Philips HQ8142/16 User manual
HQ8155, HQ8150, HQ8140
ENGLISH 4
DEUTSCH 16
ESPAÑOL 28
FRANÇAIS 41
ITALIANO 54
NEDERLANDS 67
PORTUGUÊS 79
TÜRKÇE 91
4
Introduction
Congratulations on your purchase and welcome
to Philips! To fully benet from the support that
Philips offers, register your product at www.philips.
com/welcome.
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
Danger
- Make sure the adapter does not get wet.
Warning
- The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the appliance.
Caution
- Only use the adapter supplied.
- The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
- Do not use the shaver or adapter if it is damaged.
- If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
- Charge, use and store the appliance at a
temperature between 15°C and 35°C.
ENGLISH
- HQ8150/HQ8140: Never immerse the charging
stand in water nor rinse it under the tap.
- Do not recharge the shaver in a closed pouch.
- Always unplug the shaver before you clean it
under the tap.
- The shaver complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
- Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
- This washable shaver is not suitable for shaving in
the shower.
- Do not immerse the shaver in water.
- Water may leak from the socket at the bottom
of the appliance, when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed shell inside the shaver.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.
Charging
Make sure the appliance is switched off before you
start to charge it.
Charging takes approx. 1 hour.
ENGLISH 5
You can also shave without charging by connecting
the shaver to the mains.
Charge indications
Charging
- During charging, the charging light lights up green
continuously.
Battery fully charged
- When the battery is fully charged, the top light
ashes green.
Battery running low (HQ8155/HQ8150 only)
- When the battery is running low, the bottom light
burns red.
When you switch off the shaver, this light ashes a
few times.
Cordless shaving time
When the shaver is fully charged, it has a cordless
shaving time of up to 55 minutes.
Charging the appliance
HQ8155/HQ8150 only: Charge the shaver when the
bottom light lights up red.
Do not recharge the shaver in a closed pouch.
1 Put the appliance plug in the shaver.
2 Put the adapter in the wall socket.
3 Remove the adapter from the wall socket and
pull the appliance plug out of the shaver when
the battery is fully charged.
Charging stand (HQ8150/HQ8140 only)
You can also charge the appliance by placing it in the
charging stand, if provided.
ENGLISH6
- Place the shaver properly in the plugged-in
charging stand.
- Lift the shaver from the stand without tilting it.
Using the appliance
Shaving
1 Switch on the shaver by pressing the on/off
button once.
,The blue light ring round the on/off button lights
up to indicate that the motor is running.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Switch off the shaver by pressing the on/off
button once.
,The blue light ring round the on/off button goes
out.
4 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
ENGLISH 7
5 Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
You can use the trimmer to groom your sideburns
and moustache.
1 Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
2 Close the trimmer (‘click’).
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
The normal way to clean the appliance is to rinse
the shaving unit and the hair chamber with hot
water every time you have used the shaver.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Note:Water may leak from the socket at the bottom of
the appliance when you rinse it.This is normal and not
dangerous.
ENGLISH8
Every day: shaving unit and hair chamber
1 Switch off the shaver, remove the adapter from
the wall socket and pull the appliance plug out
of the shaver.
2 Press the release button to open the shaving
unit.
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
- Make sure you clean the inside as well as the
outside of the shaving unit.
4 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
5 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.
Every six months: shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
ENGLISH 9
2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn the lock clockwise.
4 Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1 Switch off the shaver, remove the adapter from
the wall socket and pull the appliance plug out
of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Charging stand (HQ8150/HQ8140 only)
You can clean the charging stand with a moist cloth.
ENGLISH10
Storage
1 Put the protection cap on the shaver to
prevent damage.
2 The appliance can be stored in the pouch
supplied.
3 The shaver can be stored in the charging stand,
if provided.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ9
Philips shaving heads only.
Note: Do not mix up the cutters and the guards to
guarantee optimal shaving performance.
1 Switch off the shaver, remove the adapter from
the wall socket and pull the appliance plug out
of the shaver.
2 Press the release button to open the shaving
unit.
3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
ENGLISH 11
4 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise.
Make sure that the projections of the shaving
heads t exactly into the recesses.
5 Close the shaving unit.
Accessories
The following accessories are available:
- HQ8500/HQ8000 adapter.
- HQ9 Philips shaving heads.
- HQ110 Philips Shaving Head Cleaning Spray.
- HQ8010 car cord.
Environment
- Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.
- The built-in rechargeable battery contains
substances that may pollute the environment.
Always remove the battery before you discard
and hand in the appliance at an ofcial collection
point. Dispose of the battery at an ofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the
appliance to a Philips service centre.The staff of
this centre will remove the battery for you and
will dispose of it in an environmentally safe way.
ENGLISH12
