Philips 60PL9220D User manual

Philips

projection HDTV with

Pixel Plus

60"

DLP™

60PL9220D

Turn up your viewing experience

with Integrated HD DLP Projection TV

Be an eyewitness

• High definition Projection TV with DLP™ technology

• Pixel Plus for detail, depth and clarity

• Enjoy HDTV that's truer than anything you've seen before

• 3D combfilter separates colors for a razor-sharp image

Unrivalled audio performance

• Dolby Digital for movies or concerts in full surround sound

One touch convenience

• PiP allows watching a second source simultaneously

• Auto Picture to personalize your viewing

• Auto Sound uses pre-defined sound settings for better sound

• A choice of widescreen modes to adjust the picture shape

Leading interface for digital quality audio/video

• HDMI input for full digital HD connection in one cable

• Component Video Input for top quality playback

60PL9220D/37

Highlights

Projection HDTV with Pixel Plus

60" DLP™

Pixel Plus

Pixel Plus is a digital picture processing

technology that increases the number of lines

and the number of pixels. The result is razor

sharp pictures with incredible detail and depth,

every time from any source.

HDTV

HDTV delivers exceptional picture quality and

real movie-viewing experience that makes

television more dynamic, truer than anything

you've seen before. It is the latest and best

television signal available. It features picture

quality more than twice that of traditional

analog broadcasts. In order to effectively

maximize the HDTV signal, a television must

incorporate advanced signal input connectivity

and circuitry design.

3D Combfilter

The 3D comb filter separates brightness and

color signals better in 3D domain to eliminate

cross-color, cross-luminance and dot-crawl

distortion - all of which detract from your

viewing pleasure. The 3D digital comb filter

performs field-by-field comparisons of the

television image to accurately separate the

color from the black-and-white information

and remove both horizontally and vertically

hanging dots, as well as dot crawl. The result is

a razor sharp image.

Dolby Digital Surround

Because Dolby Digital and DTS, the world's

leading digital multi-channel audio standards,

make use of the way the human ear naturally

processes sound, you experience superb

quality surround sound audio with realistic

spatial cues.

Picture In Picture (PIP)

Provides the ability to watch simultaneously

two different sources, either two video

sources or a combination with data/graphics

HDMI input

HDMI makes an uncompressed digital RGB

connection from the source to the screen. By

eliminating conversion to an analog signal, it

delivers an unblemished image. The non-

degraded signal reduces flicker and leads to a

clearer picture. HDMI intelligently

communicates the highest output resolution

with the source device. The HDMI input is fully

backward compatible with DVI sources but

includes digital audio. HDMI uses HDCP copy

protection.

Component Video Input (YPbPr)

Component Video is the highest quality

interconnection standard for analog video. It is

sharper than S-video and composite video.

Issue date 2010-12-17

Version: 1.0.5

12 NC: 8670 000 27733

UPC: 6 09585 13963 3

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

60PL9220D/37

Specifications

Projection HDTV with Pixel Plus

60" DLP™

Picture/Display

• Aspect ratio: 16:9

• Visible screen diagonal (inch): 60 inch

• Display technology: Digital Light Processing, DLP

HD5

• Panel resolution: 1280x720 (720p)

• Picture enhancement: 3D Combfilter, Active

Control, Color, Contrast Plus, Digital Noise

Reduction, Pixel Plus, Tint, AutoPicture (5 modes),

Black stretch, Color Transient Improvement,

Luminance Transient Improver, Sharpness

Adjustment

• Color cabinet: Silver Frost & Black

Supported Display Resolution

•Video formats

Resolution Refresh rate

720p 60Hz

Sound

• Output power (RMS): 2 x 10W

• Sound Enhancement: Auto Volume Leveller,

AutoSound (4 modes), Balance, Treble and Bass

Control

• Sound System: Virtual Dolby Surround, Stereo

Convenience

• Ease of Installation: Autostore

• Ease of Use: Channel list

• Remote control type: RCLU026

• Remote Control: TV

• Teletext: Closed Captioning Full Text

• Picture in Picture: 1 tuner PIP

• Screen Format Adjustments: Super Zoom, 4:3, 4:3

expand, Auto Format, Subtitle Zoom, Widescreen,

Zoom 14:9, Zoom 16:9

• Clock: Sleep Timer

• On-Screen Display languages: French, Spanish,

English

Tuner/Reception/Transmission

• TV system: NTSC, ATSC

•VideoPlayback:NTSC

• Aerial Input: 75 ohm F-type

• Cable: Unscrambled Digital Cable -QAM

Connectivity

• AV 1: HDMI, CVBS in, Component Video in

• AV 2: Component Video in, CVBS in

• AV 3: S-Video Y/C, CVBS in

• Front / Side connections: S-video in, CVBS in,

Headphone out

• Audio Output - Digital: AC3 over S/PDIF (Optical)

Power

• Standby power consumption: < 1 W

• Mains power: AC 108 - 132 V, 60 Hz

Dimensions

• Box dimensions in inch (W x H x D):

60.83 x 41.22 x 25 inch

• Weight incl. Packaging (lb): 110.23

• Set dimensions in inch (W x H x D):

54.53x 36.38 x 18.7 inch

• Product weight (lb): 81.57

•
