Philips HQ7130 User manual

HQ7130, HQ7120

ENGLISH 4

DEUTSCH 15

ESPAÑOL 27

FRANÇAIS 38

ITALIANO 50

NEDERLANDS 61

PORTUGUÊS 72

TÜRKÇE 83

Important

Read this user manual carefully before you use the

appliance and save it for future reference.

This appliance is not intended for use by persons

(including children) with reduced physical, sensory

or mental capabilities, or lack of experience

and knowledge, unless they have been given

supervision or instruction concerning use of the

appliance by a person responsible for their safety.

Children should be supervised to ensure that they

do not play with the appliance.

Only use the powerplug supplied.

The powerplug transforms 100-240 volts to a safe

low voltage of less than 24 volts.

The powerplug contains a transformer. Do not cut

off the powerplug to replace it with another plug,

as this causes a hazardous situation.

Do not use a damaged powerplug.

If the powerplug is damaged, always have it

replaced with one of the original type in order to

avoid a hazard.

Make sure the powerplug does not get wet.

Charge and store the shaver at a temperature

between 5°C and 35°C.

Always unplug the shaver before cleaning it under

the tap.

The appliance complies with the internationally

approved IEC safety regulations and can be safely

cleaned under the tap.

Be careful with hot water. Always check if the water

is not too hot, to prevent your hands from getting

burnt.

This washable shaver is not suitable for shaving in

the shower.

ENGLISH

Do not immerse the shaver in water.

Water may leak from the socket at the bottom

of the appliance when you rinse it.This is normal

and not dangerous because all electronics are

enclosed in a sealed power unit inside the shaver.

To extend the lifetime of the battery:

do not charge the shaver for more than 12 hours.

only charge the shaver when the battery-low light

goes on.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards

regarding electromagnetic elds (EMF). If handled

properly and according to the instructions in this

user manual, the appliance is safe to use based on

scientic evidence available today.

Charging

Make sure the appliance is switched off before you

start to charge it.

Charging takes approx. 8 hours.

To extend the lifetime of the battery, do not charge

the shaver for more than 12 hours.

ENGLISH 5

Charge indications

Charging

When you start charging the empty shaver, the

charging light goes on.

Battery running low

When the battery is running low, the battery-low

light goes on.

When you switch off the shaver, this light ashes a

few times.

Cordless shaving time

After charging, the shaver has a cordless shaving time

of up to 30 minutes.

Charging the appliance

Only charge the shaver when the battery-low light

goes on.

1 Put the appliance plug in the shaver.

2 Put the powerplug in the wall socket.

3 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver

when the battery has been fully charged (after

approx. 8 hours).

Using the appliance

The shaver cannot be used directly from the mains.

ENGLISH6

Shaving

1 Press the on/off button once to switch on the

shaver.

The power-on lights go on to indicate that the

motor is running.

2 Move the shaving heads quickly over your skin,

making both straight and circular movements.

Shaving on a dry face gives the best results.

Your skin may need 2 or 3 weeks to get

accustomed to the Philips shaving system.

3 Press the on/off button once to switch off the

shaver.

The power-on lights go out.

4 Clean the shaver (see chapter ‘Cleaning and

maintenance’).

5 Put the protection cap on the shaver every

time you have used it, to prevent damage to

the shaving heads.

Trimming

For grooming sideburns and moustache.

1 Open the trimmer by pushing the slide

downwards.

The trimmer can be activated while the motor is

running.

2 Close the trimmer (‘click’).

ENGLISH 7

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

Be careful with hot water.Always check if the

water is not too hot, to prevent your hands from

getting burnt.

Note:Water may leak from the socket at the bottom of

the appliance when you rinse it.This is normal and not

dangerous.

Every day: shaving unit and hair chamber

1 Switch off the shaver.

2 Press the release button to open the shaving

unit.

3 Clean the shaving unit and the hair chamber by

rinsing them under a hot tap for some time.

Make sure you clean the inside as well as the

outside of the shaving unit.

4 Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue,

as this may damage the shaving heads.

ENGLISH8

5 Open the shaving unit again and leave it open

to let the appliance dry completely.

You can also clean the hair chamber without water

by using the brush supplied.

Every six months: shaving heads

1 Open the shaving unit, turn the lock

anticlockwise (1) and remove the retaining

frame (2).

2 Clean the cutters and guards with the brush

supplied.

Do not clean more than one cutter and guard

at a time, since they are all matching sets. If you

accidentally mix up the cutters and guards, it

may take several weeks before optimal shaving

performance is restored.

3 Put the shaving heads back into the shaving

unit. Put the retaining frame back into the

shaving unit and turn the lock clockwise.

4 Close the shaving unit.

Trimmer

Clean the trimmer every time you have used it.

1 Switch off the shaver.

ENGLISH 9

2 Clean the trimmer with the brush supplied.

3 Lubricate the trimmer teeth with a drop of

sewing machine oil every six months.

Storage

Put the protection cap on the shaver to prevent

damage to the shaving heads.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

Replace damaged or worn shaving heads with HQ8

Philips shaving heads only.

Note: Do not mix up the cutters and the guards to

guarantee optimal shaving performance.

1 Switch off the shaver.

2 Press the release button to open the shaving

unit.

ENGLISH10

3 Turn the lock anticlockwise (1) and remove the

retaining frame (2).

4 Remove the shaving heads and place new ones

in the shaving unit. Put the retaining frame

back into the shaving unit and turn the lock

clockwise.

Make sure that the projections of the shaving

heads t exactly into the recesses.

5 Close the shaving unit.

Accessories

The following accessories are available:

HQ8500/HQ8000 powerplug.

HQ8 Philips Shaving Heads.

HQ110 Philips Shaving Head Cleaning Spray.

HQ8010 car cord.

Environment

Do not throw away the appliance with the normal

household waste at the end of its life, but hand

it in at an ofcial collection point for recycling. By

doing this, you help to preserve the environment.

Disposal of the battery

The built-in rechargeable NiMH battery contains

substances that may pollute the environment.

ENGLISH 11

Always remove the battery before you discard

and hand in the appliance at an ofcial collection

point. Dispose of the battery at an ofcial collection

point for batteries. If you have trouble removing the

battery, you can also take the appliance to a Philips

service centre.The staff of this centre will remove

the battery for you and will dispose of it in an

environmentally safe way.

Only remove the battery if it is completely empty.

1 Remove the powerplug from the wall socket

and pull the appliance plug out of the shaver.

2 Let the shaver run until it stops, undo the two

screws in the hair chamber and remove it.

3 Undo the two screws at the back of the shaver

and remove the back panel of the housing.

4 Remove the side panels by pulling them off the

sealed power unit.

5 Undo the three screws in the sealed power

unit.

ENGLISH12
