Philips HS930 User manual

English page 3

Français page 13

Deutsch Seite 24

Nederlands pagina 34

Italiano pagina 44

Español página 54

Português página 65

1Do not allow the

shaver to become

wet.

2Do not leave the

appliance in a

position where it can become damaged by

direct sunlight or other heat source.

- Before first use or

- if the shaver has not been used for a month

or longer it should be charged for a period

of at least 8 hours (irrespective of the

reading on the display).

If the batteries are completely empty, it may

take some time (3-5 minutes) before

information appears in the display.

• Please bear in mind that your skin may

need two to four weeks to become fully

accustomed to the Philishave shaving

system.

To protect the environment, this

rechargeable Philishave appliance is

equipped with nickel-hydride batteries.

These contain less than 0.01% cadmium.

Yet we advise you to ensure that the batteries

are separated from the normal household

refuse and that they are disposed of at an

officially assigned place when discarding your

appliance in due course. Please refer to

section “Protecting the environment”.

930

100

930

100

■■■ Important English

■■■ Switching on/off

3 The slider switch has a locking

knob which prevents the shaver

from being switched on

accidentally.

Keeping the small knob on the

switch pressed-in slide the switch

upwards/downwards.

■■■ Charging

• Ensure that the shaver is switched off.

•It is advisable to charge the shaver at tem-

peratures between 5°and 35°C (41°and 95°F).

This guarantees maximum life from the

rechargeable batteries.

•Before first use (or if the shaver has not been

used for a long time) it should be charged for a

period of at least 8 hours.

•Recharging: 60 minutes.

The shaver can also be charged

from a 12 - 24 Volts (DC) supply

using cord connector type HP 1957.

Charging from a 12 - 24 Volts (DC)

supply requires approx. 24 hours.

• Regular cleaning of the shaver

means that less battery energy is

consumed, so that more shaving time becomes

available.

• The shaver will not be damaged by leaving it

connected to the mains supply after it is fully

charged. However, it is not advisable to charge the

shaver permanently as this would shorten the life of

the rechargeable batteries.

930

100

4 Insert the small plug into the

shaver. Ensure that the plug is

pushed fully home. (Note the

indication mark.)

Mains voltages: 100 - 240 Volts.

(The shaver adjusts

automatically.)

5One of the blocks of the charge meter

will start flashing.

If the batteries are almost empty, the

first block will be red.

When it turns green, there is enough

energy in the rechargeable batteries for

one cordless shave (3 minutes).

6Each time when 20% of the full charge

has been accomplished the next block

of the energy meter will start to flash.

7After 60 minutes, block “100” comes on

flashing. This block stops flashing as

soon as the shaver is fully charged.

■■■ Cordless shaving

When switching on and off, the blocks of the energy

meter become visible for approx. 8 seconds.

You can then check how much charge is still

available in the rechargeable batteries, until the

reserve capacity will be reached.

930

100

930

100

930

100

930

100

8After shaving cordless with the fully

charged shaver for some time, the fifth

block will no longer be visible.

Thereafter, the other blocks will

disappear successively.

9When the last block turns red, the

reserve energy has been reached.

(You will be able to complete the

shave.)

As the shaver is switched off you will

hear a sound signal for 4 seconds

and the red block will start flashing.

This indicates that it is time to

recharge the shaver.

■■■ Have you missed out charging?

When the batteries are completely empty and the

shaver stops, you can give the shaver a quick

charge (sufficient for one cordless shave):

- Charge the shaver until the last block turns from red

into green.

■■■ Shaving directly from the mains supply

(wall socket)

- If you wish you can connect the shaver to a wall

socket using the mains cord and shave directly from

the mains supply.

930

100

930

100

■■■ Shaving

10 Switch on.

11 The comfort control can be adjusted to suit

skin sensitivity.

Start with the control set to position 1 (for sensitive

skin) and then try other positions to find the one

that suits you best.

12 Move the shaving unit quickly over the skin

and especially against the direction of the hair

growth, stretching the skin with your free hand to

bring the hairs into an upright position.

• Best results are obtained if the skin is dry.

Preferably shave before or some time after

washing.

• If required apply a pre-shave lotion. This can be

particularly helpful if the climate is warm and humid.

1 2 3 4 5 6 7 8 9

11 12

■■■ Trimmer

The trimmer can be engaged whilst the motor is

running.

13 To engage the trimmer push the slide

upwards.

To disengage move the slide downwards.

Brush the trimmer clean after each use.

14 The trimmer has been especially designed for

grooming sideburns, moustache and beard.

The trimmer is not required for long hairs in the

neck area; these hairs can easily be shaved off

with the shaving unit.

15 Maintenance (every six months)

Apply two drops of light machine oil to the teeth of

the trimmer.

13 15

OIL

■■■ Cleaning

• Always ensure that the mains cord is disconnected

and the shaver is switched off before carrying out

maintenance or cleaning.

• Handle the shaving heads carefully to avoid

causing damage.

•Advice: Clean the shaver regularly.

16-19 Every week:

shaving head slots and hair chamber

- (Fig. 16) Use the short bristled brush to clean the

shaving head slots.

- (Fig. 17) To remove the shaving unit depress the

retaining button (1) and lift the shaving unit from the

shaver (2).

- (Fig. 18/19) Remove hairs from the chamber and

shaving unit using the long bristled brush.

16-31 Every 3 months:

shaving head slots, the hair chamber and

shaving unit (guards and cutters)

(If your skin is of an oily type or if you have been

using a pre-shave lotion: 1x per month.)

- First clean the shaver head slots and hair chamber

as previously described. (See figs. 16-19.)

Then proceed with figs. 20-31 for cleaning the

shaving unit.

- (Fig. 20 - 21) Release and remove the retaining

plate.

The shaving heads remain in the shaving unit.

- (Fig. 22) Remove only one shaving head (guard

and cutter) at a time for cleaning to ensure that the

cutters and guards do not become mixed.

Each cutter has been ground together with the

guard. If the guards and cutters are mixed, it may

take some weeks before optimal shaving

performance is restored.

- (Fig. 25) Clean the cutter by brushing only in the

direction of the arrow using the short bristled brush.

21 22

23 24 25
