Philips MCD396 User manual

MCD396

Quick Start Guide

Composite Video Cable Remote control with

battery

FM antenna

User Manual

Remove the plastic

protective sheet

What’s in the Box?

You should find these items upon opening the box.

USB/

MCD396 QUG_Eng 2008.6.24, 3:27 PM1

AC power cord

FM wire

antenna

–

SPEAKER 4Ω

R L

Speaker

(right)

Speaker

(left)

110-

127v

220-

240v

Tip

See the User Manual for other TV

connection options.

Setting up the TV

Connect the speaker cables.

Connect the FM antennas.

Connect the composite video cable to a TV.

Connect the power cords of the system and TV.

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

TAPE USB/AUX

ATo listen to the sound of this DVD Player

through your TV, use the audio cables (white/

red-not supplied) to connect LINE OUT

(L/R) jacks of the DVD Player to the

corresponding AUDIO IN jacks on the TV.

B To listen to the sound of your TV through

this DVD player, use a cinch cable (not

supplied) to connect LINE-IN on the front

panel of the DVD player to the

corresponding AUDIO OUT jacks on the TV.

AUDIO OUT

MCD396 QUG_Eng 2008.6.24, 3:28 PM2

Setting the clock

In standby mode, press and hold CLOCK on the system.

When the hour digits flash, turn the VOL control on the front panel or press VOL +/- on

the remote to set the hours.

Press CLOCK again and the minute digits flash.Then turn the VOL control on the front

panel or press VOL +/- on the remote to set the minutes.

Press CLOCK again to confirm the time setting.

Setting system menu options

Tip

See chapters "Preparations" and "System Menu Options" in the User

Manual for detailed descriptions.

TAPE USB/AUX

LATIN

DIVX(R) VODDIVX(R) VOD

Before using the remote control

1 Pull out the plastic protective sheet.

2 Select the source you wish to control by pressing one of the source

select keys on the remote control (for example CD,TUNER).

3 Then select the desired function (for example ÉÅ , à, á)

Remove the plastic protective sheet

MCD396 QUG_Eng 2008.6.24, 3:28 PM3

Playing a disc

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source.

Press PROG/ANGLE for more than two seconds to program all available stations in

order of waveband.

Press PRESETí/ëuntil the desired preset station is displayed.

Press OPEN•CLOSE 0to open the disc tray and load in a disc, then press the same

button again to close the disc tray.

➜Make sure the label side of the disc is facing up.

Playback will start automatically. If not pressÉÅ.

To stop playback, press 9.

Insert the USB device’s USB plug into the socket on the front panel of the main set.

Press SOURCE (or USB on the remote control) once or more to select USB.

Playing a USB mass storage device

With the Hi-Fi system, you can use USB flash memory (USB 2.0 or USB1.1),

USB flash players (USB 2.0 or USB1.1), memory cards (requires an additional card reader to

work with this Hi-Fi system).

Play the USB’s audio files as you do with the albums/tracks on a CD.

Tip

Detailed playback features and additional functions are described in the

accompany owner's manual.

PDCC-J.W.Wang 0814

CRoyal Philips Electronics N.V. 2008

http://www.philips.com

MCD396 QUG_Eng 2008.6.24, 3:28 PM4
