Philips MCD710 User manual

MCD710

Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

Quick start guide

User Manual

Remote control with two

AAA batteries

FM antenna

User manual

Composite Video Cable

MCD710 QUG_Eng 2007.12.27, 16:291

Tips

–See the User Manual for other TV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Setting up the TV

Switch the DVD system on and then select DISC source.

Turn on the TV and set it to the correctVideo In channel.

Connect the FM antenna.

Connect the composite video to a TV.

Connect the power cords of the system and TV.

AC power

FM antenna

Speaker

(right) Speaker

(left)

AC power

MCD710 QUG_Eng 2007.12.27, 16:292

Setting the clock

In standby mode, press and hold CLOCK on the remote.

When the hour digits flash, turn VOLUME-/+ on the system or press VOL +/- on the

remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn VOLUME-/+ on the system or

press VOL +/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connected TV does not support

progressive signals or the cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1) Turn off your TV progressive scan mode or turn on to interlaced mode.

2) Press SYSTEM MENU on the remote to exit the system menu and then DISC

and “1” to exit progressive scan.

Tip

See chapters "Getting Started" and "System Menu Options" in the

User Manual for detailed descriptions.

DIVX (R) VOD

3D PROCESSING

MCD710 QUG_Eng 2007.12.27, 16:293

Playing a disc

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROGRAM on the remote for more than two seconds to program all available

stations in order of waveband.

Press PRESET+/- (¡/ ™on the remote) until the desired preset station is displayed.

PDCC-ZC-0752

Tip

Detailed playback features and

additional functions are described in the

accompany owner's manual.

Notes for remote control:

– First, select the source you wish to control by

pressing one of the source select keys on the remote

control (DISC orTUNER, for example).

–Then select the desired function (

for

example).

Press çto open the disc tray and load in a disc, then press the same button again to

close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket on the set.

Press SOURCE once or more (or USB on the remote control) to select USB.

Play the USB’s audio files as you do with the albums/tracks on a CD,

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

MCD710 QUG_Eng 2007.12.27, 16:294
