Philips QC5380 User manual

ServiceManual

Philips Consumer Lifestyle

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification

Hair clipper pro

QC5380

12/08

PRODUCT INFORMATION

General:

- Corded and cordless use

- World wide automatic voltage selection 100 - 240 Volt

- Mains operating when battery is empty

- Battery light:

The light is continuously lit to indicate a full battery

for 30 minutes, and blinks orange when you have about

10 minutes left to use

- 100% waterproof for cleaning

Place of production date

YYWW

Safety information

- This product meets the requirements regarding

interference suppression on radio and TV.

- After the product has been repaired, it should function

properly and has to meet the safety requirements as

officially laid down at this moment.

TECHNICAL INFORMATION

- Voltage : 100 - 240 Volt

- Battery : Li-ion

- Charging time : 1 hour

- Running time : Up to 75 minutes

- Cutter need no oiling

- Cutter width : 41 mm

- Number of length settings : 10

- Length setting : 3 - 22 mm

- Precision (size of steps) : 2 mm

without comb : 0,5 mm

Buzz comb : 1 mm

- Self-sharpening stainless steel blades

DISASSEMBLY- AND RE-ASSEMBLY ADVISE

- No specific issues

REPAIR INSTRUCTIONS

- No specific issues

OPTIONAL (accessories)

- 4222 018 60071 Suitcase

- 4222 036 21721 Buzz comb

- Power plug:

2722 171 90129 Europe

2722 171 90138 USA, CA, TW, MEX, JAP

2722 171 90143 Australia/New Zealand

2722 171 90132 United Kingdom

QC5380

PARTS LIST + EXPLODED VIEW

POWER

TURBO

Pos Service code Description

4222 010 13201

4222 036 21711

4222 029 31341

See Optional

Cutter assy

Small comb (push)

Brush

Power plug
