Philips MCB146/05 User manual

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

MCB146

Quick Start Guide

User Manual

Quick Start Guide User Manual

Remote Control

MCB146_05_QSG_Eng 4/2/10, 13:421

Connection

Connect the speaker wires to the SPEAKERS terminals.

Connect the power cord of the system to the AC power outlet.

Tip:

It is unnecessary to connect the DAB/

FM antenna since it is fixed to the

main unit.

Notes for the remote control:

– First, select the source you wish to

control by pressing one of the source

select keys on the remote control (DISC

or AUX, for example).

–Then select the desired function

(2;, 4, ¢for example).

speaker

(right)

speaker

(left)

DAB/ FM wire antenna

AC power cord

MCB146_05_QSG_Eng 4/2/10, 13:422

Setting the clock

In standby mode, press and hold DISPLAY/CLOCK on the

remote control set for 2 seconds.

Press PROG on the remote control to select 12-hour

or 24-hour display.

Press DISPLAY/CLOCK to confirm.

➜The clock digits for the hours flash.

Press 4/¢to set the hours.

Press DISPLAY/CLOCK again.

➜The clock digits for the minutes flash.

Press 4/¢to set the minutes.

Press DISPLAY/CLOCK to confirm the time.

Playing a disc

Select CD source.

Lift the CD door on the top of the system to open the CD compartment.

Insert a disc with the printed side facing up and press down

on PULL TO OPEN to close the CD door.

Press 2; to start playback.

Press 9to stop playback.

MCB146_05_QSG_Eng 4/2/10, 13:423

http://www.philips.com MCB146_05_QSG_V3.0

Tip:

Detailed playback features and

additional functions are described in

the accompanied owner's manual.

Programming and tuning to FM

stations

Select FM TUNER source.

2Press SCAN for more than two seconds to program all

available stations (FM only).

Press PRESET +/- ( or 3/4on the remote control) until the

desired preset station is displayed.

Press SOURCE (or DAB on the remote control) to select

DAB to start an automatic search of available DAB stations.

Press 4/¢to change the DAB stations.

Tuning to DAB stations

5To access setup options, press MENU, then use the navigation

control buttons to select.

3Press 2; to confirm a selection.

4To perform a local scan (in UK ), press briefly SCAN.

To perform a full scan (outside UK ), press and hold SCAN.

MCB146_05_QSG_Eng 4/2/10, 13:424
