Philips MCM148/77 User manual

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

MCM148

Quick Start Guide

User Manual

Quick Start Guide User manual

ALB/

PRESET

Remote Control

MCM148_QSG_Eng 2010.3.30, 17:561

Connection

Connect the speaker wires to the SPEAKERS terminals.

Connect the power cord of the system to the AC power outlet.

Tip:

It is unnecessary to connect the FM pigtail antenna since it

is fixed to the main unit.

speaker

(right)

speaker

(left)

FM wire antenna

AC power cord

AERIAL

HEADPHO

MCM148_QSG_Eng 2010.3.30, 17:562

Setting the clock

In standby mode, press and hold CLOCK/DISPLAY on the

remote control set for 2 seconds.

Press PROG to select 12-hour or 24-hour display.

Press CLOCK/DISPLAY to confirm.

➜The clock digits for the hours flash.

Press TUNING 4 ¢ (à/ áon the remote control)

to set the hours.

Press CLOCK/DISPLAY again.

➜The clock digits for the minutes flash.

Press TUNING 4 ¢ (à/ áon the remote control)

to set the minutes.

Press CLOCK/DISPLAY to confirm the time.

Playing a disc

Select CD source.

Lift the CD door on the top of the system to open the CD compartment.

Insert a disc with the printed side facing up and press down

on PULL TO OPEN to close the CD door.

PressÉÅto start playback.

Press 9to stop playback.

PROG.

ALB/

CLOCK/DISPLAY

PRESET

CLOCK/DISPLAY

PROG.

ALB/

CLOCK/DISPLAY

PRESET

MCM148_QSG_Eng 2010.3.30, 17:563

CRoyal Philips Electronics N.V. 2010

http://www.philips.com

MCM148_77_QSG_V2.0

Tip:

Detailed playback features and

additional functions are described in

the accompanied owner's manual.

Select TUNER source.

Press PROG on the remote control for more than two seconds to program all available stations

in order of waveband.

Press ALBUM/PRESET +/- until the desired preset station is displayed

Programming and tuning to radio stations

Notes for the remote control:

– First, select the source you wish to

control by pressing one of the source select

keys on the remote control (DISC or AUX,

for example).

–Then select the desired function ( 2;,

í, ëfor example).

MCM148_QSG_Eng 2010.3.30, 17:564
