Philips HQ7405/15 User manual

ENGLISH 4

DEUTSCH 13

FRANÇAIS 22

NEDERLANDS 31

ESPAÑOL 40

ITALIANO 49

PORTUGUÊS 58

TÜRKÇE 67

HQ7415, HQ7405

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug supplied.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts.

◗The powerplug contains a transformer. Do

not cut off the powerplug to replace it with

another plug, as this will cause a hazardous

situation.

◗Do not use a damaged powerplug.

◗If the powerplug is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

C◗Make sure the powerplug does not get wet.

◗Store and use the appliance at a temperature

between 5cC and 35cC.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

◗Always unplug the shaver before cleaning it

under the tap.

ENGLISH4

Using the appliance

Shaving

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

3Switch the shaver on by pressing the on/off

button once.

C4Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips system.

5Switch the shaver off by pressing the on/off

button once.

C6Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

ENGLISH 5

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit and the hair

chamber with hot water every time you have

used the shaver.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

C◗For extra thorough cleaning, the Philips

Action Clean (shaving head cleaner, type

HQ100) is available.Ask your Philips dealer

for information.

BThe Philips Action Clean may not be available in

all countries. Contact the Customer Care Centre

in your country about the availability of this

accessory.

You can also clean the shaver in the following

way:

Every day: shaving unit and hair chamber

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button (1) and open the

shaving unit (2).

ENGLISH6

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

4Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue

as this may damage the shaving heads.

C5Open the shaving unit again and leave it

open to let the appliance dry completely.

You can also clean the hair chamber without

water by using the brush supplied.

Every six months: shaving heads

C1Open the shaving unit, turn the wheel

anticlockwise (1) and remove the retaining

frame (2).

C2Clean the cutters and guards with the

brush supplied.

Do not clean more than one cutter and guard at

a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may

take several weeks before optimal shaving

performance is restored.

ENGLISH 7

3Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit, press the wheel (1) and turn it

clockwise (2) (also see chapter

'Replacement').

4Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer with the brush

supplied.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗The appliance can be stored in the pouch

supplied (HQ7415 only).

ENGLISH8

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with

HQ6 Philips Quadra shaving heads only.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button (1) and open the

shaving unit (2).

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit in such a way that

the parts with the small holes point

towards the centre of the shaving unit.

Make sure that the projections of the shaving

heads fit exactly into the recesses.

C5Put the retaining frame back into the

shaving unit, press the wheel (1) and turn it

clockwise (2).

6Close the shaving unit.

ENGLISH 9

Accessories

The following accessories are available:

- HQ8000 powerplug.

- HQ6 Philips Quadra shaving heads.

- HQ100 Philips Action Clean (shaving head

cleaner).

- HQ101 Philips Action Clean refill (shaving head

cleaning liquid).

- HQ110 Philips shaving head cleaner (shaving

head cleaning spray).

Environment

C◗Do not throw the appliance away with the

normal household waste at the end of its life,

but hand it in at an official collection point for

recycling. By doing this you will help to

preserve the environment.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

ENGLISH10

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.

BThe shaver has not been rinsed long enough or

the water used was not hot enough.

◗Clean the shaver thoroughly before you

continue shaving (see chapter 'Cleaning and

maintenance').

BCause 2: long hairs are obstructing the shaving

heads.

◗Clean the cutters and guards with the brush

supplied. See chapter 'Cleaning and

maintenance', section 'Every six months:

shaving heads'.

BCause 3: the shaving heads are damaged or worn.

◗Replace the shaving heads. See chapter

'Replacement'.

2The shaver does not work when the on/off

button is pressed

BCause: the shaver is not connected to the mains.

◗Put the powerplug in the wall socket.

3The shaving unit has come off the shaver

BCause: the shaving unit has not been placed

correctly.

ENGLISH 11

C◗If the shaving unit becomes detached from the

shaver, check whether the hinge spring is still

properly attached, i.e. has not come loose and

does not show any cracks or damage. If the

hinge spring is still properly attached, the

shaving unit can be easily put back on the

shaver again. However, if the hinge spring has

come loose, is cracked or damaged, please

contact your Philips dealer or the nearest

Philips service centre to avoid damage to your

shaver.
