Philips QT4060 Philishave User manual

QT4060,

QT4040

ENGLISH 6

DEUTSCH 14

NORSK 22

SVENSKA 29

SUOMI 37

DANSK 44

QT4060, QT4040

Introduction

Dear customer, you have made the right choice!

Your new maintenance-free Philips vacuum beard trimmer combines

innovative technology and outstanding comfort of use.

The integrated vacuum mechanism absorbs cut-off hairs during use and

guarantees a clean washbasin after use.

The contour-following comb, the self-sharpening cutting element and

the adjustment ring for selecting hair lengths of 1.5 to 18 mm ensure

excellent cutting results and time-saving operation.The high-quality

trimmer guarantees a precise and defined cut and the ergonomic shape

of the appliance allows pleasant and comfortable handling.

Your new Philips vacuum beard trimmer is excellently suited for cutting

and contouring your beard and sideburns.

General description

AComb attachment

BDetachable cutting unit

CFlexible hair guide

DHair-collection chamber

EFilter

FAdjustment ring (Precision Zoom Lock`)

GOn/off button

HCharging light

ISocket for appliance plug

JPowerplug

KCleaning brush

Important

Read these instructions for use carefully before using the appliance and

save them for future reference.

◗Check if the voltage indicated on the powerplug corresponds to

the local mains voltage before you connect the appliance.

◗Only use the powerplug supplied.

◗The powerplug contains a transformer. Do not cut off the

powerplug to replace it with another plug, as this will cause a

hazardous situation.

ENGLISH6

◗Do not use the appliance when the cutting unit is damaged or

broken, as this may cause injury.

◗Do not use a damaged powerplug.

◗If the powerplug is damaged, always have it replaced by one of the

original type in order to avoid a hazard.

◗Make sure the appliance and the powerplug do not get wet.

◗Keep the appliance out of the reach of children.

◗Use, charge and store the appliance at a temperature between

15cC and 35cC.

◗This appliance is only intended for trimming the human beard. Do

not use it for any other purpose.

Charging

Charge the appliance fully before you start using it for the first time or

after a long period of disuse.

1Make sure the appliance is switched off before you start charging

it.

2Insert the appliance plug into the appliance and put the

powerplug in the wall socket.

◗The charging light goes on to indicate that the appliance is

charging (fig. 2).

◗It will take approx. 10 hours to fully charge the battery.

◗A fully charged appliance has a cordless trimming time of up to

50 minutes.

BWhen the appliance has been charged for the first time, we advise you

to use it until the battery is completely empty.

BFor a single trimming session the appliance must be charged for at

least 90 minutes.

Optimising the lifetime of the rechargeable battery.

- After the appliance has been charged for the first time, use it until

the battery is completely empty.

- Do not charge the appliance for more than 24 hours.

- Do not keep the powerplug plugged into the wall socket all the

time.

ENGLISH 7

- Do not recharge the appliance between trimming sessions.

- Discharge the battery completely twice a year by letting the motor

run until it stops.Then fully recharge the battery.

- If the appliance has not been used for a long period of time, it must

be fully recharged.

Preparing for use

Always comb your beard or moustache with a fine comb before you

start trimming.

Using the appliance

Corded trimming (QT4060 only)

Do not run the appliance from the mains when the battery is fully

charged.

BIf the battery is low, you can also use the appliance from the mains:

1Switch the trimmer off, connect it to the mains and wait a few

seconds before switching it on.

2If the battery is completely empty, wait a few minutes before

switching the appliance on.

Absorbing cut hairs

The suction system is activated automatically as soon as you switch the

appliance on. It absorbs cut hairs during every kind of use, i.e. trimming

with and without comb attachment and contouring.The flexible hair

guide follows the contours of the face and directs cut hairs towards the

nozzle of the vacuum mechanism.

We advise you to empty the hair-collection chamber after each

trimming session.When trimming long, dense beards it may also be

necessary to empty the hair-collection chamber during the trimming

session in order to maintain optimal suction performance (also see

chapter 'Cleaning', section 'Hair-collection chamber').

ENGLISH8

BTo ensure optimal functioning of the vacuum system, do not cut off

more than approx. 7mm of your overall beard length at a time. If you

want to cut your beard shorter, repeat the process one or more times.

Trimming with comb attachment

1Turn the adjustment ring (Precision Zoom Lock`) to the desired

trimming length setting (see table) (fig. 3).

◗The setting will appear in the window below the adjustment ring

(Precision Zoom Lock`).

If you are trimming for the first time, start with the maximum

trimming length setting (9).

2To trim in the most effective way, move the trimmer against the

direction of hair growth. Do not move the trimmer too fast.

Make smooth and gentle movements and make sure the surface

of the comb always stays in contact with the skin (fig. 4).

ENGLISH 9

Resulting hair length

1.5 mm

2.5 mm

4 mm

5.5 mm

7.5 mm

9.5 mm

12 mm

15 mm

18 mm

Setting

Trimming length settings

Trimming at the unique 'stubble look' setting

◗Use the trimmer with the comb attachment set to length setting

1.This allows you to create a 'stubble look' (fig. 5).

Trimming without comb attachment

Full beards and single hairs.

1Remove the comb attachment (fig. 6).

BNever pull at the flexible top of the comb attachment.Always pull at

the bottom part.

2Make well-controlled movements and touch the hair lightly with

the trimmer (fig. 7).

Cleaning

The appliance may only be cleaned dry.

Do not use abrasives, scourers or liquids such as alcohol, petrol or

acetone to clean the appliance.

Never use sharp or hard objects to clean the filter to avoid damaging

it.

Hair-collection chamber

1Switch the appliance off.

2Remove the hair-collection chamber and remove the hairs by

shaking or brushing them out (fig. 8).

3For extra thorough cleaning and to maintain optimal suction

performance, detach the filter... (fig. 9).

4...and carefully clean the hair-collection chamber and the filter

with the brush supplied (fig. 10).

Appliance

1Remove the comb attachment.

ENGLISH10
