Philips HQ7363/17 User manual

HQ7390, HQ7380, HQ7363, HQ7360

ENGLISH 4

FRANÇAIS 15

Introduction

Congratulations on your purchase and welcome

to Philips! To fully benet from the support that

Philips offers, register your product at www.philips.

com/welcome.

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

Danger

- Make sure the adapter does not get wet.

Warning

- The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

- This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

- Children should be supervised to ensure that they

do not play with the appliance.

Caution

- Do not use the shaver or the adapter if it is

damaged.

- Only use the adapter supplied.

- If the adapter is damaged, always have it replaced

with one of the original type in order to avoid a

hazard.

- Charge, use and store the shaver at a temperature

between 5°C and 35°C.

- Always unplug the shaver before you clean it

under the tap.

ENGLISH

- Be careful with hot water. Always check if the

water is not too hot, to avoid burning your hands.

- The appliance complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

- This washable shaver is not suitable for shaving in

the shower.

- Do not immerse the shaver in water.

- Water may leak from the socket at the bottom

of the appliance when you rinse it.This is normal

and not dangerous because all electronics are

enclosed in a sealed power unit inside the shaver.

General

- The adapter transforms 100-240 volts to a safe

low voltage of less than 24 volts.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

Charging

Make sure the appliance is switched off before you

start to charge it.

When you charge the shaver for the rst time

or after a long period of disuse, let it charge

continuously for at least 12 hours, for instance

overnight.

ENGLISH 5

Charging normally takes 1 hour.

You can also shave without charging by connecting

the shaver to the mains.

Charge indications

Charging

- When you start charging the empty shaver, the

charging light goes on.

Battery fully charged

- When the battery is fully charged, the charging

light starts ashing.

When you unplug the shaver, the charging light goes

out.

Battery running low

- When the battery is running low, the battery-low

light goes on.

When you switch off the shaver, this light ashes a

few times.

Cordless shaving time

After having been charged for 6 minutes, the battery

contains enough energy for one shave.

When the shaver is fully charged, it has a cordless

shaving time of up to 35 minutes.

Charging the appliance

Charge the shaver when the battery-low light goes

on.

1 Put the appliance plug in the shaver.

2 Put the adapter in the wall socket.

3 Remove the adapter from the wall socket and

pull the appliance plug out of the shaver when

the battery is fully charged.

ENGLISH6

Using the appliance

Shaving

1 Press the on/off button once to switch on the

shaver.

,The power-on lights go on.

2 Move the shaving heads quickly over your skin.

Make both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get accustomed

to the Philips shaving system.

3 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

4 Put the protection cap on the shaver every

time you have used it, to prevent damage to

the shaving heads.

Trimming

You can use the trimmer to groom your sideburns

and moustache.

1 Push the slide downwards to open the

trimmer.

The trimmer can be activated while the motor is

running.

2 Close the trimmer after trimming (‘click’).

ENGLISH 7

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

Be careful with hot water.Always check if the

water is not too hot, to avoid burning your hands.

Note:Water may leak from the socket at the bottom of

the appliance when you rinse it.This is normal and not

dangerous.

Every day: shaving unit and hair chamber

1 Switch off the shaver, remove the adapter from

the wall socket and pull the appliance plug out

of the shaver.

2 Press the release button to open the shaving

unit.

3 Rinse the hair chamber and the inside of the

shaving unit under a hot tap for some time.

4 Rinse the outside of the shaving unit.

5 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

ENGLISH8

6 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

by using the brush supplied.

Every six months: shaving heads

1 Press the release button to open the shaving

unit, turn the lock anticlockwise (1) and

remove the retaining frame (2).

2 Clean the cutters and guards with the brush

supplied.

Note: Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it may take

several weeks before optimal shaving performance is

restored.

3 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn the lock clockwise.

4 Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1 Switch off the shaver, remove the adapter from

the wall socket and pull the appliance plug out

of the shaver.

ENGLISH 9

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Storage

- Put the protection cap on the shaver to prevent

damage to the shaving heads.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ8

Philips shaving heads only.

Note: Do not mix up the cutters and the guards to

guarantee optimal shaving performance.

1 Switch off the shaver, remove the adapter from

the wall socket and pull the appliance plug out

of the shaver.

2 Press the release button to open the shaving

unit.

ENGLISH10

3 Turn the lock anticlockwise (1) and remove the

retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit. Put the retaining frame

back into the shaving unit and turn the lock

clockwise.

Make sure that the projections of the shaving

heads t exactly into the recesses.

5 Close the shaving unit.

Accessories

The following accessories are available:

- HQ8500/HQ8000 adapter.

- HQ8 Philips Shaving Heads.

- HQ110 Philips Shaving Head Cleaning Spray.

- HQ8010 car cord.

Note: Some accessories may not be available in all

countries. Contact the Consumer Care Centre in your

country about the availability of the accessories.

Environment

- Do not throw away the appliance with the normal

household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

ENGLISH 11

- The built-in rechargeable lithium-ion (Li-ion)

battery contains substances that may pollute the

environment.Always remove the battery before

you discard and hand in the appliance at an ofcial

collection point. Dispose of the battery at an

ofcial collection point for batteries. If you have

trouble removing the battery, you can also take

the appliance to a Philips service centre.The staff

of this centre will remove the battery for you and

will dispose of it in an environmentally safe way.

Removing the rechargeable battery

Only remove the rechargeable battery if it is

completely empty.

1 Remove the adapter from the wall socket and

pull the appliance plug out of the shaver.

2 Let the shaver run until it stops, undo the two

screws in the hair chamber and remove it.

3 Undo the two screws at the back of the shaver

and remove the back panel of the housing.

4 Pull the side panels off the sealed power unit.

ENGLISH12
