Philips GC3802/20 User manual

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

ServiceManual

Philips Consumer Lifestyle

Azur Performer

GC3802/20

14/05

Product information

Fast & powerful crease removal

•Soleplate: SteamGlide

•Continuous steam output:  g/min

•Steam boost:  g

•Vertical steam

•Spray

•Power:  W

Easy to use

•Water tank capacity:  ml

•Filling and emptying water: Sideways opening door

•Drip stop

•Soft grip

•Cord storage: Cord clip

•Power cord length:  m

•Reaching tricky areas: Triple precision tip

•Fast and easy filling

Sustainability

•ECO setting:  energy reduction

Calc management

•Calc clean solution: Double active calc clean

Safety Information

•This product meets the requirements regarding

interference suppression on radio and TV.

•After the product has been repaired, it should function

properly and has to meet the safety requirements and

legal regulations as officially laid down at this moment.

Water Advice

•Azur Performer is designed to be used for tap water.

The double active calc clean system can ease the calc

cleaning process. Regular cleaning of your iron will result

in longlasting steam performance. For better ironing

results we recommend to use demineralized water. This

ensures a consistent steam flow from your iron.

Technical information

•Voltage :    V

•Frequency :    Hz

•Power :  W

GC3802/20

2-5

Disassembly advice

BACKPLATE SCREW COVER STICKER 2

BACKPLATE 3, SWIVEL 5

POWER CORD 4

LAMP ASSY 6

Remove BACKPLATE COVER STICKER 2

Remove Screws A1, A2, A3

Remove BACKPLATE 3 & SWIVEL 5

Remove Screw B1, B2

Remove CORD CLAMP

Remove POWER CORD 4

Remove LAMP ASSY 6

FILLING DOOR 7

INLAY 9

SPRAY KNOB 12

TRIGGER & TRIGGER HOLDER 15

Remove BACKPLATE COVER STICKER 2

Remove Screws A1, A2, A3

Remove BACKPLATE 3 & SWIVEL 5

Remove Screw B1, B2

Remove CORD CLAMP

Remove POWER CORD 4

Remove LAMP ASSY 6

Remove FILLING DOOR 7

Remove Screw C1

Remove INLAY 9

Remove SPRAY KNOB 12

Remove Screw D1, D2, D3

Remove TRIGGER & TRIGGER HOLDER 15

HOUSING 13

CAM LEVER 17

T-DIAL INDICATOR 19

WATER TANK ASSY 20

COVER 22

SOLEPLATE ASSY 26

Remove BACKPLATE COVER STICKER 2

Remove Screws A1, A2, A3

Remove BACKPLATE 3 & SWIVEL 5

Remove Screw B1, B2

Remove CORD CLAMP

Remove POWER CORD 4

Remove LAMP ASSY 6

Remove FILLING DOOR 7

Remove Screw C1

Remove INLAY 9

Remove SPRAY KNOB 12

Remove Screw D1, D2, D3

Remove TRIGGER & TRIGGER HOLDER 15

Remove Screw E1, E2

Remove HOUSING 13

Remove CAM LEVER 17

Remove Screw F1

Remove T-DIAL INDICATOR 19

Remove Screws G1, G2

Remove WATER TANK ASSY 20

Remove Screws H1, H2, H3

Remove COVER 22

Remove SOLEPLATE ASSY 26

3-5

LIVE

VEE VCC

VEE

VCC

VCC VCC

VCC

9001

BROWN

LIVE

NEUTRAL

EARTH

RLY_Ctrl

MCLR

ICSPDAT

ICSPCLK

9002

BLUE

9003

RED

3002

1M 0.5W (MF)

3001

220R 1W (WW)

3003

270R 0.5W (MF)

3007

220R 0.1W

3013

100k 0.1W

3012

22k 0.1W

8003

47V 1W

8001

1N4007

3004

10k

0.1W

2.7k

0.1W

3008

100k

0.1W

3009

100k

0.1W 3011

100k 0.1W

3005

3006

47k 0.1W

NEON

HEATING ELEMENT

THERMOSTAT

THERMAL FUSE

8004

5V1

0.5W

8002

1N4007

8006

BAS316

7002

BC856

4001

Relay 24VDC 0.2W

7001

BC846B

2002

47µF

63V

2003

330µF

6.3V

2001

220nF X2 275V

VDD

1001

PIC12F508

GP5

GP4

GP3

VSS

GP0

GP1

GP2

2004

100nF 50V

3010

47k 0.1W

2005

100nF 50V

2006

470nF

16V

8005

ASO LED

4002

Motion

sensor

Part lists & Electrical diagram

Pos Service code Description

N/A Scoop

Backplate Screw Cover Sticker

Backplate Normal Assy

Power Cord

Swivel

N/A

Lamp Assy

Filling Door

Tank Seal

Inlay

Steam Slider

Spray Knob

Housing Printed

SOS Trigger Assy

N/A Calc Clean Button

Cam Lever

Cam Lever Spring

Water Tank Assy

Steam Shaft

Cover Inscribed

Thermostat Bush

Dosing Seal Assy

SOS Seal

N/A

S/P Mtd Assy

Chamber

Ryton Ring

Soleplate Gasket

Water Pump (Spray and SOS pump)

4239 021 91311

4239 021 90621

4239 021 90871

Exploded view

4-5

C1 D1

H2 G2

11 3

29 17

5-5

•Due to the high wattage of the iron, only the specied cord set must be used.

•Should damage be observed on the , it must be replaced.

•Continued usage is not allowed.

•If is provided without type plate information eg. Type number, voltage etc. When replacing the cover, engrave

the type number & voltage on the type plate with a sharp object.

•After the product has been repaired, it should function properly and has to meet the safety requirements & legal regulation

as laid down & ocially established at this moment.

•The following tests are common checks that are conducted on a repaired product before it is returned to the consumer.

Check the soleplate temperature is within IEC requirement.

Soleplate temperature ( °C)

Materials, for example

Test-

point

= =

Minimum Maximum

Check that leakage current is within IEC requirement.

Measure leakage current between LIVE/NEUTRAL & EARTH.

Check that there is no water leakage from any part of product during operation.

Check that the functionality of the product (product dependent) eg. Steaming, steam trigger, variable steam, SOS, PCBA

etc is working properly.

When replacing fuse, to also service the water tubes which is probably choked with calc.

All failed PCBAs including to be packed with ESD bags for shipment.

ned screws in terms of length and material used.

Repair Instruction

Check that there are no loose parts eg. Extra screws in the product can cause short-circuit or product malfunctions

160 230
