Philips 42FD9932 - annexe 2 User manual

Flat Colour Monitor

42FD9932

Product highlights

• True flat multimedia product which can be hung on the wall like a painting.

• Plasma DisplayVery advanced technology enabling wide viewing angles,

flicker free picture and bright superb colours.

• Very large and impressing display:

- Data:VGA,SVGA, XGA, and MACII capable for professional presentations.

-Video:multi system playback.

• Built in Sound System Powerful 2 x 40W MPO sound.

• Home EntertainmentThe ideal monitor for home cinema applications.

• Anti-reflex coated flat glass screen

• 160˚ viewing angle

• Energy star power management

Multi media at its best performance

Flat Colour Monitor

42FD9932

Release date : Autumn 1999

Predecessor : ---

Date of issue : August 1999

Subject to modification without notice

Technical specifications

Display

• Visible diagonal 42”,106 cm

• Display type AC-Plasma

• Number of pixels 852 (*3)*480

• Gray scale levels 256

• Contrast 480:1

• Aspect ratio 16:9

• Anti-reflex coated glass screen


• Viewing modes

- Data:16x9,4x3

-Video:16x9, 14x9,4x3

• Settings viaVGA menu

-Volume

- Brightness

- Contrast

- Colour temperature

- Horizontal picture

-Vertical picture

Multi media modes

-VGA 640x480 31.468 kHz 60 Hz

-VGA 640x400 31.468 kHz 70 Hz

-VGA 640x350 31.468 kHz 70 Hz

- SVGA 800x600 31.165 kHz 56 Hz

- XGA 1024x768 45.000 kHz 56 Hz

- MAC II 640x480 35.000 kHz 67 Hz

Sound

• 2 x 40W MPO

• Sound system:2x3 speaker stereo

• Loudspeakers:

- 2x65x132 mmWoofers

- 2x65x132 mm Passive Radiators

- 2x12 mm DomeTweeters

-Volume 2.1 Litre per Box

Connections

• VGA input and audio L + R in

• VGA output and audio L + R out

• Active loop through forVGA maximum 2 sets

• A/V connections

-Y/C, YUV (1 Fh)

- CVBS inputs,Cinch and BNC

-Audio in

Selectable colour temperature

• 10,000˚K for data and presentations

• 6,500˚K or 5,600˚K for video

Remote control

• Executive commander

• RC type: RC0333

Miscellaneous

• Ambient temperature:+5~+45˚C

• Maximum operating altitude:2000 m

• Mains: AC 100-240V

• Power consumption:around 350W

• Standby consumption:1W

• Weight (excl. packaging):

- Display: 42.5 kg

• Dimensions (wxhxd):

- Display: 122.2x68.1x14.6 cm

• Wall mounting bracket included

View from below
