Philips HQ7890CC User manual

HQ7890CC

1 2 3 4

56 7 8

9 10 11 12

13 14 15 16

17 18 19 20

HQ7890CC

ENGLISH 6

 18

 32

 43

 55

 67

 79

 92

 104

 116

 129

 142

 155

 167

 179

 192

Introduction

Congratulations on your purchase and welcome to Philips!To fully benefit

from the support that Philips offers, register your product at

www.philips.com/welcome.

Important

Read this user manual carefully before you use the shaver and the Jet

Clean system. Save the user manual for future reference.

Danger

- Make sure the adapter does not get wet (Fig. 1).

Warning

- Be careful with hot water. Always check if the water is not too hot,

to prevent your hands from getting burnt.

- The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

- The shaver and the Jet Clean system are not intended for use by

persons (including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliances by a person responsible for their safety.

- Children should be supervised to ensure that they do not play with

the shaver and the Jet Clean system.

Caution

- Do not use the shaver or the Jet Clean system if it is damaged.

- Do not immerse the shaver in water (Fig. 2).

- This shaver is not suitable for shaving in the shower.

- Charge, use and store the shaver at a temperature between 5°C

and 35°C.

- Water may leak from the socket at the bottom of the shaver when

you rinse it.This is normal and not dangerous because all electronics

are enclosed in a sealed power unit inside the shaver (Fig. 3).

- Always put the protection cap on the shaver to protect the shaving

heads when you are travelling.

ENGLISH

- The shaver, the Jet Clean system and the other accessories are not

dishwasher-proof.

- Only use the adapter supplied.

- If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

- Only use the Jet Clean systemwith the original HQ200 cleaning fluid.

- Do not immerse the Jet Clean system in water nor rinse it under the

tap. (Fig. 4)

- Use and store the Jet Clean system at a temperature between

5°C and 35°C.

- Always place the Jet Clean system on a stable, level and horizontal

surface to prevent leakage.

- Always place the Jet Clean system on a fluid-resistant surface.

- When the Jet Clean system is ready for use, do not move it to

prevent leakage of cleaning fluid.

- The Jet Clean system thoroughly cleans but does not disinfect your

shaver, therefore do not share the shaver with others.

Compliance with standards

- The shaver complies with the internationally approved IEC safety

regulations and can be safely cleaned under the tap (Fig. 5).

- The shaver and the Jet Clean system comply with all standards

regarding electromagnetic fields (EMF). If handled properly and

according to the instructions in this user manual, the appliances are

safe to use based on scientific evidence available today.

General

- The adapter transforms 100-240 volts to a safe low voltage of less

than 24 volts.

- Noise level: Lc = 60 dB [A]

ENGLISH 7

Charging

Make sure the shaver is switched off before you charge it.

Charging takes approx. 1 hour.

You can also shave without charging by connecting the shaver to the mains.

A fully charged shaver has a cordless shaving time of up to 55 minutes.

1 Charge the shaver when the bottom light flashes orange.

Charge indications

Charging

- When you start charging the empty shaver, the bottom light flashes

orange.When the battery contains enough power for one shave, the

middle charging light starts flashing green (Fig. 6).

Battery fully charged

- When the battery is fully charged, the top charging light lights up

green continuously.

Battery low

- When the battery is almost empty i.e. when there are only 5 or less

shaving minutes left, the bottom charging light starts to flash orange.

When you switch off the shaver, this light still flashes orange a few times.

Charging with the adapter

1 Put the appliance plug in the shaver (Fig. 7).

2 Put the adapter in the wall socket.

3 Remove the adapter from the wall socket and pull the appliance

plug out of the shaver when the battery is fully charged.

Charging in the Jet Clean system

1 Place the shaver in the holder and completely push down the lever

to lock the shaver into place (Fig. 8).

,The charging light on the Jet Clean system flashes to indicate that

the shaver is charging.

,When the charging light lights up continuously (after approx. 1

hour), the shaver is fully charged (Fig. 9).

ENGLISH8

2 Move the lever upwards until it does not go any further (1) and

remove the shaver from the Jet Clean system(2). (Fig. 10)

,The charging light goes out.





1 Press the on/off button once to switch on the shaver.

2 Move the shaving heads over your skin in circular

movements (Fig. 11).

- Shaving on a dry face gives the best results.

- Your skin may need 2 or 3 weeks to get accustomed to the Philips

shaving system.

Note: Do not make straight movements.

3 Press the on/off button once to switch off the shaver.

4 Clean the shaver (see chapter ‘Cleaning and maintenance’).

5 Put the protection cap on the shaver every time you have used it,

to prevent damage (Fig. 12).



You can use the trimmer to groom your sideburns and moustache.

1 Push the slide downwards to open the trimmer (Fig. 13).

Note:You can activate the trimmer while the motor is running.

2 Close the trimmer (‘click’) (Fig. 14).

Cleaning and maintenance

The best and most hygienic way to clean the shaver is in the Jet Clean

system.You can also clean the shaver by rinsing it under the tap or with

the brush supplied.

Regular cleaning guarantees better shaving performance.

Note:Water may leak from the socket at the bottom of the shaver when you

rinse it.This is normal and not dangerous.

ENGLISH 9



Preparing the Jet Clean system for use

Fill the cleaning chamber before first use and when the cleaning light

flashes to indicate that the fluid level is too low.When the fluid level

drops below the minimum level, the cleaning light flashes with intervals

and the holder returns to its starting position.

If you use the Jet Clean system to clean the shaver every day, refill the

cleaning chamber approx. every 15 days.

1 Simultaneously press the release buttons on both sides of the

cleaning chamber (1) and lift the Jet Clean system off the cleaning

chamber (2) (Fig. 15).

The cleaning chamber remains behind.

2 Unscrew the dosing cap from the bottle with HQ200 Cleaning

Fluid and remove the airtight seal.

3 Fill the cleaning chamber with cleaning fluid up to the MAX

indication (Fig. 16).

4 Place the Jet Clean system back onto the cleaning chamber (Fig. 17).

Make sure the release buttons snap back into place.

5 Put the appliance plug in the Jet Clean system and put the adapter

in the wall socket (Fig. 18).

,The holder automatically moves to the highest position.

The Jet Clean system is now ready for use.



1 Place the shaver in the holder and completely push down the lever

to lock the shaver into place.

,The charging light on the Jet Clean system flashes to indicate that

the shaver is being charged.

2 Press the start button to start the cleaning program. (Fig. 19)

The cleaning light starts flashing and the shaver is automatically lowered

into the cleaning fluid.

,During the cleaning program, which takes approx. 1 hour, the

cleaning light flashes continuously.

ENGLISH10
