Philips GC1703 User manual

ServiceManual

Philips Consumer Lifestyle

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

Steam Iron EasySpeed

GC1703

10/01

PRODUCT INFORMATION

Features

- Color : Ink Blue

- Aluminium soleplate

- Pointed tip soleplate

- Tank capacity 180 ml

- Steam rate 15 g/min

- Cord length 1.8 m

- Calc clean function

Safety Information

- This product meets the requirements regarding

interference suppression on radio and TV.

- After the product has been repaired, it should function

properly and has to meet the safety requirements and

legal regulations as officially laid down at this moment.

TECHNICAL INFORMATION

Voltage : 110 V, 220 - 240 V

Frequency : 50 - 60 Hz

Power : 1000 W, 1200 - 1440 W

Dimension (F-box) : 285 (L) x 123 (W) x 152 (H) mm

Weight (Product) : 0.95 kg

Water advice

Suitable for tap water use. However, if the water in your area

is very hard, it is advisable to mixed with an equal portion of

distilled water or use only distilled water.

Aluminium soleplate

Smooth & corrosion free which treats fabric gently.

Pointed tip soleplate design

Access difﬁcult-to-reach areas on a garment.

Calc clean function

Ensure longer life for the iron by removing calc build-up

inside the soleplate steam chamber.

GC1703

BACKPLATE 14

LAMP ASSY 7

CORDSET 10

SWIVEL 9

DOSING ASSY 13

INLAY 8

Remove Screw A

Remove BACKPLATE 14

Remove DOSING ASSY 13

Remove Screw B

Remove INLAY 8

DISASSEMBLY ADVICE

THERMOSTAT DIAL 12

WATER TANK ASSY 11

THERMOSTAT BUSH 6

METAL SHEET 5

COVER 4

DOSING SEAL 2

RYTON RING 3

SOLEPLATE ASSY 1

Remove THERMOSTAT DIAL 12

Remove Screws C1, C2, C3

Remove WATER TANK ASSY 11

Remove THERMOSTAT BUSH 6

Remove Screws D1, D2, D3

Remove COVER 4

REPAIR INSTRUCTION

- In case of any defect on the thermostat, the complete soleplate has to be replaced.

- In the event that no information about the type number & voltage has been stamped onto the type plate sparepart, engrave at

least type number & voltage onto the typeplate sparepart with a tool when replacing this part.

- After product has been repaired, it should function properly & has to meet the safety requirements & legal regulations as officially

laid down at this moment.

2-4

GC1703

PARTS LIST & ELECTRICAL DIAGRAM

Resistor

Lamp

Heating

Element

INPUT

Thermostat

Thermal

Fuse

3-4

Pos Service code Description

4239 021 41931

4239 021 37080

4239 015 56600

4239 015 70150

4239 026 24720

4239 010 10500

4239 026 13220

4239 021 14520

4239 021 37030

4239 025 96960

4239 000 06720

4239 000 07150

4239 021 36940

4239 021 37050

4239 021 37000

4239 021 38600

4239 015 40240

4239 015 40580

Soleplate assy (Aluminium) 230 V

Soleplate m. a. 110 V

Dosing seal

Ryton ring

Cover (no SOS)

Metal sheet

Thermostat bush

Lamp assy

Inlay printed

Swivel

Cordset EU

Cordset 110 V

Water tank assy

Thermostat dial printed - Eng

Dosing assy

Dosing assy 110 V

Backplate impressed

Backplate impressed - 110 V indication

= changed

GC1703

EXPLODED VIEW

4-4
