Philips AirVibe AS3505/00 User manual

Air quality monitor

AS3500 series

AirVibe

EN User manual 3 ZH-S 使用手冊 17

English

Contents

1 Important 4

Safety 4

2 Your AirVibe 7

Overview 7

3 Getting started 8

Sleep mode 9

PM2.5 Instant mode 9

4 Using your AirVibe 10

Understanding the color ring 11

5 Cleaning 12

6 Troubleshooting 13

7 Guarantee and service 15

8 Notices 15

Electromagnetic elds (EMF) 15

Compliance with EMF 15

Recycling 16

1 Important

Safety

Read this user manual carefully before you use the appliance, and save it for future

reference.

•Keep out of direct sunlight.

•The adaptor for this appliance shouldn’t be used for any other products.

Danger

•Do not let water or any other liquid or ammable detergent enter the appliance to

avoid electric shock and/or a re hazard.

•Do not clean the appliance with water, any other liquid, or a (ammable) detergent

to avoid electric shock and/or a re hazard.

•Do not spray any ammable materials such as insecticides or fragrance around the

appliance.

•Always unplug the appliance from the electrical outlet immediately after using and

before cleaning.

•Keep the cord out of heavy trac areas. To avoid a re hazard never put the cord

under rugs or near heat vents.

Warning

•Do not operate the appliance with a damaged cord or plug or after the appliance

malfunctions or has been damaged in any manner. For assistance, contact Consumer

Care Centre in your country, go to your local Philips dealer.

•Only use the power supply unit provided with the appliance.

•If the power cord is damaged, you must have it replaced by Philips, a service center

authorized by Philips, or similarly qualied persons in order to avoid a hazard.

•When transporting, be careful not to drop the appliance or subject it to shocks.

Continued usage as such could lead to re or electric shock.

English

•This appliance is not intended for use by person (including children) with reduced

physical sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety.

•This appliance is not a toy. Children should be supervised to ensure that they do not

play with the air monitor.

•Do not cover the appliance or block the air inlets.

•Do not soak the product in water.

•Do not place the appliance near heat sources, such as a stove, replace or a gas

appliance and do not expose the appliance to direct sunlight.

•To disconnect, press the power button to switch o the appliance, then remove the

plug from the electrical outlet.

•DO NOT use outdoors. For indoor use only.

•Charge, use and store the appliance in a place where temperature is between 5°C to

35°C.

Caution

•A loose t between the AC outlet (receptacle) and plug may cause overheating and

a distortion of the appliance plug. Contact a qualied electrician to replace loose or

worn outlet.

•Avoid knocking any parts of the appliance with hard objects.

•Do not ll water from the air inlets on top of the appliance.

•Always place and use the appliance on a dry, stable, level, and horizontal surface or

hang on the wall.

•Do not place anything around the appliance nor sit on it.

•Do not place the appliance directly below an air conditioner to prevent condensation

from dripping onto the appliance, or incorrect sensor readings from the cold air

coming out of the air conditioner.

•Place the appliance properly to prevent children from knocking it over or tripping on

the power cord.

•Do not insert your ngers or objects into the air inlet.

•Do not use the appliance near gas appliance, heating devices, or replaces.

•Always unplug and switch o the appliance after use and before you clean it.

•Do not use the appliance in a room or in a vehicle with major temperature changes,

as this may cause condensation inside the appliance or inaccurate sensor reading.

•For residential use, place the appliance at least 2m away from electrical appliances

that use airborne radio waves such as TVs, radios, and radio-controlled clocks to

prevent interference.

•The appliance is only intended for household use under normal operating

conditions.

•The adaptor only can be used for this appliance.

•Only use the adapter supplied.

•Inside laser component classication measurement according to GB7247.1-2012

(released on 2012-12-31).

•Inside laser component can’t be touched or saw by consumer in normal use.

LASER RADIATION

AVOID DIRECT EYE EXPOSURE

CLASS 3R LASER PRODUCT

Max output 5mw, wavelength 650nm,

continuous wave

•For indoor detection, do not place the appliance near the windows or air conditioner which has a strong air convection.

Before detecting the air quality, close the room for ten minutes to get better results. Even in the same place, the

pollutant concentration is dierent at dierent locations, use multi- point detection in your room to get fully

understand of the air condition.

