Philips MB4010T001 User manual

This "exclamation point" calls attention to a feature for which

you should read the enclosed literature carefully to prevent operating

and maintenance problems.

This "bolt of lightning" indicates that uninsulated material

within your unit may cause an electrical shock. For the safety

of everyone, do not remove product covering.

MB4010T001

AutoScan Color Monitor

CAUTION

ATTENTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR

CAUTION TO REDUCE THE RISK OF ELECTRICAL SHOCK DO NOT REMOVE COVER(OR BACK)

NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL

For Customer Use:

Enter below the Serial No. which is located on the

back of the cabinet. Retain this information for

future reference.

Model No. MB4010T001

Serial No.

English Operating Instructions...... 2 - 13

Français Mode d'emploi ……………14 - 25

Appendix

English Declaration FCC ... A1

Information for Users in the U.S. ... A3

Warranty ... A5

Deutsch Hinweis / GS ... A4

Achtung ... A6

Français Declaration FCC ... A2

Introduction

The colour monitor displays sharp and brilliant images of text and

graphics with a maximum resolution up to 1024x768 pixels. It is optimal

for Windows, spread sheets, and any other application.

This monitor automatically scans horizontal frequencies from 30KHz to

54KHz, and vertical frequencies from 50Hz to 110Hz. With

microprocessor based digital controlled circuit, the monitor can

automatically adjust itself to the video card’s scanning frequency and

displays an image with precise parameters you desire. The wide range

of scanning frequency supports variety of operating platforms, such as

IBM PC and compatibles, including Intel based platforms such as 386,

486, Pentium and Pentium Pro.

Feature Highlights

•Global Styling demonstrates a soft & smart image.

•Digital Control feature provides user-friendliness and ease-of-use

when operating the monitor.

•Anti-Glare and Anti-Static screen coating eliminate any bad effects

caused by the screen surface such as reflection of the room lights

and dust attraction.

•85Hz refresh rate:

The maximum display resolution is 1024 x 768 pixels non-interlaced

mode. The recommanded optimum resolution up to 800 x 600 pixels

non-interlaced by maximum 85Hz refresh rate.

•Green Design including automatic power saving function (NUTEK)

and low emission MPRII compliance shows our commitment in

environmental care.

•DDC1/DDC2B allows communication between the monitor and PC

system for optimal video configuration.

Note: If you experienced your monitor display is changing from color

to mono, it's possible that you are using a non-VESA-DDC-standard

video card. Please consult with your local Philips dealer for more

information.

As an Energy Star Partner, MAGNAVOX, has determined that this

product meets the Energy Star guidelines for energy efficiency.

IBM, IBM PC and Power PC are registered trademarks of International

Business Machines Corporation.

Safety precautions and maintenance

◆Disconnect the monitor from the mains supply if the monitor is not

to be used for an extended period of time.

◆Do not attempt to remove the back cover, as you will be exposed to

a shock hazard. The back cover should only be removed by qualified

service personnel.

◆Do not place objects on top of the monitor cabinet, which could fall

into vents or which could cover them and prevent proper cooling of

the monitor’s electronic devices.

Do not expose the monitor to rain or excessive moisture to avoid the

risk of shock or permanent damage to the set.

◆Do not use alcohol or ammonia based liquid to clean the monitor. If

necessary, clean with a slightly damp cloth. Disconnect the monitor

from the mains supply before cleaning.

◆Consult a service technician if the monitor does not operate normally

when operating instructions of this manual are followed.

Package

Your package includes the following items:

•The monitor

•Pedestal

•Power cord

•Interface cable (flying-in)

◆

End of life disposal

Your new set contains materials which can be recycled and reused.

Specialized companies can recycle your product to increase the amount

of reusable materials and to minimize the amount of materials to be

disposed of.

Please inform yourself on local regulations on disposal of your old set.

Installation

Important: Please refer to the user’s manuals of your computer and

video adapter to make sure these equipments are properly installed

and configured before installing the monitor.

Positioning / Ventilation

◆Avoid exposing the monitor to direct sunlight, stoves or any other

heat sources.

◆To prevent overheating, make sure that the ventilation openings of

the monitor are not covered.

◆Keep moisture and dust away.

◆Keep away from any magnetic objects, such as speakers, electric

motors, transformers, ...etc.

◆When positioning this monitor, make sure that the mains plug and

socket are easily accessible.

Pedestal

With the built-in pedestal you can tilt and / or swivel the monitor for a

most comfortable viewing angle.

To fit the pedestal, refer to the illustration on the inside back-cover of

this manual.

Connection

Intel Based platform: 386, 486, Pentium, or other compatibles:

•Connect the monitor to the computer using the supplied interface

cables.

Important: Please make sure the AC power to your computer is

“OFF”before connecting or disconnecting any display peripheral.

Failure to do so may cause serious personal injury as well as

permanent damage to your computer equipments.

1) IBM PC connection

2) Mains connection

Monitor rear view

VIDEO IN

Connection to the mains

(Rear of the monitor)

(Mains cord)

Connecting to the mains

This monitor is set to operate at a mains supply of 100-240 volts AC .

If the mains voltage in your home is not between this, consult your

dealer.

Connect one end of the mains cord to the mains socket at the rear of

monitor, and the other end to the mains supply.

The monitor will be operating in power saving mode if you switch on

your monitor without signal input from PC. (Please refer to Power

Management Signalling instruction.)

VIDEO IN

Front Control locations and functions

POWER.

Press this knob, the green LED lights and the power is ON.

Press this knob again, the green LED disappears and the power

is OFF.

CONTRAST

Used to adjust the picture contrast level.

BRIGHTNESS

Used to adjust the overall screen brightness as a compensation

for ambient light.

"+" or "-"

Press "+" or "-" to adjust the selected function.

For an optimized adjustment of the picture following controls are

available at the front.

The function pads:

H-Shift : to adjust the horizontal position of the image.

H-Size : to adjust the horizontal amplitude of the image.

V-Shift : to adjust the vertical position of the image.

V-Size : to adjust the vertical amplitude of the image.

SHIFT key

To select the level of function.

"Shift" LED off - Control is on first level

"Shift" LED on - Control is on second level

Second level of the function pads:

Trapezoid : to correct the trapezoid distortion of the

image.

Pincushion : to correct the barrel distortion of the image

Recall : to recall original factory preset mode

Remarks:

1. When pressing any function pad, the "Shift" LED will flash

once to indicate the function has been selected.

2. Once the limit of the adjustable range has been reached,

the shift LED will flash continuously.

(A) User mode: (15 modes)

The set will save the user's setting parameters automatically.

After 10 seconds of key-pad inactivity, the LED will flash twice to

indicate the parameters being saved.

Adjustment

The monitor is pre-set with 8 modes for optimal display size and centering

as indicated in the following table:

Resolution Horizontal Vertical

Mode (dots x lines) Freq.(KHz) Freq.(Hz) Remark

VGA 640 x 350 31.5 70 Non-interlaced

VGA 640 x 400 31.5 70 Non-interlaced

VGA 640 x 480 31.5 60 Non-interlaced

VESA/75 640 x 480 37.5 75 Non-interlaced

VESA/60 800 x 600 37.8 60 Non-interlaced

VESA/75 800 x 600 46.9 75 Non-interlaced

VESA/60 1024 x 768 48.3 60 Non-interlaced

VESA/85 800 x 600 53.7 85 Non-interlaced
