Philips L 1250 - HPM Operating and maintenance instructions

MATERIAL SAFETY DATA SHEET

PRODUCT: L 1250 - HPM, L 1261 - HPA

(325779, 305581) Revised: 6/01

SECTION 1: MANUFACTURER

Manufacturer's Name and Address: Philips Lighting Company

A Division of Philips Electronics

North America Corporation

200 Franklin Square Drive

Somerset, NJ 08875

Emergency Telephone No.: (800) 424-9300 CHEMTREC

(732) 563-3197 Environmental

Other Information Calls: (800) PLC-BULB

SECTION 2: HAZARDOUS INGREDIENTS

OSHA (PEL) ACGIH (TLV) %

Mercury (7439-97-6) .1mg/m3Ceiling .025mg/m38hr.TWA <.02

Lead Iodide (10101-63-0) * .05mg/m3< .1mg/m_ <.02

Gallium Iodide (13450-91-4)* NONE ESTABLISHED <.02

Cobalt (7440-48-4)+ .1 mg/m_ NONE EST'D <.02

Krypton - 85 HPM less than 15 nCi; HPA less than 50 nCi.

*HPM Only. +HPA Only.

A division of

Philips Electronics North America Corporation 200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

Tel: 732.563.3000

L 1250 - HPM, L 1261 - HPA

Page 2 of 5

SECTION 3: CHEMICAL/PHYSICAL DATA

These items are light bulbs. . The bulb is quartz. HPA lamps are about 30 cm long; HPM lamps

are either 24 or 37 cm long. Other chemical or physical characteristics are not applicable.

SECTION 4: FIRE AND EXPLOSION DATA

THE BULB WALL OF THIS ELECTRICAL DISCHARGE LAMP IS COMPOSED OF

QUARTZ AND IS DESIGNED FOR USE ONLY WITH PROPER FIXTURES, IGNITORS

AND BALLASTS. THE LAMP OPERATES UNDER HIGH INTERNAL PRESSURE AT

VERY HIGH TEMPERATURES AS HIGH AS 950•AND MAY RUPTURE

UNEXPECTEDLY. IF RUPTURE OCCURS, DISCHARGE OF EXTREMELY HOT

QUARTZ PARTICLES INTO THE ENCLOSURE AND/OR SURROUNDING

ENVIRONMENT COULD OCCUR, THEREBY CREATING A RISK OF PERSONAL

INJURY, PROPERTY DAMAGE, OR FIRE.

SECTION 5: REACTIVITY DATA

Stability: Envelope is stable.

Incompatibility: Envelope can be affected by oils and fats deposited on surface from fingers.

Handling of envelope should only be done with gloves.

While the amount of lead iodide is small and exposure occurs only if the lamp

is broken the following incompatibility is noted. Lead iodide is incompatible

with hydrogen peroxide, strong oxidizers, sodium and potassium. Fluorine

decomposes lead iodide at ambient temperatures, igniting the liberated iodine

and generating much heat.

A division of

Philips Electronics North America Corporation 200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

Tel: 732.563.3000

L 1250 - HPM, L 1261 - HPA

Page 3 of 5

SECTION 6: HEALTH HAZARD DATA

WARNING: THIS LAMP EMITS SHORTWAVE ULTRAVIOLET RADIATION WHICH IS

HARMFUL TO SKIN AND EYES AND CAN CAUSE SERIOUS SKIN BURNS AND EYE

INFLAMMATION. USE ONLY IN EQUIPMENT SPECIFICALLY DESIGNED TO

REDUCE THE RISK OF PERSONAL INJURY AND PROPERTY DAMAGE RESULTING

FROM ARC TUBE RUPTURE AND FROM ULTRAVIOLET RADIATION. IT IS

RECOMMENDED THAT THIS LAMP BE USED IN FIXTURES HAVING A SAFETY

INTERLOCK SWITCH. LEAD IODIDE IS NOT LISTED AS A CARCINOGEN BY IARC,

NTP, OR OSHA.

------------------------------------------------------------------------------------------------------------------

FIRST AID: If exposure to ultraviolet radiation occurs, it is recommended that an

opthamologist be consulted.

SECTION 7: PRECAUTIONS FOR SAFE HANDLING AND USE

WASTE DISPOSAL METHOD: The lamp contains a small amount of mercury - together with a

small amount of lead iodide. Under the toxicity characteristic leaching procedure (TCLP)

promulgated by the United States E.P.A. tests of used or spent high intensity discharge lamps

indicate that these lamps generally are considered to be hazardous when discarded. (Fed. Reg.

7/27/94.) EPA has issued the Universal waste Rule for lamps which fail the TCLP (Fed Reg

7/6/99). More than thirty States now manage lamps under this Rule. The UWR requires

recycling or hazardous waste disposal of those lamps which fail TCLP. There are some

exemptions which depend on your status, volume and or location. Check with your State

Authorities for information to ensure proper waste disposal practice.

A division of

Philips Electronics North America Corporation 200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

Tel: 732.563.3000

L 1250 - HPM, L 1261 - HPA

Page 4 of 5

SECTION 7: PRECAUTIONS FOR SAFE HANDLING AND USE (Cont'd)

Safe Handling: Read and Follow the installation/operating instructions listed below to help

reduce risk of personal injury and property damage and help prevent early lamp failure:

1) Before lamp installation/replacement, shut power off & allow lamp & fixture to cool to

avoid

electrical shock & potential burn hazards.

2) Protect lamp from abrasions & scratches. Do not install or use cracked or broken lamp. If

lamp cracks or breaks in use, disconnect power supply immediately, allow system to cool &

remove lamp.

3) Do not touch lamp with bare hands. If touched with hands, clean lamp with denatured

alcohol and wipe with a lint-free cloth before installing.

4) Replace lamp at or before the end of rated life. Allowing lamp to operate until it fails is not

recommended and may increase the risk of inner arc tube rupture.

5) Use within voltage limits recommended by ballast manufacturer. Do not operate lamp at

higher than specified power.

6) The permissible maximum operating temperatures (e.g., the pinch temperatures, the

tempera-

ture of the bulb wall) as indicated on the product leaflet may not be exceeded.

7) Lamp should be operated within 10 degrees of the horizontal position to insure maximum

operating efficiency.

SECTION 8: SPECIAL PROTECTION DATA

WARNING: THIS LAMP EMITS SHORTWAVE ULTRAVIOLET RADIATION. USE

ONLY IN EQUIPMENT DESIGNED TO REDUCE RISK OF PERSONAL INJURY AND

PROPERTY DAMAGE. DO NOT LOOK AT OPERATING LAMP WITHOUT

PROTECTIVE FIXTURE AND/OR PROTECTIVE GOGGLES. DO NOT USE LAMP IF

ULTRAVIOLET FILTER GLASS IS MISSING OR DAMAGED.

A division of

Philips Electronics North America Corporation 200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

Tel: 732.563.3000

L 1250 - HPM, L 1261 - HPA

Page 5 of 5

SECTION 9: SPECIAL PRECAUTIONS & COMMENTS

No restrictions as product shipped by truck, air or water. Spent lamps may require D008 RCRA

classification. If state adopts universal waste rule, spent lamps can be shipped using common

carrier and bills-of-lading. Contact your state environmental agency for guidance.

Prepared: 8/9/95 S21-95001

A division of

Philips Electronics North America Corporation 200 Franklin Square Drive

P.O. Box 6800

Somerset, NJ 08875-6800

Tel: 732.563.3000
