Philips HS190/24 User manual

HS190

ENGLISH 4

한국어 12

BAHASA MELAYU 21

繁體中文 30

简体中文 38

Introduction

Congratulations on your purchase and welcome

to Philips! To fully benet from the support that

Philips offers, register your product at

www.philips.com/welcome.

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

Warning

- This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

- Children should be supervised to ensure that they

do not play with the appliance.

Caution

- Keep the appliance dry.

- This symbol means that it is not allowed to rinse

this appliance under the tap.

- Use and store the appliance at a temperature

between 5°C and 35°C.

- Remove the batteries if you are not going to use

the appliance for a month or more.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

ENGLISH

Preparing for use

Inserting the batteries

Make sure that your hands are dry when you

insert the batteries.

The appliance runs on two R6 AA 1.5-volt batteries

(not included). Preferably use Philips alkaline

batteries.

1 Push on the rib of the battery compartment

cap (1) and then lift the cap off the appliance (2).

2 Place two batteries in the battery

compartment.

Make sure the + and - indications on the batteries

match the indications in the battery compartment.

The shaver does not work if the batteries have been

placed incorrectly.

3 Put the battery compartment cap back onto

the appliance (‘click’).

The cap only ts onto the appliance in one way.

To avoid damage due to battery leakage:

- do not expose the appliance to temperatures

higher than 35°C;

- Remove the batteries if you are not going to use

the appliance for a month or more.

- do not leave empty batteries in the appliance.

Cordless shaving time

Two new batteries provide a cordless shaving time

of 60 minutes.

ENGLISH 5

Using the appliance

Shaving

1 Press the switch lock (1) and push the on/off

slide upwards (2) to switch on the shaver.

2 Move the shaving heads quickly over your skin.

Make both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get accustomed

to the Philips shaving system.

3 After use, push the on/off slide downwards to

switch off the shaver.

4 Put the protection cap on the shaver every

time you have used it, to prevent damage.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

- For easy and optimal cleaning, the Philips Action

Clean (shaving head cleaner, type HQ100) is

available. Ask your Philips dealer for information.

Note:The Philips Action Clean may not be available

in all countries. Contact the Consumer Care Centre in

your country about the availability of this accessory.

You can also clean the shaver in the following way:

ENGLISH6

Every week: shaving unit and hair chamber

1 Switch off the shaver.

2 First clean the top of the appliance with the

cleaning brush supplied.

3 Press the release button (1) and remove the

shaving unit (2).

4 Clean the inside of the shaving unit and the

hair chamber with the cleaning brush.

5 Put the shaving unit back onto the shaver

(‘click’).

Every two months: shaving heads

1 Switch off the shaver.

2 Press the release button (1) and remove the

shaving unit (2).

ENGLISH 7

3 Push the sides of the central spring towards

each other (1) and then lift the retaining frame

out of the shaving unit (2).

4 Slide the shaving heads out of the retaining

frame.

Hold your nger underneath the shaving head to

prevent the cutter from falling out.

5 Disassemble and clean the shaving heads one

by one.

Note: Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may take

several weeks before optimal shaving performance is

restored.

6 Clean the cutter with the short-bristled side of

the cleaning brush.

Brush carefully in the direction of the arrow.

7 Clean the guard with the cleaning brush.

8 Slide the shaving heads back into the retaining

frame and put the retaining frame back into the

shaving unit.

9 Put the shaving unit back onto the shaver.

Tip: For extra thorough cleaning, clean the shaving

heads by putting them in a degreasing liquid (e.g.

alcohol) every six months.To remove the shaving heads,

follow steps 1 to 4 described above.After cleaning,

lubricate the central point on the inside of the guards

with a drop of sewing machine oil to prevent wear of

the shaving heads.

ENGLISH8

Storage

- Always put the protection cap on the shaver after

use, to prevent damage.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ4

ÇPhilips shaving heads only.

1 Switch off the shaver.

2 Press the release button (1) and remove the

shaving unit (2).

3 Push the sides of the central spring towards

each other (1) and then lift the retaining frame

out of the shaving unit (2).

4 Slide the shaving heads out of the retaining

frame.

5 Slide new shaving heads into the retaining

frame.

6 Put the retaining frame back into the shaving

unit.

7 Put the shaving unit back onto the shaver

(‘click’).

ENGLISH 9

Accessories

The following accessories are available:

- HQ4 ÇPhilips shaving heads.

- HQ100 Philips Shaving Head Cleaner

(not available in China).

- HQ101 Philips Shaving Head Cleaning Fluid

(not available in China).

- HQ110 Philips Shaving Head Cleaning Spray

(not available in China).

Environment

- Do not throw away the appliance with the normal

household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

- Batteries contain substances that may pollute the

environment. Do not throw away empty batteries

with the normal household waste, but dispose of

them at an ofcial collection point for batteries.

Always remove the batteries before you discard

and hand in the appliance at an ofcial collection

point

Guarantee and service

If you need service or information or if you have

a problem, please visit the Philips website at

www.philips.com or contact the Philips Consumer

Care Centre in your country (you nd its phone

number in the worldwide guarantee leaet).

If there is no Consumer Care Centre in your

country, go to your local Philips dealer.

ENGLISH10