•During the detection, substances that contain alcohol (such as perfume, drinks, rotten vegetables, paint and marker

pens) and sulfur dioxide (such as bactericides and antiseptics) will interfere the sensing results. Interference of such

gases should be avoided. If the appliance has been aected, it is recommended to put the appliance in a clean and

ventilated place for a while before the sensing results are back to normal.

English

2 Your AirVibe

Congratulations on your purchase of Philips rst Wi-Fi connected air quality monitor.

To fully benet from the support that Philips oers, register your product at

www.Philips.com/support.

Read this important information and user manual before you install and use the device.

And save them for your future reference.

Overview

Display screen

Power button

Air inlet

Cable-xing slot

Formaldehyde module

(AS1100, specic type

only) *

Power in socket

Power adapter

Power cord

* You can get additional accessories to get more functionality of your air quality monitor.

•For indoor detection, do not place the appliance near the windows or air conditioner which has a strong air convection.

Before detecting the air quality, close the room for ten minutes to get better results. Even in the same place, the

pollutant concentration is dierent at dierent locations, use multi- point detection in your room to get fully

understand of the air condition.

•During the detection, substances that contain alcohol (such as perfume, drinks, rotten vegetables, paint and marker

pens) and sulfur dioxide (such as bactericides and antiseptics) will interfere the sensing results. Interference of such

gases should be avoided. If the appliance has been aected, it is recommended to put the appliance in a clean and

ventilated place for a while before the sensing results are back to normal.

3 Getting started

Air quality monitor is designed for

monitoring your indoor air quality

continuously, for instant data reading,

make sure the power is always

connected.

It has a build-in battery, in case you

would like to take your air quality monitor

around to make quick measurements.

1 Connect the adapter into the

power-in socket.

2 Connect the power plug to the

power socket.

3 Press the power button to turn on

AirVibe. To turn o AirVibe, press

and hold the power button for

4 seconds.

4 Download the free Ali Smart App

from app stores. You can also

download the App by scanning the

below QR code.

5 Open the Ali Smart App and follow

the on-screen instructions to nd

your product from the category of

air quality monitor. You can also nd

your product by scanning the above

QR code. Follow the on-screen

steps to setup.

English

Sleep mode

Press and hold the power button for

2 seconds.

» The brightness of the screen

dims.

PM2.5 Instant mode

PM2.5 Instant Mode gives you accurate

PM2.5 feedback in every second, this

mode lasts for a continuous 5 minutes

when triggered by button of the Airvibe or

App. After the 5 minutes it automatically

switches to Monitoring Mode with

reduced sensing frequency to every

minute. When Instant mode is triggered,

there is a small ‘i’appears on product

PM2.5 page, it enables you to see instant

PM2.5 changes accurately.

8:08

6 Press the Wi-Fi conguration button

with a sharp object (such as a pen)

to enable the Wi-Fi connection.

» The Wi-Fi icon ( ) blinks

orange on the screen.

7 After the successful connection, the

Wi-Fi icon ( ) will change from

orange to white, stop blinking. You

can monitor your indoor air in real-

time, and get alerts from your smart

phone with the app. The real-time

data will be also displayed on your

phone. If you wish to read the data

from the monitor itself, click the

power button to change pages.

8 Follow steps 5-7 when your network

has changed.

4 Using your AirVibe

PM2.5

Most of the indoor air pollutants fall

under PM2.5 – which refers to airborne

particle pollutants smaller than

2.5 micrometers. Common indoor sources

of ne particles are tobacco smoke,

cooking, burning candles. Some airborne

bacteria and the smallest mold spores,

pet allergen and dust mite allergen

particles also fall under PM2.5.

Formaldehyde

This is a household chemical that is often

used in the manufacture of carpets, glues,

dyes, markers and paints. A colorless

gas released from paints, solvents and

adhesives, formaldehyde typically

leaches from furniture, soft furnishings,

wood products and construction

materials. It is an irritant and a known

carcinogen, with prolonged exposure

considered a serious health risk.

Indoor formaldehyde could remain a

period of emission time ranging from

3 years to more than 10 years, with high

temperature and humidity promote the

release of formaldehyde.

It is important to monitor the

formaldehyde release through the sensor.
