Philips HQ7330 User manual

Электробритвы Philips HQ7330/19 Серия 7000:

Инструкция пользователя



 4

 16

 29

 41

 52

 64

 76

 89

 100

 112

 124

 136

 149

 161

 172

 184

 196

 209



Congratulations on your purchase and welcome to

Philips! To fully benet from the support that Philips

offers, register your product at

www.philips.com/welcome.



Read this user manual carefully before you use the

appliance and save it for future reference.



- Make sure the adapter does not get wet.



- The adapter contains a transformer. Do not cut

off the adapter to replace it with another plug, as

this causes a hazardous situation.

- This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

- Children should be supervised to ensure that they

do not play with the appliance.



- Do not use the shaver or the adapter if it is

damaged.

- Only use the adapter supplied.

- If the adapter is damaged, always have it replaced

with one of the original type in order to avoid a

hazard.

- Charge, use and store the shaver at a temperature

between 5°C and 35°C.



- Always unplug the shaver before you clean it

under the tap and before you use the appliance in

the bath or shower.

- Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

- The appliance complies with the internationally

approved IEC safety regulations and can be safely

used in the bath or shower and cleaned under

the tap.

- Do not immerse the shaver in water.

- Water may leak from the socket at the bottom

of the appliance when you rinse it. This is normal

and not dangerous because all electronics are

enclosed in a sealed power unit inside the shaver.

- The shaver and the other accessories are not

dishwasher-proof.



- The adapter transforms 100-240 volts to a safe

low voltage of less than 24 volts.

- Noise level: Lc = 59dB(A)



This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.



Make sure the appliance is switched off before you

start charging it.

 5

When you charge the shaver for the rst time

or after a long period of disuse, let it charge

continuously for at least 12 hours, for instance

overnight.

Charging normally takes 1 hour.

After having been charged for 6 minutes, the battery

contains enough energy for one shave.

When the shaver is fully charged, it has a shaving

time of up to 35 minutes.

Note: The shaver cannot be used directly from the

mains.





,When you start charging the empty shaver, the

charging light goes on.



,When the battery is fully charged, the charging

light starts to ash.

When you unplug the shaver, the charging light goes

out.



,When the battery is running low, the battery-low

light goes on.

When you switch off the shaver, this light ashes a

few times.



Charge the shaver when the battery-low light goes

on.

6

1 Put the appliance plug in the shaver.

2 Put the adapter in the wall socket.

3 Remove the adapter from the wall socket and

pull the appliance plug out of the shaver when

the battery has been fully charged.





1 Press the on/off button once to switch on the

shaver.

The power-on lights go on to indicate that the

motor is running.

2 Apply Nivea shaving foam to your face, for a

fresh shaving sensation.

3 Move the shaving heads quickly over your skin,

making both straight and circular movements.

- Moisten the shaving heads for an optimal shaving

performance.

- Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

4 Press the on/off button once to switch off the

shaver.

The power-on lights go out.

5 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

 7

6 Put the protection cap on the shaver every

time you have used it, to prevent damage to

the shaving heads.



For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

2 Close the trimmer (‘click’).



Regular cleaning guarantees better shaving

performance.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

Note: Water may leak from the socket at the bottom of

the appliance when you rinse it. This is normal and not

dangerous.

8



1 Switch off the shaver, remove the adapter from

the wall socket and pull the appliance plug out

of the shaver.

2 Press the release button to open the shaving

unit.

3 Clean the shaving unit and the hair chamber by

rinsing them under a hot tap for some time.

,Make sure you clean the inside as well as the

outside of the shaving unit.

4 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

5 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

by using the brush supplied.



1 Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

 9

2 Clean the cutters and guards with the brush

supplied.

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

3 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn the lock clockwise.

4 Close the shaving unit.



Clean the trimmer every time you have used it.

1 Switch off the shaver, remove the adapter from

the wall socket and pull the appliance plug out

of the shaver.

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.



- Put the protection cap on the shaver to prevent

damage to the shaving heads.

10



Replace the shaving heads every two years for

optimal shaving results.’

Replace damaged or worn shaving heads with HQ8

Philips shaving heads only.

Note: Do not mix up the cutters and the guards to

guarantee optimal shaving performance.

1 Switch off the shaver, remove the powerplug

from the wall socket and pull the appliance plug

out of the shaver.

2 Press the release button to open the shaving

unit.

3 Turn the lock anticlockwise (1) and remove the

retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit. Put the retaining frame

back into the shaving unit and turn the lock

clockwise.

Make sure that the projections of the shaving

heads t exactly into the recesses.

5 Close the shaving unit.



The following accessories are available:

- HQ8500/HQ8000 powerplug.

- HQ8 Philips Shaving Heads.

- HQ110 Philips Shaving Head Cleaning Spray.

- HQ8010 car cord.

 11
