switched off (StandBy mode).

8REPEAT

Press this button once to repeat only the song that is currently playing (only applies

to PC music files). The Repeat icon is displayed on the LCD screen.

Press again to repeat all songs of the currently selected item.

The Repeat All icon is displayed on the LCD screen.

Pressing again will return to Normal Play.

99(STOP)

Stops playing the current item.

10 ∞(previous/rewind)

Press this button once to jump to the previous song in the playlist, album or artist.

If it reaches the beginning of a list, it wraps around to the end of the list.

In Edit Mode: Press this button to delete one character at a time (backspace).

11 ;/2(pause/play)

Press this button once to play the currently selected item (playlist, album, artist,

genre or song file). Information about the current item is displayed on the screen

Press again while the song is playing to pause the song.

To continue playing an item that has been paused, press ;/2again.

12 §(next/fast forward)

Press this button once to jump to the next song in the playlist, album or artist.

If it reaches the end of a list, it wraps around to the beginning of the list.

Press and hold the button for more than 1 second to fast forward the current song.

Play recommences when the button is release.

13 – E+ (Volume Up/down)

Increases (+) and decreases (–) the volume.

14 INFO

Displays additional information on the currently selected music file.

Pressing the button again enables a return to the default item display.

15 s(Mute)

Mutes the sound.

16 OK

Selects the current highlighted menu item

Example: If the currently displayed item is an album, pressing OK will start playing

that album.

17 PLAY LIST

Displays the Dynamic Playlist that is stored on the SLA5500.

The list may contain up to 20 items

18 JUMP TO

Activates Jump To function (character based keys (0-9) will be activated).

19 yy(On/Standby)

Turns on the Wireless Music Receiver.

Pressing the button again turns the device off (the device is then in ‘standby’ mode).

Home

Favourites

Server 1 [MM]

Server 2 [MM]

Playlist

Nick Ferry

Best of ABBA

Leila

....

Configuration

Device Status

Configuration Wizard

Select Language

Advanced Settings

Configure Date/Time

Select Profile

Navigating the menu

The SLA5500 has a built-in LCD screen. Together with the remote control device,

it enables easy operation.

LCD Menu Structure

The menu displayed on the Wireless Music Receiver LCD screen is organized as a

hierarchy, enabling you to access the:

•Home menu

•ADynamic Playlist of music files (if available)

•Music files stored in your Philips Media Manager Library

(multiple servers may be visible)

•Configuration menu

The exact menu structure will depend on your network environment and how your

music library is organised on your personal computer.

A top level LCD menu structure could look like this:

Home

Press the HOME button (1)

at any time

See Music Files Menu for more details

Configuration

Press the SYSTEM button (6)

at any time

See Configuration Menu for more details

This manual suits for next models

Table of contents

Other Philips Stereo Receiver manuals

Philips

Philips HTR9900/12 User manual

Philips

Philips LX600/69 Operating manual

Philips

Philips MX-1015 User manual

Philips

Philips US2-PH61153 User manual

Philips

Philips FR996/00S User manual

Philips

Philips FR752/00 User manual

Philips

Philips LX600/01 Operating manual

Philips

Philips LX600 User manual

Philips

Philips DFR150017 User manual

Philips

Philips FR735 User manual

Philips

Philips FR965/00 User manual

Philips

Philips LX710/01 User manual

Philips

Philips HTR9900/12 User manual

Philips

Philips HTR5205/98 User manual

Philips

Philips FR999/17 User manual

Philips

Philips HTR3465/98 User manual

Philips

Philips MX990DHT User manual

Philips

Philips SLA500 User manual

Philips

Philips LX 8000SA Operating manual

Philips

Philips MX-1055D User manual

Philips

Philips FR-963 User manual

Philips

Philips HTR5204/12 User manual

Philips

Philips LX600/69 User manual

Philips

Philips FR 911 User manual

Popular Stereo Receiver manuals by other brands

Marantz

Marantz CINEMA 70S owner's manual

Kenwood

Kenwood KMDX92 instruction manual

Yamaha

Yamaha RX-830 owner's manual

Pioneer

Pioneer AVH-Z7250BT owner's manual

Yamaha

Yamaha RX-750 owner's manual

Denon

Denon AVR-1311 owner's manual

Denon

Denon AVR-S760H owner's manual

Denon

Denon AVR-X7200W Service manual

Pioneer

Pioneer SC-LX904 Initial setup guide

Sony

Sony XAV-1500 operating instructions

Radio Shack

Radio Shack DX-399 owner's manual

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver operating instructions

Pioneer

Pioneer SX-1000TA operating instructions

Yamaha

Yamaha MusicCast TSR-5B3D owner's manual

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver operating instructions

Sony

Sony STR-DG500 - Multi Channel Av Receiver Service manual

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Brochure & specs

Pioneer

Pioneer SX-838 Service manual
