Philips MCM128B/05 User manual

Quick Start Guide

Step B

Step A

Enjoy

Setup

What’s in the Box?

You should find these items upon opening the box.

MCM128B

Quick Start Guide

User Manual

User manual

MW antenna

Pull out the insulation

plastic sheet.

VOLUME

ALBUM

DBB DSC

MUTE

SLEEP TIMER

REPEAT

SHUFF

AUX PROG

TUNER

VOLUME

DBB DSC

Remote Control

MCM128B_05 QSG_Eng 22/11/06, 17:221

Step A Setup

Tip

It is unnecessary to

connect the FM pigtail

antenna since it is

fixed to the main unit.

Connection

Setting the clock

For radio reception, connect the supplied MW antenna to the

MW aerial terminal.

Connect the speaker wires to the SPEAKERS terminals,

marked red wire to “+”, marked black wire to “-”.

Connect the power cord of the system to the

AC power outlet.

In standby mode, press PROG/CLOCK button.

The clock digits for the hours flash.

Press ¡1 / 2™ to set the hours.

Press PROG/CLOCK again.The clock digits for the minutes flash.

Press ¡1 / 2™ to set the minutes.

Press PROG/CLOCK to confirm the time.

USB DIRECT

PROG/CLOCK

MICRO SYSTEM MCM128

AC MAINS~

RIGHT

aerial

LEFT

AC power cord

FM wire antenna

Speaker

(right)

Speaker

(left)

MW loop antenna

MCM128B_05 QSG_Eng 22/11/06, 17:222

Tip

Detailed playback features and

additional functions are described in

the accompanied owner's manual.

Step B Enjoy

Playing a disc

Select TUNER source.

Press BAND (TUNER on the remote control) to select your waveband.

Tu r n TUNING 0to tune to a station.

Listening to radio

SLEEP TIMER

REPEAT

SHUFF

PROG

TUNER

MUTE

ALBUM

USB

STANDBY-ON SOURCE VOLUME

BAND

PROG/CLOCK TUNING

SOURCE BAND TUNING

Select CD source.

Press OPEN•CLOSE on the top of the system to open the CD door.

Insert a disc with the printed side facing up and press down

on OPEN•CLOSE to close the CD door.

PressÉÅto start playback.

Press 9to stop playback.

Notes for the remote control:

– First, select the source you wish to

control by pressing one of the source select

keys on the remote control (DISC or AUX,

for example).

–Then select the desired function ( 2;,

í, ëfor example).

MCM128B_05 QSG_Eng 22/11/06, 17:223

Step B Enjoy

Playing a USB mass storage device

Make sure that your MCM128B is being powered on.

Press SOURCE repeatedly (or USB on the remote) to enter USB mode.

The LCD display shows- - - with USB DIRECT.

Plug a compatible USB mass storage device to MCM128B’s USB port marked .

If needed, use a suitable USB cable to connect between the device and MCM128’s USB port.

The device will automatically power on.

PressÉÅon your MCM128B to start playback.

Press 9to stop playback.

2006 CKoninklijie Philips Electronics

http://www.philips.com PDCC-JH-0647

Tip

Refer to the user manual supplied for

the description about compatibility of

USB mass storage device, and

playability of the files stored on the

USB device.

Notes for USB usage:

–This micro system is able to support most USB mass storage devices on the current market.

–In case this micro system fails to identify your USB device, please unplug it and then plug it again. For

USB devices designed with batteries, if the problem remains, please ensure sufficient power supply to

your USB devices by replacing/recharging the batteries.

–You may not be able to play bought tracks in your USB device through this system, such as those

bought from the Apple iTunes or Microsoft PlaysForSure websites!

–This micro system is designed for playback of digital music formats MP3 andWMA only and does not

support WMA-DRM,AAC,WAV, M4a, M4b etc.

–Never try to connect this micro system with your PC through a USB cable to avoid any possible

damage!

MCM128B_05 QSG_Eng 22/11/06, 17:224
