Philips HQ686/02 User manual

ENGLISH 4

BAHASA MELAYU 14

BAHASA INDONESIA 25

TI”NG VI◊T 36

 46

HQ686

Important

Read these instructions for use carefully before

using the appliance and save them for future

reference.

◗Only use the powerplug supplied to charge

and use the appliance.

◗The powerplug transforms 100-240 volts to a

safe low voltage of less than 24 volts. Only the

powerplug supplied guarantees safe

transformation.

◗The powerplug contains a transformer. Do

not cut off the powerplug to replace it with

another plug, as this will cause a hazardous

situation.

◗If the powerplug is damaged, always have it

replaced by one of the original type in order

to avoid a hazard.

◗Charge, store and use the appliance at a

temperature between 5cC and 35cC.

◗Do not recharge the shaver in a closed pouch.

C◗Make sure the powerplug and the cord do not

get wet.

C◗The appliance complies with the

internationally approved IEC safety regulations

and can be safely cleaned under the tap.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

ENGLISH4

Charging

Make sure the appliance is switched off before

you start charging it.

When you charge the shaver for the first time or

after a long period of disuse, leave it to charge

continuously for 4 hours.

Charging normally takes approx. 1 hour.

Do not leave the appliance connected to the

mains for more than 24 hours.

You can also shave without charging by

connecting the shaver to the mains.

Charge indications

C◗As soon as you start charging the empty

shaver, the green pilot light goes on.

◗When the battery has been fully charged, the

green pilot light starts blinking.

C◗The red pilot light goes on when the battery

is almost empty.When you switch the

appliance off, the red pilot light blinks a few

times.

ENGLISH 5

Charging the appliance

Do not recharge the shaver in a closed cassette.

C1Put the appliance plug in the shaver.

2Put the powerplug in the wall socket.

3Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver when the battery has been fully

charged.

Cordless shaving time

A fully charged shaver has a cordless shaving time

of up to 30 minutes.

Using the appliance

Shaving

1Remove the appliance plug from the shaver

before you start shaving.

2Switch the shaver on by pressing the on/off

button once.

C3Move the shaving heads quickly over your

skin, making both straight and circular

movements.

Shaving on a dry face gives the best results.

ENGLISH6

Your skin may need 2 or 3 weeks to get

accustomed to the Philishave system.

4Switch the shaver off by pressing the on/off

button once.

C5Put the protection cap on the shaver every

time you have used it, to prevent damage.

Trimming

For grooming sideburns and moustache.

C1Open the trimmer by pushing the slide

upwards.

The trimmer can be activated while the motor is

running.

Cleaning and maintenance

Regular cleaning guarantees better shaving

performance.

The easiest and most hygienic way to clean the

appliance is to rinse the shaving unit and the hair

chamber with hot water every time you have

used the shaver.

Be careful with hot water. Always check if the

water is not too hot, to prevent your hands from

getting burnt.

C◗For easy and optimal cleaning, the Philishave

Action Clean (shaving-head cleaner, type

ENGLISH 7

HQ100) is available.Ask your Philishave dealer

for information.

BThe Philishave Action Clean may not be available

in all countries. Contact the Customer Care Centre

in your country about the availability of this

accessory.

Shaving unit

When you clean the appliance, it is not necessary

to take the shaving heads (cutters and guards)

apart. If you want to take them apart, be sure not

to mix up the cutters and guards, since grinding of

the cutters in the guards only guarantees optimal

performance for each matching set. If you

accidentally mix up the sets, it could take several

weeks before optimal shaving performance is

restored.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button to open the

shaving unit.

C3Clean the shaving unit and the hair

chamber by rinsing them under a hot tap

for some time.

4Close the shaving unit and shake off excess

water.

Never dry the shaving unit with a towel or tissue

as this may damage the shaving heads.

ENGLISH8

C1Open the shaving unit again and leave it

open to let the appliance dry completely.

◗You can also clean the hair chamber without

water by using the brush supplied.

Trimmer

Clean the trimmer every time you have used it.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Clean the trimmer with the brush.

C3Lubricate the trimmer teeth with a drop

of sewing machine oil every six months.

Storage

C◗Put the protection cap on the shaver to

prevent damage.

◗Store the powerplug and the shaver in the

luxury pouch.

Replacement

Replace the shaving heads every two years for

optimal shaving results.

ENGLISH 9

OIL

Replace damaged or worn shaving heads with

Philishave HQ6 Quadra shaving heads only.

1Switch the shaver off, remove the

powerplug from the wall socket and pull

the appliance plug out of the shaver.

C2Press the release button to open the

shaving unit.

C3Turn the wheel anticlockwise (1) and

remove the retaining frame (2).

C4Remove the shaving heads and place new

ones in the shaving unit in such a way that

the projections fit exactly into the

recesses in the shaving unit.

5Put the retaining frame back into the

shaving unit, press the wheel and turn it

clockwise.

6Close the shaving unit.

C◗If the shaving heads have been properly

inserted, the shiny parts are pointing inwards

and towards each other.

Accessories

The following accessories are available:

- HQ8000 powerplug.

ENGLISH10

- HQ6 Philishave Quadra shaving heads.

- HQ100 Philishave Action Clean (shaving head

cleaner).

- HQ101 Philishave Action Clean refill (shaving

head cleaning liquid).

- HQ110 Philishave shaving head cleaner (shaving

head cleaning spray).

Environment

The built-in rechargeable battery contains

substances that may pollute the environment.

Disposal of the battery

Remove the battery when you discard the

appliance. Do not throw the battery away with

the normal household waste, but hand it in at an

official collection point.You can also take the

appliance to a Philips service centre, which will

remove the battery for you and will dispose of it

in an environmentally safe way.

Only remove the battery if it is completely empty.

1Remove the powerplug from the wall

socket and pull the appliance plug out of

the shaver.

C2Let the shaver run until it stops, undo the

screws and open the shaver.

3Remove the battery.

ENGLISH 11

Do not connect the shaver to the mains again

after the battery has been removed.

Guarantee & service

If you need information or if you have a problem,

please visit the Philips Web site at

www.philips.com or contact the Philips Customer

Care Centre in your country (you will find its

phone number in the worldwide guarantee

leaflet). If there is no Customer Care Centre in

your country, turn to your local Philips dealer or

contact the Service Department of Philips

Domestic Appliances and Personal Care BV.

Troubleshooting

1Reduced shaving performance

BCause 1: the shaving heads are dirty.The shaver

has not been rinsed long enough or the water

used was not hot enough.

◗Clean the shaver thoroughly before you

continue shaving (see chapter 'Cleaning

maintenance').

BCause 2: long hairs are obstructing the shaving

heads.

C◗Remove the retaining frame from the shaving

unit by turning the wheel anticlockwise.

◗Remove the shaving heads from the shaving

unit.

ENGLISH12
